- Page 1 GN32LD CURVED GAMING MONIT USER MANUAL...
- Page 3 Table of Contents Section 1: Safety Precautions..............4 Section 2: Box Contents .................5 Section 3: Product Overview ..............6 3.1 – Monitor Buttons .................6 3.2 – Monitor Ports ................6 Section 4: Stand Installation ..............7 Section 5: Wall Mounting................9 Section 6: Connectivity Options ............10 6.1 –...
-
Page 4: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter. -
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 Cover Base x 1 (with attached bracket) Cover x 1 NO. 1 Screw x 1 NO. 2 Screws x 3 NO. 3 Screws x 4 DP Cable x 1 (for Wall Mounting) Power Cable x 1... -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons Power Connector: Insert the Power Cable to supply power to the monitor. M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. -
Page 7: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam over the monitor before attaching the Stand. Follow the steps below to finish the installation. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Stand Stem Stand Base Foam... - Page 8 5. Align the Stand Stem’s bracket with the opening on the back of the monitor. Carefully insert the bracket into the opening, top first then bottom. The pieces should click into place. 6. Place the Monitor on your desktop or table after completing the installation and carefully pull or push it up or down to adjust the height.
-
Page 9: Section 5: Wall Mounting
Section 5: Wall Mounting Open the package, take out the product with foam still attached, and gently place it on a desktop or table. If the monitor was attached to the stand, remove the stand. Stand Stem Stand Base Foam Monitor Foam 2. -
Page 10: Section 6: Connectivity Options
Section 6: Connectivity Options 6.1 – Connecting the Power Cable • Connect the included Power Cable to the power connector, and then plug the other end into an AC outlet. Power Cable (Supplied) 6.2 – Connecting Your Earphones • When earphones are plugged in, no sound will be emitted from the speakers. Earphones (Not included) Listening to loud audio for prolonged periods of time may permanently damage your hearing. -
Page 11: Dp Connectivity
6.3 – DP Connectivity • In order for the Monitor to receive DP signals from the computer, use the DP cable to connect the Monitor to the computer. DP Cable (Included) DP OUTPUT 6.4 – HDMI Connectivity • In order for the Monitor to receive HDMI signals from the computer, use the HDMI cable to connect the Monitor to the computer. -
Page 12: Section 7: Basic Operation
Section 7: Basic Operation Insert one end of the DP cable into your PC’s graphics card. HDMI or DVI (display port) may also be used. These cables are not included. For optimal refresh rate (or “performance”), it is recommended to use a DP (display port) or DVI-D dual link cable with the Monitor’s corresponding connector. -
Page 13: Section 8: Indicator Light
Section 8: Indicator Light This light is located on the bottom of the Monitor. Bottom View Indicator Light Solid blue/green/white light indicates power is on and the monitor is operating normally. Flashing blue light indicates no video source has been detected. Red light indicates that no horizontal or vertical signal has been detected or power is low. -
Page 14: Section 9: Osd Setup
Section 9: OSD Setup The On-Screen Display (OSD) Menu may be used to adjust your Monitor’s settings and appears on screen after turning on the Monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration and parts etc. -
Page 15: Osd Menu Functions
9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description Input Source NONE Select the DVI signals input HDMI NONE Select the HDMI signals input NONE Select the DP signals input Brightness/ Brightness 0~100 Adjust display brightness Contrast Contrast 0~100 Adjust display contrast Turn on DCR function Turn off DCR function... - Page 16 Main Menu Sub-Menu Options Description Multi-Window Multi-Window Off, PIP Mode, Users can select the corresponding PBP 2Win combination of PIP/PBP according to the number of input signal channel. PIP Size Small, Medium, To adjust the PIP/PBP display window Large size PIP Position Top Right, Top To adjust the PIP/PBP window position...
-
Page 17: Section 10: Troubleshooting
Section 10: Troubleshooting The screen is blank • Be sure the Power Button has been pressed to turn the monitor on. • Confirm the brightness and contrast settings are set normally. • Check if the Indicator Light is flashing. If so, this indicates there is no signal from your video source. -
Page 18: Pip (Picture In Picture) Input Information
10.1 – PIP (Picture in Picture) Input Information Mode Home Screen Picture in Picture Additional Input Interchange Picture Input Source Source Window Mode HDMI Mode 1 Mode 2 HDMI Mode 3 Note: ”O” means this feature is supported while “X” means it is not supported. 10.2 –... -
Page 19: Section 11: Specifications
20.83 Ibs/13.92 Ibs 11.1 – Resolution Compatibility for DVI/DP System Requirements below are the minimum system requirements for your GN32LD monitor. The requirements are recommended in order to properly use all of the monitor’s features and ensure high-quality picture. Minimum Requirements Operating System: Windows® 7 / Windows®... -
Page 20: Section 12: 1 Year Limited Hardware Warranty
Section 12: 1 Year Limited Hardware Warranty Your GN32LD Curved Gaming Monitor (”Product”) includes a One Year Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada only and is available only to original purchasers. - Page 21 DECLARATION OF CONFORMITY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
