Summary of Contents for Viotek GN35DA
- Page 1 GN35DA CURVED GAMING MONIT USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. Ver 1.0 5/30/19...
-
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions..............4 Section 2: Box Contents .................5 Section 3: Product Overview ..............6 3.1 – Monitor Buttons ...............6 3.2 – Monitor Ports ................6 Section 4: Stand Installation ..............7 Section 5: Wall Mounting................8 Section 6: Connectivity Options ............9 6.1 –... -
Page 4: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter. -
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 NO. 1 Screw x 1 NO. 2 Screws x 2 NO. 3 Screws x 4 User Manual x 1 Power Cable x 1 DP Cable x 1 Screwdriver x 1 Cable Clip x 1 (AC 100-240V, 50/60Hz) -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off. -
Page 7: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. 2. Take out the cable clip, stand stem and stand base. Remove the foam covering the bottom of the monitor. -
Page 8: Section 5: Wall Mounting
Section 5: Wall Mounting This monitor ONLY includes screws which can be used for attaching the monitor to a mount. No mount or mounting accessory is included. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. -
Page 9: Section 6: Connectivity Options
Section 6: Connectivity Options 6.1 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an wall outlet. Power Cable 6.2 – Connecting Headphones Plug in your headphones, or any 3.5mm-compatible external audio device, to receive audio signals from your monitor. -
Page 10: Dp Connectivity
6.3 – DP Connectivity In order for the monitor to receive DP signals from the computer, use the DP cable to connect the monitor to the computer. DP Cable (included) DP OUTPUT 6.4 – HDMI Connectivity In order for the monitor to receive HDMI signals from the computer, use an HDMI cable to connect the monitor to the computer. -
Page 11: Section 7: Basic Operation
Section 7: Basic Operation Insert one end of the DP cable into your PC’s graphics card. Other connection types may be used. Additional cables not included. For optimal refresh rate (or “performance”), it is recommended to use a DP (display port) or DVI-D dual link cable with the monitor’s corresponding connector. -
Page 12: Section 9: Osd
Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s specifications. -
Page 13: Osd Menu Functions
9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description Input Source NONE Switch to DVI signal input HDMI NONE Switch to HDMI signal input NONE Switch to DP signal input Brightness/ Brightness 0~100 Adjust display brightness Contrast Contrast 0~100 Adjust display contrast Turn on DCR function Turn off DCR function... -
Page 14: Section 10: Eco Modes And Gameplus Switching
Main Menu Sub-Menu Options Description Multi-Window Multi-Window Off, PIP Mode, Select PIP/PBP modes according to the PBP 2Win number of input signals etc. Sub Win2 DVI, HDMI, DP Select according to input signal for PIP/ PBP mode Input PIP Size Adjust the PIP/PBP display window size Small, Medium, Large... -
Page 15: Section 11: Troubleshooting
• Press ) button to switch Gameplus modes. According to the needs of your game, choose the corresponding game icon. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios. •... -
Page 16: Pip (Picture In Picture) Input Information
• Make sure the power cable is properly connected to the monitor and power source. Cannot plug and play. • Check PC requirements to make sure it is compatible with the monitor. • Check graphics card requirements to make sure it is compatible with the monitor. Dim image •... -
Page 17: Section 12: Information
18 lbs / 8.13kg 12.2 – Resolution Compatibility for DVI/DP System Requirements below are the minimum system requirements for your GN35DA monitor. The requirements are recommended in order to properly use all of the monitor’s features and ensure high-quality picture. - Page 18 Warranty services are provided by Viotek Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;...
- Page 19 The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.
- Page 20 COPYRIGHT © 2019 VIOTEK. ALL RIGHTS RESERVED.
