USB-1408FS User's Guide

Non-volatile memory

EEPROM
EEPROM Configuration

Microcontroller

Type
Program memory
Data memory

Power

Parameter
Supply current (Note 10)
+5V USB power available
(Note 11)
Output current (Note 12)
This is the total current requirement for the USB-1408FS which includes up to 10 mA for the
Note 10:
status LED.
Self-powered hub refers to a USB hub with an external power supply. Self-powered hubs allow a
Note 11:
connected USB device to draw up to 500 mA.
Root port hubs reside in the PC's USB host controller. The USB port(s) on your PC are root port
hubs. All externally powered root port hubs (desktop PCs) provide up to 500 mA of current for a
USB device. Battery-powered root port hubs provide 100 mA or 500 mA, depending upon the
manufacturer. A laptop PC that is not connected to an external power adapter is an example of a
battery-powered root port hub.
Bus powered hubs receive power from a self-powered or root port hub. In this case the maximum
current available from the USB +5 V is 100 mA. The minimum USB +5 V voltage level can be
as low as 4.1 V.
Note 12: Output current refers to the total amount of current that can be sourced from the USB +5 V,
analog outputs and digital outputs.

General

Parameter
Device type
Device compatibility
Table 13. Non-volatile memory specifications
1,024 bytes
Address Range Access
0x000-0x1FF Read/write
0x200-0x3FF Read/write with unlock
Table 14. Microcontroller specifications
High performance 8-bit RISC microcontroller
16,384 words
2,048 bytes
Table 15. Power specifications
Conditions
Connected to self-powered hub
Connected to externally-powered root port hub
Connected to bus-powered hub
Connected to self-powered hub
Connected to externally-powered root port hub
Connected to bus-powered hub
Table 16. General specifications
Conditions
30
Description
512 bytes user area
512 bytes calibration data
Specification
80 mA
4.5 V min, 5.25 V max
4.1 V min, 5.25 V max
420 mA max
20 mA max
Specification
USB 2.0 full speed
USB 1.1, USB 2.0
Specifications
