- Page 1 Wall-Mounted Sit-Stand Workstation | Single Monitor Mount | Keyboard Tray Actual product may vary from photos User Manual SKU#: WALLSTSI1 For the latest information and specifications visit www.startech.com/WALLSTSI1 Manual Revision: 05/30/2019...
-
Page 2: Compliance Statements
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual... -
Page 3: Warning Statements
Il prodotto è in grado di supportare i seguenti pesi: 20.5 kg. • Il prodotto è destinato all’uso in ambienti interni. Se ne sconsiglia l’impiego in ambienti esterni. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 4 • Dit product is alleen bedoeld voor binnengebruik en mag niet buiten worden gebruikt. 注意 • 必ず取扱説明書に従って本製品の組み立てを行って下さい。 • 本製品で定められた最大積載重量を超えないようにして下さい。 最大積載重量をオーバーした 場合、 怪我をする恐れや器物破損の恐れがあります。 本製品は、 モニター1台あたり20.5kgまで支 持できます。 • 本製品は、 室内での使用を想定しています。 戸外では使用しないで下さい。 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 5: Safety Statements
Säkerhetsåtgärder • Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så sätt att risk för snubblingsolyckor och andra olyckor kan undvikas. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 6: Table Of Contents
Attaching a Monitor ..........................22 Attaching the Monitor Mount ......................22 Adjusting the Monitor Tilt ........................25 Adjusting the Spring Arm Tension ...................... 25 Adjusting the Keyboard Tilt ........................27 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 7: Product Diagram
Product Diagram Monitor Mount Swivel Arm Spring Arm Keyboard Tray Wall-Mount Bracket Mouse Pad Aluminum Pole Mouse Holder Cable-Management Clip To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 8: Product Dimensions
Product Dimensions To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 9: Product Rotation
Product Rotation To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 10: Product Information
Product Information Specifications Type of measurement Measurement VESA mounting hole pattern 75x75 100x100 Tilt +900 to -150 Screen size Maximum 762 mm (30 in.) Rotate 3600 To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 11: Package Contents
Mouse Holder x 1 • Mouse Tray x 1 • Mouse Tray Fixed Plate x 1 • Hook-and-Loop Strip x 1 • Anti-Slip Rubber Strips x 2 • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 12: Requirements
User Manual x 1 • Requirements Phillips Head Screwdriver x 1 • Drill with Drill Bit x 1 • Writing Utensil x 1 • Level x 1 • To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 13: Installation
Remove the Decorative Cover from the bottom of the Aluminum Pole. The Decorative Cover will be located on the end of the Aluminum Pole that has the notch. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 14 Cable-Management Clip. Note: You do not need to hold the nut of the other side of the Cable-Management Clip while tightening or loosening the tension of the Cable-Management Clip. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 15 Swivel Arm. The Swivel Arm should be secure but free enough to rotate. Repeat steps 8 - 12 to install the other Cable-Management Clip and Swivel Arm w/ Logo at the desired height. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 16 Using two of the Wall Screws, mount the top Wall-Mount Bracket on the mounting surface. Secure the Aluminum Pole in place by tightening the Adjustment Knob on the Wall-Mount Bracket. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 17 Aluminum Pole. Make sure to align the notch on the Decorative Cover with the Bottom Lock Plate. Inserting the Decorative Cover To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 18: Attaching The Mouse Pad
Align the screw holes on the Mouse Tray Fixed Plate with the screw holes on the bottom of the Mouse Tray. Aligning the Mouse Tray Fixed Plate with the Mouse Tray To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 19: Attaching The Wrist Rest
Remove the backing from the Wrist Rest and while applying • pressure, attach it to the bottom of the Keyboard Tray (in the location your wrists would normally rest while typing on a keyboard). To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... -
Page 20: Attaching The Hook-And-Loop Strip
Keyboard, making sure to align the two strips. Attaching the Keyboard Tray Align the Mounting Hole on the third Swivel Arm with the Mounting Peg on the bottom Swivel Arm. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 21 Mounting Peg until it clicks in place. Attaching the Swivel Arm to the Mounting Peg Using the Hex Key (included), tighten the Hex Screw on the side of the Swivel Arm. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 22 Using the Hex Key, tighten the Hex Screw on the side of the Keyboard Tray next to the mounting hole. Do not over- tighten, to allow for keyboard swivel. Note: The Keyboard Tray supports up to a maximum 2.5 kg. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 23: Attaching A Monitor
The Monitor Mount supports up to a maximum of 9 kg. Align the Mounting Hole on the Spring Arm with the Mounting Peg on the top Swivel Arm. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 24 Slide the Mounting Hole on the Spring Arm over the Mounting Peg until it clicks into place. Attaching the Spring Arm To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
- Page 25 Using the Hex Keys, adjust the swivel tension of the Monitor Mount by loosening or tightening the Hex Screws located on the Monitor Mount next to the Mount Hole. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 26: Adjusting The Monitor Tilt
Using the large Hex Key, adjust the tension of the Spring • Arm by loosening or tightening the recessed Hex Screw located at the top of the Spring Arm next to the Mounting Peg. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 27 Adjust the tension of the Spring Arm until the Spring Arm is • capable of holding the weight of the attached Monitor at the desired height. Adjusting the Spring Arm Tension To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support...
-
Page 28: Adjusting The Keyboard Tilt
Keyboard but it is still adjustable. Adjusting the Keyboard Tray Tilt Note: The screw cap located on the opposite side of the Hex Screw is not used for tilt adjustments. To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support... - Page 29 Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
- Page 30 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
