USB-1608FS-Plus User's Guide

Power

Parameter
Supply current
Supply current
+5V power available (Note 2)
Output current (Note 3)
"Self-powered hub" refers to a USB hub with an external power supply. Self-powered hubs allow a
Note 2:
connected USB device to draw up to 500 mA. "Root port hubs" reside in the PC USB host Controller.
The USB port(s) on your PC are root port hubs. All externally-powered root port hubs, such as a
desktop PC, provide up to 500 mA of current for a USB device. Battery-powered root port hubs
provide 100 mA or 500 mA, depending upon the manufacturer. A laptop PC that is not connected to an
external power adapter is an example of a battery-powered root port hub. If your laptop PC is
constrained to the 100 mA maximum, you need to purchase a self-powered hub.
Output current is the total amount of current that can be sourced from the PC +5V, SYNC, and digital
Note 3:
outputs.

General

Parameter
Device type
Device compatibility

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Dimensions (L × W × H)
USB cable length
User connection length
Table 11. Power specifications
Condition
USB enumeration
Including DIO and SYNC output loading
Connected to externally-powered root port hub or a
self-powered hub
Table 12. General specifications
Specification
USB 2.0 (full-speed)
USB 1.1, USB 2.0
Table 13. Environmental specifications
Specification
0 °C to 70 °C
–40 °C to 70 °C
0% to 90% non-condensing
Table 14. Mechanical specifications
Specification
79 × 82 × 27 mm (3.10 × 3.20 × 1.05 in.)
3 m (9.84 ft) max
3 m (9.84 ft) max
21
Specifications
Specification
< 100 mA
< 500 mA
4.5 V min, 5.25 V max
200 mA max
