In order to continue serving our customers and providing the best products, our product information
including our user manuals may receive updates from time to time. Please check our website for the
latest user manuals and product materials.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GN35LD and is the answer not in the manual?

Questions and answers

Summary of Contents for Viotek GN35LD

  • Page 1 GN35LD CURVED GAMING MONIT USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
  • Page 3: Table Of Contents

    Table of Contents Section 1: Safety Precautions ................4 Section 2: Box Contents ..................5 Section 3: Product Overview ................6 3.1 – Monitor Buttons ..................6 3.2 – Monitor Ports ..................6 Section 4: Stand Installation ................7 Section 5: Wall Mounting ..................9 Section 6: Connectivity Options ................10 6.1 –...
  • Page 4: Section 1: Safety Precautions

    VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter.
  • Page 5: Section 2: Box Contents

    Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 Cover Base x 1 (with Attached Bracket) NO. 3 Screws x 4 NO. 1 Screw x 1 NO. 2 Screws x 3 (for Wall Mounting) Cover x 1 Power Cable x 1 (AC 100-240V, 50/60Hz)
  • Page 6: Section 3: Product Overview

    Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off.
  • Page 7: Section 4: Stand Installation

    Section 4: Stand Installation Keep the foam over the monitor before attaching the stand. Follow the steps below to finish the installation. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Stand Stem Stand Base Foam...
  • Page 8 5. Align the stand stem’s bracket with the opening on the back of the monitor. Carefully insert the bracket into the opening, top first then bottom. The pieces should click into place. 6. Place the monitor on your desktop or table after completing the installation and carefully pull or push it up or down to adjust the height.
  • Page 9: Section 5: Wall Mounting

    Section 5: Wall Mounting Open the package, take out the product with foam still attached, and gently place it on a desktop or table. If the monitor was attached to the stand, remove the stand. Stand Stem Stand Base Foam Monitor Foam 2.
  • Page 10: Section 6: Connectivity Options

    Section 6: Connectivity Options 6.1 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an AC outlet. Power Cable 6.2 – Connecting Your Earphones When earphones are plugged in, no sound will be emitted from the speakers. Earphones (Not included) Listening to loud audio for prolonged periods of time may permanently damage your hearing.
  • Page 11: Dp Connectivity

    6.3 – DP Connectivity In order for the Monitor to receive DP signals from the computer, use the DP cable to connect the Monitor to the computer. DP Cable (Included) DP OUTPUT 6.4 – HDMI Connectivity In order for the Monitor to receive HDMI signals from the computer, use the HDMI cable to connect the Monitor to the computer.
  • Page 12: Section 7: Basic Operation

    Section 7: Basic Operation Insert one end of the DP cable into your PC’s graphics card. DVI or HDMI may also be used. These cables are not included. For optimal refresh rate (or “performance”), it is recommended to use a DP (display port) or DVI-D dual link cable with the Monitor’s corresponding connector.
  • Page 13: Section 9: Osd Setup

    Section 9: OSD Setup The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration and parts etc.
  • Page 14: Osd Menu Functions

    9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description Input Source NONE Select the DVI signals input HDMI NONE Select the HDMI signals input NONE Select the DP signals input Brightness/ Brightness 0~100 Adjust display brightness Contrast Contrast 0~100 Adjust display contrast Turn on DCR function Turn off DCR function...
  • Page 15 Main Menu Sub-Menu Options Description Audio Mute On, Off Turn the Mute mode on/off Volume 0-100 Set the audio volume Audio Source HDMI, DP Display the input signals from (HDMI or Multi-Window Multi-Window Off, PIP Mode, Select the corresponding combination of PBP 2Win PIP/PBP according to the number of input signal channel.
  • Page 16: Section 10: Led Effects System Console

    Section 10: LED Effects System Console Press any one of the buttons (M, , E, ) to activate the navigation window. 2. Press button to enter the LED Effects System Console menu. LED Effects System Console Colorful Color HighLight Strength Breath Mode 3.
  • Page 17: Section 11: Gameplus Adjustment

    Section 11: GAMEPLUS Adjustment Press any one of the buttons (M, , E, ) to activate the navigation window. 5. Press button to switch between Gameplus modes. According to the needs of your game, choose the corresponding game icon. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios.
  • Page 18 The monitor needs cleaning • Make sure the monitor has been powered off before cleaning. • Always use soft, non-abrasive cloth when cleaning. • Use dry, non-abrasive cloth to gently remove debris or dust. • If necessary, lightly dampen a non-abrasive cloth with water and gently clean the surface. •...
  • Page 19: Pip (Picture In Picture) Input Information

    12.1 – PIP (Picture in Picture) Input Information Mode Home Screen Picture in Picture Additional Input Interchange Picture Input Source Source Window Mode HDMI Mode 1 Mode 2 HDMI Mode 3 Note: ”O” means this feature is supported while “X” means it is not supported. 12.2 –...
  • Page 20: Section 13: Specifications

    20.57 lbs/29.56 lbs 13.1 – Resolution Compatibility for DVI/DP System Requirements below are the minimum system requirements for your GN35LD monitor. The requirements are recommended in order to properly use all of the monitor’s features and ensure high-quality picture. Minimum Requirements Operating System: Windows® 7 / Windows®...
  • Page 21: Section 14: 1 Year Limited Hardware Warranty

    Section 14: 1 Year Limited Hardware Warranty Your GN35LD Curved Gaming Monitor (”Product”) includes a One Year Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada only and is available only to original purchasers.
  • Page 22 DECLARATION OF CONFORMITY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 24 COPYRIGHT © 2017 VIOTEK. ALL RIGHTS RESERVED.
