GN35DR
CURVED GAMING MONIT
OR
USER MANUAL
In order to continue serving our customers and providing the best products, our product information
including our user manuals may receive updates from time to time. Please check our website for the
latest user manuals and product materials. Ver 1.0 7/31/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GN35DR and is the answer not in the manual?

Questions and answers

Related Manuals for Viotek GN35DR

Summary of Contents for Viotek GN35DR

  • Page 1 GN35DR CURVED GAMING MONIT USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. Ver 1.0 7/31/18...

  • Page 3: Table Of Contents

    Table of Contents Section 1: Safety Precautions..............4 Section 2: Box Contents .................5 Section 3: Product Overview ..............6 3.1 – Monitor Buttons .................6 3.2 – Monitor Ports ................6 Section 4: Stand Installation ..............7 Section 5: Wall Mounting................9 Section 6: Connectivity Options ............10 6.1 –...

  • Page 4: Section 1: Safety Precautions

    VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter.

  • Page 5: Section 2: Box Contents

    Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 Cover Base x 1 (with Attached Bracket) NO. 3 Screws x 4 NO. 1 Screw x 1 NO. 2 Screws x 3 (for Wall Mounting) Cover x 1 Power Cable x 1 (AC 100-240V, 50/60Hz)

  • Page 6: Section 3: Product Overview

    Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off.

  • Page 7: Section 4: Stand Installation

    Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Stand Stem Stand Base Foam Monitor Foam 2.
  • Page 8 5. Align the stand stem’s bracket with the opening on the back of the monitor. With the top going in first, carefully insert the bracket. The pieces should click into place. 6. Place the monitor on your desktop or table after completing installation and carefully pull or push it up or down to adjust height.

  • Page 9: Section 5: Wall Mounting

    Section 5: Wall Mounting This monitor ONLY includes screws which may be used when attaching the monitor to a mount. No mount or mounting accessory is included. 1. Open the package, take out the product with foam still attached, and gently place it on a desktop or table.

  • Page 10: Section 6: Connectivity Options

    Section 6: Connectivity Options 6.1 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an wall outlet. Power Cable 6.2 – Connecting Your Earphones Plug in your earphones to receive audio signals from your monitor. If your earphones are connected to the monitor and audio devices are connected to your computer at the same time, the audio devices will not produce sound.

  • Page 11: Dp Connectivity

    6.3 – DP Connectivity In order for the Monitor to receive DP signals from the computer, use the DP cable to connect the Monitor to the computer. DP Cable (Included) DP OUTPUT 6.4 – HDMI Connectivity In order for the monitor to receive HDMI signals from the computer, use an HDMI cable to connect the monitor to the computer.

  • Page 12: Section 7: Basic Operation

    Section 7: Basic Operation Insert one end of the DP cable into your PC’s graphics card. Other connection types may be used. Additional cables not included. For optimal refresh rate (or “performance”), it is recommended to use a DP (display port) or DVI-D dual link cable with the monitor’s corresponding connector.

  • Page 13: Section 9: Osd

    Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration and parts etc.

  • Page 14: Osd Menu Functions

    9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description Input Source NONE Switch to DVI signal input HDMI NONE Switch to HDMI signal input NONE Switch to DP signal input Brightness/ Brightness 0~100 Adjust display brightness Contrast Contrast 0~100 Adjust display contrast Turn on DCR function Turn off DCR function...
  • Page 15 Main Menu Sub-Menu Options Description Audio Mute On, Off Turn mute mode on/off Volume 0-100 Adjust audio volume Audio Source Auto Source, Select audio signal input via HDMI or DP HDMI, DP Multi-Window Multi-Window Off, PIP Mode, Select PIP/PBP modes according to the PBP 2Win number of input signals etc.

  • Page 16: Section 10: Eco Modes And Gameplus Switching

    Section 10: ECO Modes and Gameplus Switching Press any one of the buttons (M, , E, ) to activate the navigation window. 2. Press button to switch ECO modes. These modes include Standard, Text, Movie, Game, FPS, and RTS and can be used to optimize settings according to your activity. Standard mode is suitable for most activities.
  • Page 17 The color bleeds or visual effects appear unusual. • If your screen is all red or blue, or any colors disappear, check to see that the cable is properly inserted. A loose connection can cause a bad signal. • Try connecting to another video source for comparison. The screen appears to be scrolling, rolling, or moving unusually.

  • Page 18: Pip (Picture In Picture) Input Information

    11.2 – PIP (Picture in Picture) Input Information Mode Home Screen Picture in Picture Additional Input Interchange Picture Input Source Source Window Mode HDMI Mode 1 Mode 2 HDMI Mode 3 Note: ”O” means this feature is supported while “X” means it is not supported. 11.3 –...

  • Page 19: Section 12: Information

    20.57 lbs/29.56 lbs 12.2 – Resolution Compatibility for DVI/DP System Requirements below are the minimum system requirements for your GN35DR monitor. The requirements are recommended in order to properly use all of the monitor’s features and ensure high-quality picture. Minimum Requirements Operating System: Windows® 7 / Windows®...

  • Page 20: Section 13: 1 Year Limited Hardware Warranty

    Section 13: 1 Year Limited Hardware Warranty Your VIOTEK GN35DR Curved Gaming Monitor (”Product”) includes a One Year ® Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada only and is available only to original purchasers.
  • Page 21 FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 24 COPYRIGHT © 2018 VIOTEK. ALL RIGHTS RESERVED.
