- Page 1 GN32DA CURVED GAMING MONIT USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. Ver 1.0 6/11/19...
-
Page 2: Table Of Contents
Table of Contents Section 1: Safety Precautions..............3 Section 2: Box Contents .................4 Section 3: Product Overview ..............5 3.1 – Monitor Buttons ...............5 3.2 – Monitor Ports ................5 Section 4: Stand Installation ..............6 Section 5: Wall Mounting................7 Section 6: Connectivity Options ............8 6.1 –... -
Page 3: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter. -
Page 4: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 Cable Clip x 1 NO. 1 Screw x 1 NO. 2 Screws x 2 NO. 3 Screws x 4 DP Cable x 1 (for Wall Mounting) Power Cable x 1 Screwdriver x 1 User Manual x 1... -
Page 5: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons Power Connector: Insert the power cable to supply power to the monitor. M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. -
Page 6: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. 2. Take out the cable clip, stand stem and stand base. Remove the foam covering the bottom of the monitor. -
Page 7: Section 5: Wall Mounting
Section 5: Wall Mounting This monitor ONLY includes screws which can be used for attaching the monitor to a mount. No mount or mounting accessory is included. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. -
Page 8: Section 6: Connectivity Options
Section 6: Connectivity Options 6.1 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an wall outlet. Power Cable 6.2 – Connecting Headphones Plug in your headphones, or any 3.5mm-compatible external audio device, to receive audio signals from your monitor. -
Page 9: Dp Connectivity
6.3 – DP Connectivity In order for the monitor to receive DP signals from the computer, use the DP cable to connect the monitor to the computer. DP Cable (included) DP OUTPUT 6.4 – HDMI Connectivity In order for the monitor to receive HDMI signals from the computer, use an HDMI cable to connect the monitor to the computer. -
Page 10: Section 7: Basic Operation
Section 7: Basic Operation Insert one end of the DP cable into your PC’s graphics card. Other connection types may be used. Additional cables not included. For optimal refresh rate (or “performance”), it is recommended to use a DisplayPort (DP) or DVI-D dual link cable with the monitor’s corresponding connector. 2. -
Page 11: Section 9: Osd
Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s specifications. -
Page 12: Osd Menu Functions
9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description NONE Switch to DVI signal input Input Source HDMI NONE Switch to HDMI signal input NONE Switch to DP signal input Brightness 0~100 Adjust display brightness Contrast 0~100 Adjust display contrast Brightness/ Contrast Turn on DCR function... -
Page 13: Section 10: Eco Modes And Gameplus Switching
Main Menu Sub-Menu Options Description Multi- Multi-Window Off, PIP Mode, Select PIP/PBP modes according to the Window PBP 2Win number of input signals etc. Sub Win2 Input DVI, HDMI, DP Select according to input signal for PIP/ PBP mode PIP Size Adjust the PIP/PBP display window size Small, Medium, Large... -
Page 14: Section 11: Troubleshooting
• Press E ( ) to set RGB range (Limited or Full) effects. RGB Range:Limited Section 11: Troubleshooting 11.1 – General Problems The screen is blank • Press the power button to turn the monitor on. • Confirm the brightness and contrast settings are set normally. •... -
Page 15: Pip (Picture In Picture) Input Information
• Check if the graphics card is installed properly. • Make sure the power cable is properly connected to the monitor and power source. Image position is not centered/the size is not right • Please adjust Clock or Auto settings. Color difference (colors are not optimized) •... -
Page 16: Section 12: Information
Net Weight (with stand) 17.7Ibs / 8.05kg 12.2 – Resolution Compatibility for DVI/DP System Requirements below are the minimum system requirements for your GN32DA monitor. The requirements are recommended in order to properly use all of the monitor’s features and ensure high-quality picture. -
Page 17: Section 13: One-Year Limited Hardware Warranty
Warranty services are provided by Viotek Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;... - Page 18 FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 20 COPYRIGHT © 2019 VIOTEK. ALL RIGHTS RESERVED.
