Maintenance

SW1 SW2
ON OFF
OFF ON
OFF OFF
OFF OFF
OFF OFF
Note: HMI Power must be cycled to enable the DIP switch mode.
Touchscreen Calibration mode: This mode allows calibration of the
touchscreen. This mode can also be entered by pressing anywhere on
the screen for several seconds during HMI powerup.
Hide System Toolbar: Hides the arrow in the bottom-right corner of the
screen that accesses the System Toolbar (same as "Hide System
Toolbar" in System Parameters and LB9020).
Boot Loader mode: This mode is used when replacing or reinstalling
the operating system and is intended for use by qualified repair
personnel only. Improper use by setting to ON may damage the HMI.
Contact Maple Systems for more information.

Fusing Requirements

If the display does not come on within two seconds of power up, remove
power. An internal fuse will prevent damage if the polarity of the DC
power is incorrect. Check wiring to ensure proper connections and try to
power up again.
1010-1014 Rev 03
DIP switch positions (not on all models)
DIP switches shown in the off position.
SW3 SW4
OFF OFF
OFF OFF
ON OFF
OFF ON
OFF OFF
Mode
Touchscreen Calibration mode
Hide System Toolbar
Boot Loader mode
Reserved
Normal operation
