10.22.2 Set Pixel Shift and Parallax Direction

When pixel deviation occurs, images of mono cameras are vague and images of color cameras are
dispersive. If you find the image's edge has pixel deviation via observation, follow steps below to
alleviate it. Refer to the table below for effect contrast.
If the overall image has the phenomenon below, it may be caused by lens optical structure
deviation.
Camera Type
Mono Camera
GigE Line Scan Camera
Figure 10-48 Set Line Rate Ratio
Table 10-6 Effect Contrast
Normal Image
User Manual
·
Abnormal Image
