- Page 1 GNV27DB2 GAMING MONITOR USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
-
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions ..........4 Section 2: Box Contents ............. 5 Section 3: Product Overview ..........6 3.1 – Monitor Buttons ............6 3.2 – Monitor Ports ............6 Section 4: Stand Installation ..........7 Section 5: Mount Installation ..........8 Section 6: Basic Operation .......... -
Page 4: Section 1: Safety Precautions
® VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter. -
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 NO.1 Screws x 4 NO. 2 Screws x 4 (for Stand Installation) (for Mounting) DP Cable x 1 Power Cable x 1 Screwdriver x 1 User Manual x 1 The screws come in different sizes: NO.1 (11mm x 4 pcs), NO.2 (35mm x 4 pcs). -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off. -
Page 7: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. 1. Open the package and take out the monitor with foam still attached. Gently place it top-down on a desktop or table. 2. Take out the stem and base. Use the included screwdriver and one screw to fasten base to the stem. -
Page 8: Section 5: Mount Installation
Section 5: Mount Installation 1. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. If the monitor is already attached to the stand, remove the stand. Button 2. Press the button to remove the adapter on back of monitor, then tighten the included four NO. -
Page 9: Section 6: Basic Operation
GPUs that use AMD® FreeSync™ or NVIDIA® G-Sync™. The feature is off on VIOTEK monitors by default and must be manually enabled in the monitor’s OSD (see Section 8: OSD). To use this feature, the connecting device must be compatible with adaptive sync (FreeSync and/or G-Sync);... -
Page 10: Section 8: Osd
Section 8: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M ( ) button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s standard configuration settings. -
Page 11: Osd Menu Functions
8.1 – OSD Menu Functions Main Menu Sub-Menu Options Description NONE Switch to DP signal input Input Source HDMI1, HDMI2, NONE Switch to HDMI signal input HDMI3 Brightness 0~100 Adjust display brightness Blacklevel 0~100 Adjust display blacklevel Brightness/ Contrast 0~100 Adjust display contrast Contrast Turn on DCR function... - Page 12 Main Menu Sub-Menu Options Description Multi-Window Multi-Window Off, PIP Mode, Select PIP/PBP modes according to the PBP 2Win number of input signals Sub Win2 Input DP, HDMI1, Select according to input signal for PIP/ HDMI2, HDMI3 PBP mode PIP Size Adjust the PIP/PBP display window size Small, Medium, Large...
-
Page 13: Section 9: Eco Modes And Gameplus
Section 9: ECO Modes and Gameplus Press any one of the buttons (M, , E, ) to activate the navigation window. ( ) to switch Gameplus modes. Choose the crosshair icon best suited for your 2. Press game. These game icons are primarily designed to optimize your aim during shooting games, though they can be used for other scenarios. - Page 14 The color bleeds or visual effects appear unusual. • If your screen is all red or blue, or any colors disappear, check to see that the cable is properly inserted. A loose connection can cause a bad signal. • Try connecting to another video source for comparison. Replace the connecting cable if needed.
-
Page 15: Section 11: Cleaning
Section 11: Cleaning The monitor needs cleaning. Take the following steps when cleaning. Do not press the monitor display with hands or other objects; otherwise, there is a risk of damaging the screen. 1. Power off the monitor and PC. 2. -
Page 16: Section 12: Specifications
Section 12: Specifications Item Detail Model Number GNV27DB2 Screen Size 27’’ Curvature 1500R Viewing Angle approx. 178° (H); 178° (V) 16:9 Aspect Ratio Resolution 2560 x 1440p Backlight E-LED Power on: Blue (solid); Power saving: Blue (flashing) LED Indicator Typical Brightness 300 cd/m (TYP);... -
Page 17: Section 13: Three-Year Limited Hardware Warranty
Section 13: Three-Year Limited Hardware Warranty ® Your VIOTEK GNV27DB2 Curved Monitor (”Product”) includes a Three-Year Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada only and is available only to original purchasers. - Page 18 THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY. DECLARATION OF CONFORMITY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 20 COPYRIGHT © 2021 VIOTEK. ALL RIGHTS RESERVED.
