Operating, Maintenance & Parts Manual
Follow all instructions and warning for
inspecting, maintaining and operating
this hoist.
The use of any hoist presents some risk of personal injury or
property damage. That risk is greatly increased if proper
instructions and warnings are not followed. Before using this
hoist, each operator should become thoroughly familiar with all
warnings, instructions, and recommendations in this manual.
Retain this manual for future reference and use.
Forward this manual to the hoist operator.
Failure to operate the equipment as directed in the manual
may cause injury.
Before using the hoist, fill in the information below.
Refer to the hoist identification plate.
00001996 (REV AB)
Rated Loads 1/8 To 3 Tonnes
125 Kg To 3000 Kg
Model Number
Serial Number
Purchase Date
Voltage
Rated Load
®
627NH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LODESTAR NH and is the answer not in the manual?

Questions and answers

Related Manuals for CM LODESTAR NH

Summary of Contents for CM LODESTAR NH

  • Page 1 ® Operating, Maintenance & Parts Manual Rated Loads 1/8 To 3 Tonnes 125 Kg To 3000 Kg Follow all instructions and warning for inspecting, maintaining and operating this hoist. The use of any hoist presents some risk of personal injury or property damage.
  • Page 2 CM HOIST PARTS AND SERVICES ARE AVAILABLE IN THE UNITED STATES AND IN CANADA PARTS FOR YOUR HOIST ARE AVAILABLE FROM YOUR LOCAL AUTHORIZED REPAIR STATION. FOR THE NAME OF THE NEAREST PARTS OR SERVICE CENTER, VISIT OUR WEB SITE WWW.CMWORKS.COM...

  • Page 3: Safety Precautions

    Code for elevators, dumbwaiters, escalators and moving walks (ASME A17.1). Columbus McKinnon Corporation cannot be re- sponsible for applications other than those for which CM equipment is intended. *Copies of this standard can be obtained from ASME Order Department, 22 Law Drive, Box 2300, Fairfield, NJ 07007-2300, U.S.A.
  • Page 4 RNING CHOOSE THE RIGHT HOIST FOR THE JOB... RNING...

  • Page 5: Table Of Contents

    Specifications ......6-8 CM Repair/Replacement policy ..(Back Page)

  • Page 6: General Information

    Abuse, repair by an unauthorized person, or use of non-CM replace- ment parts voids the guarantee and could lead to dangerous operation. For full Terms of Sale, see Sales Order Acknowl- edgement.
  • Page 7 Table 1.b.Specifications, cont’d Lodestar Electric Chain Hoists Single Speed 230/460-3-60 or 220/380-3-50 or 220/415-3-50 Lifting Speed Lifting Speed Chain Weight Load Capacity per length of lift 60 Hz units 50Hz units Chain Size Model Chain Falls Tonne ft/min m/min ft/min m/min in x in mm x mm...
  • Page 8 Table 1.c. Specifications, cont’d Lodestar Electric Chain Hoists Two Speed 230-3-60 or 460-3-60 or 575-3-60 or 220-3-50 or 380-3-50 or 415-3-50 or 550-3-50 Lifting Speed Lifting Speed Chain Weight Load Capacity Chain Size 60Hz units 50Hz units per length of lift Chain Model Falls...

  • Page 9: Hook Suspensions

    Series 635 Low Headroom and Motor Driven Trolleys described next. ® Latchlok Hooks CM’s Latchlok hooks (see Figure 5) are available to replace the standard upper and lower hooks used on the Lodestar Electric Hoists. Figure 5. Upper or Lower Latchlok ®...

  • Page 10: Unpacking Information

    The dead end block should project through the bottom TO AVOID INJURY: Use only the CM supplied suspension screws to attach the of the hoist with the pin hole and slot aligned to the underside suspension to the hoist and hand torque these screws to of the hoist as shown in Figure 7.

  • Page 11: Recommended Torques

    Table 2.a. Recommended Torques: V1 Models A-H *Recommended Seating Torqu Fastener Fastener Description Tool Required ft-lbf Brake End 1/4-20 Slotted Fillister Slotted Blade 4.0 - 5.0 5.4 - 6.8 cover Head Screw Screw Driver 1/4-20 Slotted Fillister Slotted Blade Motor End 4.0 - 5.0 5.4 - 6.8 Screw Driver...

  • Page 12: Attaching Load Chain

    ATTACHING LOAD CHAIN INSTALLING THE SERIES 635 LOW HEADROOM TROLLEY (See Figure 9) To attach the chain to the dead end block on Models E, E-2, H, H-2, R, R-2 and RR-2, proceed as follows: W RNING 1. Suspend the hoist from an adequate support. Operating the trolley on a beam that has no rail stops may 2.

  • Page 13: Series 635 Trolley Side Frame Spacing

    Align the holes in the shackle and lug. Insert the lug If CM’s washer spacing recommendations are not followed, trolley pin in the aligned holes and secure the lug pin by driving the may fall from beam.

  • Page 14: Power Supply And Electrical Connections

    POWER SUPPLY AND ELECTRICAL CONNECTIONS The hoist should be connected to a branch circuit which complies with the requirements of the National Electrical Code and applicable local codes. It is recommended, especially for a single phase hoist with a (1) horsepower motor (.75 Kilowatts), that a line with adequate capacity be run directly from the power supply to the hoist to prevent problems with low voltage and circuit overloads.
  • Page 15 National Electrical Code 415-3-50 and applicable local codes as instructed in this manual 550-3-50 Remember, operation with low voltage can void the CM SIGNS OF INADEQUATE ELECTRICAL POWER repair/replacement policy. When in doubt about any of the (LOW VOLTAGE) ARE: electrical requirements, consult a qualified electrician.

  • Page 16: General

    “control cord alteration kit” (Part Number 28642) can be 2. WHEN APPLYING A LOAD, IT SHOULD BE DIRECTLY obtained from CM for shortening the length of the control cord. UNDER HOIST OR TROLLEY. AVOID OFF CENTER LOADING OF ANY KIND.

  • Page 17: Safety Procedures

    9. DO NOT load hoist beyond the rated capacity shown on ID plate. When in doubt, use the next larger capacity CM Lodestar Hoist. 10.Warn personnel of your intention to lift a load in the area. Tie off the load with auxiliary chains or cables before...

  • Page 18: Inspection

    INSPECTION To maintain continuous and satisfactory operation, a regular CAUTION: Any deficiencies found during inspections inspection procedure must be initiated to replace worn or are to be corrected before the hoist is returned to service. damaged parts before they become unsafe. Inspection Also, the external conditions may show the need for intervals must be determined by the individual application disasembly to permit a more detailed inspection, which,...

  • Page 19: Minimum Frequent Inspections

    Table 4. Minimum Frequent Inspections TYPE OF SERVICE ITEM Normal Heavy Severe a) Brake for evidence of slippage. b) Control functions for proper operation. c) Hooks for damage, cracks, twists, excessive throat opening, latch engagement and latch operation - see page 18. d) Load chain for adequate lubrication, as well as for signs of wear, damaged links or foreign matter - see page 20.

  • Page 20: Load Chain

    Use only CM supplied replacement load chain and parts.Chain beyond length indicated, nicked, gouged or twisted should and parts may look alike, but CM chain and parts are made of be replaced before returning hoist to service. Chain should specific material or processed to achieve specific properties.

  • Page 21: Load-Limiter

    • CM trackwheel bearings are pre-lubricated and require using the lubricants specified on page 85. If desired, these no lubrication. lubricants may be purchased from CM. Refer to page 85 for information on ordering the lubricants. EXTERIOR FINISH The gearbox is packed at assembly with grease and should...

  • Page 22: Adjustments Electric Brake

    BRAKE ADJUSTMENTS Connect the solid state reverse switch to a 115-1-60/230-1-60 light circuit as shown below. DC ELECTRIC BRAKE ASSEMBLY Close the switch to energize the 115-1-60/230-1-60 The correct air gap between field and armature is .008-.018 in power supply. The light bulb will illuminate if the (0.2-0.45 mm) for models A through H and .008-,020 in (0.2- solid state reverse switch is not damaged.

  • Page 23: Limit Switches

    2 feet and the bottom of the hoist. (61 cm), then raise the hook by jogging cautiously until the upper limit switch stops upward motion. The stopping C UTION: THE “ ” DIMENSIONS SHOWN IN T BLE 6 RE point of hook should be the desired upper position.
  • Page 24 12.Double check setting by lowering the hook about 2 feet (61 cm) and then run the hook into the upper limit with CONVERTING LIMIT SWITCH GUIDES (UP) control held depressed. 1. Disconnect the hoist from the power supply system. 2. Refer to the exploded views and remove the back frame .

  • Page 25: Troubleshooting

    TROUBLE SHOOTING ll Hoists Table 7. TROUBLE PROB BLE C USE CHECK ND REMEDY 1. Hook does not respond A.) No voltage at hoist-main line or branch A.) Close switch, replace fuse or reset to the control station or circuit switch open; branch line fuse breaker.
  • Page 26 Table 7 (cont.) TROUBLE PROB BLE C USE CHECK ND REMEDY A.) Open lowering circuit-open or shorted A.) Check electrical continuity and repair or 4.) Hook raises but will not winding in reversing contactor coil, loose replace defective part. Check operation of lower.
  • Page 27 Table 7 (cont.) Two Speed Hoist TROUBLE PROBABLE CAUSE CHECK AND REMEDY 11.) Hoist will not operate at A.) Open Circuit. A.) Open or shorted motor winding, loose or slow speed in either broken wire in circuit, speed selecting direction. contactor stuck in opposite speed mode.

  • Page 28: Electrical Data

    ELECTRIC L D T TO DETECT OPEN ND SHORT CIRCUITS IN ELECRIC L COMPONENTS Open circuits in the coils of electrical components may be detected by isolating the coil and checking for continuity with an ohmmeter or with the unit in series with a light or bell circuit. Shorted turns are indicated by a current draw substantially above normal (connect ammeter in series with suspected element and impose normal voltage) or D.C.
  • Page 29 Table 8. (cont. Volts- *D.C. Volts- *D.C. Full Load Full Load Phase H.P. Current Resistance Phase H.P. Current Resistance Models Models ( mps) ( mps) (kW) Leads Hertz (Ohms) Hertz (kW) Leads (Ohms) 1 - 2 110-1-50 11.6 1 - 2 3 - 4 ,B,E 110-1-50...

  • Page 73: Assembly Instructions

    Install load chain properly as indicated below. • DEAD END BLOCK USE ONLY CM ST R (#) GR DE LO D CH IN ND CM REPL CEMENT P RTS. USE OF OTHER CH IN ND P RTS M Y BE D NGEROUS ND VOIDS F CTORY W RR NTY.
  • Page 74 22. If the new chain is longer than the old, check to be sure limit switch will allow for new length of lift. In the event maximum adjustment does not allow entire length of lift, check with CM ® for modification if necessary.

  • Page 75: Cutting Chain

    Using “Commercial” or other manufacturer’s parts to repair the CM Lodestar Hoists may cause load loss. TO AVOID INJURY: Use only CM supplied replacement parts. Parts may look alike but CM parts are made of specific materials or processed to achieve specific properties.
  • Page 88 1.11 1.11 1.2.1 1.11 1.11 1.10 1.10 LUG ASSEMBLY 1.16 1.13 SWIVEL HOOK ASSEMBLY 1.12 1.15 1.14 1.17 1.11 1.2.1 1.11 1.11 2.10 1.10 RIGID HOOK ASSEMBLY TRIPLE REEVED LUG ASSEMBLY UPPER SUSPENSIONS...
  • Page 89 V1-SMALL FRAME V2-LARGE FRAME PART NUMBERS PART NUMBERS MODELS ITEM DESCRIPTION QTY. A, A-2, AA, MODELS MODELS MODELS MODELS AA-2, B, B- E, E-2, H, J, J-2, L, L- R, R-2, RT, RT-2, 2, C, C-2, F, 2, LL, LL-2 RR, RR-2 RRT, RRT-2 SWIVEL SUSPENSION ASSEMBLY - W/ LATCH TYPE...
  • Page 90 LOWER HOOK THRUST BEARING 88485 88485 LOWER HOOK NUT 982526 982526 LOWER HOOK NUT PIN 983772 983772 LOWER HOOK CHAIN BLOCK 28007 35026 LOWER HOOK CHAIN BLOCK PIN 45943 35790 * Contact CM for LatchLok part numbers LOWER HOOK BLOCKS SINGLE REEVED...
  • Page 91 982514 982445 HOOK BLOCK LABEL 00000766 00000766 HOOK BLOCK SCREWS WITH NUTS AND 1.10 C245 LOCKWASHERS (2 EACH) DEAD END SCREW WITH NUT AND LOCKWASHER C249 * Contact CM for LatchLok part numbers LOWER HOOK BLOCKS DOUBLE & TRIPLE REEVED...
  • Page 92 BACK FRAME w/ DRIVE SHAFT ASSEMBLED VIEW BRAKE ASSEMBLY BRAKE COIL HOIST MOTOR ITEM 1 VOLTAGE 00001400 110/115-1-50/60 103VDC 220/230-1-50/60 00001401 220/230-3-50/60 205VDC 380/415/480-3-50/60 00001402 550/575-3-50/60 255VDC ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE V1 LODESTAR SIZE 8 00001427 V1 LODESTAR, SIZE 8 ROTOR 00001430 V1 LODESTAR, SIZE 8 HUB...
  • Page 93 BACK FRAME w/ DRIVE SHAFT ASSEMBLED VIEW BRAKE ASSEMBLY ROTOR BRAKE COIL HOIST MODEL HOIST MOTOR ITEM1 ITEM 1.1 VOLTAGE 00001406 00001428 110/115-1-50/60 103VDC 220/230-1-50/60 J, J-2, L, L-2, 00001407 00001428 220/230-3-50/60 205VDC R, R-2, RT, RT-2 380/415/480-3-50/60 00001408 00001428 550/575-3-50/60 255VDC 220/230-3-50/60...
  • Page 94 BACK FRAME w/ DRIVE SHAFT ASSEMBLED VIEW BRAKE ASSEMBLY BRAKE COIL FRICTION INTERMEDIATE HOIST ITEM 1 ITEM 1.9 DISC PLATE MODEL ITEM 1.3 ITEM 1.7 115V COIL 230V COIL 460V COIL 575V COIL 115V 230V 460V 575V A, A-2, 27656 27659 28655 27658...
  • Page 95 BACK FRAME w/ DRIVE SHAFT ASSEMBLED VIEW BRAKE ASSEMBLY BRAKE COIL SPRING ITEM 1 ITEM 1.3 HOIST MODEL ITEM 1.7 115V COIL 230V COIL 460V COIL 575V COIL 115V 230V 460V 575V J, J-2, L, L-2, 35646 35647 35622 35649 51510 51511 51513...
  • Page 96 1.1.2 1.1.4 1.1.2 1.1.2 1.1.1 1.1.3 1.1.4 1.1.5 1.1.4 ITEM NO. PART NUMBER DESCRIPTION QTY. 29336 STATION ASSEMBLY AND CONTROL CORD FOR 10 FOOT LIFT 29336-15 STATION ASSEMBLY AND CONTROL CORD FOR 15 FOOT LIFT 29336-20 STATION ASSEMBLY AND CONTROL CORD FOR 20 FOOT LIFT 58272 2 BUTTON CONTROL STATION 1.1.1...
  • Page 97 1.1.2 1.1.2 1.1.4 1.1.2 1.1.3 1.1.1 1.1.4 1.1.5 1.1.4 ITEM NO. PART NUMBER DESCRIPTION QTY. 29348 STATION ASSEMBLY AND CONTROL CORD FOR 10 FOOT LIFT 29348-15 STATION ASSEMBLY AND CONTROL CORD FOR 15 FOOT LIFT 29348-20 STATION ASSEMBLY AND CONTROL CORD FOR 20 FOOT LIFT 58273 2 BUTTON CONTROL STATION 1.1.1...
  • Page 98 1.1.2 1.1.6 1.1.2 1.1.6 1.1.6 1.1.4 1.1.2 1.1.6 1.1.1 1.1.6 1.1.4 1.1.5 1.1.3 1.1.4 ITEM NO. PART NUMBER DESCRIPTION QTY. 51750 STATION ASSEMBLY AND CONTROL CORD FOR 20 FOOT LIFT 58220CM 4 BUTTON CONTROL STATION 1.1.1 58278 GROMMET 1.1.2 58279 HARDWARE KIT 58255 1-SPEED INSERT...
  • Page 120 1.20 1.11 1.21 1.15 1.16 1.17 1.14 1.18 1.19 1.24 1.10 1.23 1.22 1.13 1.12 ITEM NO. PART NUMBER DESCRIPTION QTY. 29917 CONTACTOR PLATE SUB-ASSEMBLY 31633 CONTACTOR PLATE 29312 DIN-RAIL 5.00" LONG 29014 TERMINAL STRIP 29015 TERMINAL STRIP END CLAMP 24799 REVERSING CONTACTOR 110V 982686...
  • Page 121 1.20 1.21 1.12 1.30 1.22 1.23 1.10 1.25 1.27 1.20 1.26 1.11 1.28 1.14 1.29 1.17 1.24 1.16 1.18 1.15 CONTACTOR REVERSING SECONDARY BKT S/A CONTACTOR VOLTAGE 00000484 28860 1.13 00000485 24797 1.19 ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE CONTACTOR PLT S/A 31633 CONTACTOR PLATE...
  • Page 122 1.21 1.26 1.24 1.23 1.20 1.19 1.18 1.21 1.15 1.22 1.27 1.14 1.28 1.29 1.25 1.30 1.10 1.31 1.17 1.11 1.13 1.16 1.10 00000487 28860 00000488 24797 1.12 00000489 24799 110V ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE CONTACTOR PLT S/A 31633 CONTACTOR PLATE 29015...
  • Page 123 1.16 1.14 1.11 1.20 1.19 1.18 1.17 1.15 1.12 1.10 CONTACTOR REVERSING SECONDARY BKT S/A CONTACTOR VOLTAGE 00000309 28860 1.13 00000310 24797 00000311 24799 110V ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE CONTACTOR PLT S/A 31633 CONTACTOR PLATE 29010 DIN-RAIL 6.50"...
  • Page 124 1.14 1.12 1.13 1.16 1.15 1.10 1.11 00000315 28860 00000316 24797 00000317 24799 110V ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE CONTACTOR PLT S/A 31633 CONTACTOR PLATE 29312 DIN-RAIL 5.00" LONG 29015 TERMINAL STRIP END CLAMP 29018 FUSIBLE TERMINAL STRIP 00000398 TERMINAL STRIP COVER SEGMENT SEE TABLE...
  • Page 125 1.20 1.14 1.17 1.16 1.15 1.10 1.11 1.19 1.18 1.13 1.12 00000318 28860 28878 00000319 24797 28871 00000320 24799 28870 110V ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE CONTACTOR PLT S/A 2-SPEED 31633 CONTACTOR PLATE 29010 DIN-RAIL 6.50" LONG 987873 LOCKWASHER #10 ASA MEDIUM 982686...
  • Page 126 ITEM NO. PART NUMBER DESCRIPTION QTY. 27419 CONTACTOR PLATE ASSEMBLY 31654 CONTACTOR PLATE 29312 DIN-RAIL 5.00" LONG 29014 TERMINAL STRIP 29015 TERMINAL STRIP END CLAMP 28553 REVERSING CONTACTOR 110V 982686 SCREW #10-32 UNF-2A X 3/8" SL 987873 LOCKWASHER #10 ASA MEDIUM 27910 CAPACITOR MOUNTING BRACKET 27716...
  • Page 127 1.15 1.16 1.17 1.19 1.18 1.12 1.20 1.11 1.14 1.21 1.13 1.10 ITEM NO. PART NUMBER DESCRIPTION QTY. 00000359 CONTACTOR BRACKET S/A 00000278 CONTACTOR BRACKET 35268 CLAMP 982873 MACHINE SCREW PAN HEAD 35279 START CAPACITOR 35285 RUN CAPACITOR INSULATOR 35278 CAPACITOR, RUN 20940 GROUND LABEL...
  • Page 128 1.24 1.13 1.15 1.10 1.12 1.11 1.19 1.18 1.17 1.14 1.25 1.26 1.16 1.23 1.27 1.22 1.28 1.21 1.29 1.30 1.31 1.32 CONTACTOR REVERSING TRANSFORMER SECONDARY BRACKET S/A CONTACTOR P/N VOLTAGE 00000357 24791 00000592 1.33 00000358 28906 00000593 1.20 ITEM NO. PART NUMBER DESCRIPTION QTY.
  • Page 129 1.24 1.10 1.11 1.12 1.18 1.19 1.17 1.15 1.14 1.25 1.13 1.26 1.23 1.27 1.28 1.16 1.29 1.21 1.30 1.31 1.32 1.22 1.33 CONTACTOR REVERSING TRANSFORMER SECONDARY BRACKET S/A CONTACTOR P/N VOLTAGE 1.34 00000360 24791 00000594 00000361 28906 00000595 00000362 28905 00000596 110V...
  • Page 130 1.21 1.10 1.11 1.13 1.20 1.12 1.15 1.14 1.16 1.17 1.19 1.18 CONTACTOR REVERSING SECONDARY TRANSFORMER BKT S/A CONTACTOR VOLTAGE 00000351 00000594 28860 00000352 00000595 24797 00000353 00000596 24799 110V ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE CONTACTOR BKT S/A 00000278 CONTACTOR BRACKET 29010...
  • Page 131 1.22 1.20 1.13 1.10 1.12 1.11 1.15 1.14 1.24 1.21 1.25 1.23 1.19 1.16 1.17 1.18 CONTACTOR REVERSING SPEED SECONDARY TRANSFORMER BKT S/A CONTACTOR SELECTOR VOLTAGE 00000369 00000594 28860 28878 00000370 00000595 24797 28871 00000371 00000596 24799 28870 110V ITEM NO. PART NUMBER DESCRIPTION QTY.
  • Page 132 1.24 1.23 1.13 1.10 1.12 1.11 1.14 1.15 1.22 1.21 1.20 1.19 1.16 1.17 1.18 SPEED CONTACTOR REVERSING SECONDARY TRANSFORMER SELECTING BKT S/A CONTACTOR VOLTAGE CONTACTOR 00000363 00000594 28860 28878 00000364 00000595 24797 28871 00000365 00000596 24799 28870 110V ITEM NO. PART NUMBER DESCRIPTION QTY.
  • Page 133 1.11 1.10 1.16 1.15 1.12 1.14 1.13 CONTRACTOR REVERSING SECONDARY TRANSFORMER BKT S/A CONTACTOR VOLTAGE 00000354 00000597 28860 00000355 00000598 24797 00000356 00000599 24799 110V ITEM NO. PART NUMBER DESCRIPTION QTY. SEE TABLE CONTACTOR BKT S/A 00000278 CONTACTOR BRACKET 29312 DIN-RAIL 5.00"...
  • Page 134 1.22 1.18 1.19 1.11 1.10 1.13 1.12 1.20 1.21 1.17 1.14 1.15 1.16 SPEED CONTACTOR REVERSING SECONDARY TRANSFORMER SELECTING BKT S/A CONTACTOR CONTACTOR CONTACTOR 00000337 00000597 28860 28878 00000338 00000598 24797 28871 00000339 00000599 24799 28870 110V ITEM NO. PART NUMBER DESCRIPTION QTY.
  • Page 135 1.10 1.11 1.12 1.13 1.21 1.22 1.28 1.27 1.14 1.15 1.16 1.17 1.18 1.26 1.19 1.24 1.20 1.25 1.23 1.30 1.29 ITEM NO. PART NUMBER DESCRIPTION QTY. 00000480 CONTACTOR BKT S/A 110V 00000278 CONTACTOR BRACKET 29015 TERMINAL STRIP END CLAMP 28905 REVERSING CONTACTOR 35278...
  • Page 136 LOAD BRACKET WIDTH PART NUMBER QTY. ITEM NO. DESCRIPTION 1 TON UNITS 2 TON UNITS 1 TON UNITS 2 TON UNITS 35774 50762 TRACK WHEEL 982520 948804 TRACK WHEEL STUD NUT SUSPENSION BOLT (SPECIAL ALLOY STEEL BOLT) 35450 *9 5/32" LONG 35407 **10 1/4"...
  • Page 137 LENGTH WIDTH ITEM NO. DESCRIPTION PART NUMBER QTY. SIDE FRAME-PLAIN SIDE (DOES NOT INCLUDE WHEELS) 4.00" THRU 5.63" FLANGE WIDTH 36696 5.63" THRU 7.25" FLANGE WIDTH 36629 FLANGE OVER 7.25" CONTACT FACTORY IF FRAME IS EQUIPPED WITH TROLLEY GUARDS CONTACT FACTORY TRACKWHEEL 39002 TRACKWHEEL BEARING...

  • Page 138: Lubricants

    Lower Hook *Oil obtain locally Thrust Bearing *These oils are not furnished by CM in Packaged Quantities. When ordering lubricants, specify the type of lubricant, part number and packages quantily required. Touch-up Paints for Lodestar Electric Chain Hoists: Hoist Order *(1) case (12-12 oz. Aerosol Cans) of Black Touch-up paints Part Number 84189.

  • Page 139: Notes

    NOTES...
  • Page 140 TO AVOID INJURY: • Do not alter or modify equipment. • Do use only CM replacement parts For the name of the nearest parts or service center, visit our website or call our customer service department.
