5 . Basic Monitoring
Is the PolaRx5 tracking satellites?
Select the 'GNSS' tab then
'Satellites and Signals'
In open sky, the PolaRx5
should track between 15
and 25 GPS and Glonass
satellites.
The Carrier-to-Noise plot
for GPS should show
about 3 satellites with an
L1CA above 50 dB-Hz
Is there any interference?
• Select the 'GNSS' tab then 'Spectrum'
• Click 'Show table' on the
Spectrum plot then select
GPS L2-P(Y). This frequency
band can be vulnerable to
interference.
The small GPS L2 signal at
1227.6 MHz should be visible.
Other spikes or anomalous
activity in the spectrum may
indicate interference.
For more information:
The memory stick delivered with the PolaRx5
contains the following documents:
PolaRx5 User Manual
PolaRx5 Firmware Manual
SBF Reference Guide
You can also consult our webpage or contact our
Support Department:
http://www.septentrio.com
support@septentrio.com
PolaRx5
Quick Start Guide
To set up the PolaRx5 you will need:
Power adapter
WiFi capable device
Antenna
Antenna cable
USB cable

Advertisement

loading
Need help?

Need help?

Do you have a question about the PolaRx5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SEPTENTRIO PolaRx5

  • Page 1 • Click 'Show table' on the Spectrum plot then select GPS L2-P(Y). This frequency band can be vulnerable to interference. To set up the PolaRx5 you will need: • The small GPS L2 signal at 1227.6 MHz should be visible. Other spikes or anomalous activity in the spectrum may indicate interference.
  • Page 2 Connect the power adapter to the ‘PWR’ socket on the PolaRx5 front panel • Plug the power adapter into the mains • Find the PolaRx5 WiFi • The PolaRx5 will start up automatically signal on your device and click: Connect • When connected, open a web browser using the IP 2.
