- Page 1 GN32DR CURVED GAMING MONIT USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. Ver 1.0 7/30/18...
-
Page 2: Table Of Contents
Table of Contents Section 1: Safety Precautions..............3 Section 2: Box Contents .................4 Section 3: Product Overview ..............5 3.1 – Monitor Buttons .................5 3.2 – Monitor Ports ................5 Section 4: Stand Installation ..............6 Section 5: Wall Mounting................8 Section 6: Connectivity Options ............9 6.1 –... -
Page 3: Section 1: Safety Precautions
VIOTEK shall not be held responsible for injury or damage of products or persons due to ®... -
Page 4: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 Cover Base x 1 (with Attached Bracket) Cover x 1 NO. 1 Screw x 1 NO. 2 Screws x 3 NO. 3 Screws x 4 DP Cable x 1 (for Wall Mounting) Power Cable x 1... -
Page 5: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons Power Connector: Insert the power cable to supply power to the monitor. M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. -
Page 6: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Stand Stem Stand Base Foam Monitor Foam 2. - Page 7 5. Align the stand stem’s bracket with the opening on the back of the monitor. With the top going in first, carefully insert the bracket. The pieces should click into place. 6. Place the monitor on your desktop or table after completing installation and carefully pull or push the screen up or down to adjust height.
-
Page 8: Section 5: Wall Mounting
Section 5: Wall Mounting This monitor ONLY includes screws which may be used when attaching the monitor to a mount. No mount or mounting accessory is included. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. -
Page 9: Section 6: Connectivity Options
Section 6: Connectivity Options 6.1 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an wall outlet. Power Cable 6.2 – Connecting Your Earphones Plug in your earphones to receive audio signals from your monitor. If your earphones are connected to the monitor and audio devices are connected to your computer at the same time, the audio devices will not produce sound. -
Page 10: Dp Connectivity
6.3 – DP Connectivity In order for the monitor to receive DP signals from the computer, use the DP cable to connect the monitor to the computer. DP Cable (Included) DP OUTPUT 6.4 – HDMI Connectivity In order for the monitor to receive HDMI signals from the computer, use an HDMI cable to connect the monitor to the computer. -
Page 11: Section 7: Basic Operation
Section 7: Basic Operation Insert one end of the DP cable into your PC’s graphics card. Other connection types may be used. Additional cables not included. For optimal refresh rate (or “performance”), it is recommended to use a DP (display port) or DVI-D dual link cable with the monitor’s corresponding connector. -
Page 12: Section 9: Osd
Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration and parts etc. -
Page 13: Osd Menu Functions
9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description NONE Switch to DVI signal input Input Source HDMI NONE Switch to HDMI signal input NONE Switch to DP signal input Brightness 0~100 Adjust display brightness Contrast 0~100 Adjust display contrast Brightness/ Turn on DCR function Contrast... -
Page 14: Section 10: Eco Modes And Gameplus Switching
Main Menu Sub-Menu Options Description Multi- Multi-Window Off, PIP Mode, Select PIP/PBP modes according to the Window PBP 2Win number of input signals etc. Sub Win2 Input DVI, HDMI, DP Select according to input signal for PIP/ PBP mode PIP Size Small, Medium, Adjust the PIP/PBP display window size Large... -
Page 15: Section 11: Troubleshooting
Section 11: Troubleshooting 11.1 – General Problems The screen is blank • Press the power button to turn the monitor on. • Confirm the brightness and contrast settings are set normally. • Check if the indicator light is flashing. If so, there is no signal from your video source. •... -
Page 16: Pip (Picture In Picture) Input Information
1440p @ resolution. 60Hz resolution. At this resolution, tearing and visual deformation should be minimized. Section 12: Information 12.1 – Specifications Item Detail Model Number GN32DR Screen Size 31.5’’ Curvature 1800R Viewing Angle 178° (H)/178° (V) Aspect Ratio 16:9... -
Page 17: Resolution Compatibility For Dvi/Dp
20.68 Ibs 12.2 – Resolution Compatibility for DVI/DP System Requirements below are the minimum system requirements for your GN32DR monitor. The requirements are recommended in order to properly use all of the monitor’s features and ensure high-quality picture. Minimum Requirements Operating System: Windows® 7 / Windows®... - Page 18 conditions. WP does not warrant uninterrupted or error-free operation of this Product. This Warranty does not cover any damage due to: (a) transportation; (b) storage; (c) improper use; (d) failure to follow the product instructions or to perform any preventive maintenance;...
- Page 20 COPYRIGHT © 2018 VIOTEK. ALL RIGHTS RESERVED.
