D8 PLUS - SQ P2 10:2018
ELECTRIC CHAIN HOIST
Before installing the D8 Plus hoist, fill in the information below.
Model Number
Serial No.
Purchase Date
Voltage
Rated Load
RATED LOADS 1/2 TO 2 TONNES
500 KG TO 2000 KG
WARNING
Follow the instructions and warnings of the
OPERATING, MAINTENANCE & PARTS manual
and all of the instructions contained in this
ADDENDUM in order to assemble, commission
and integrate the hoist.
The use of any D8 Plus hoist presents some risk
of personal injury or property damage, and that
risk is greatly increased if the proper commissioning
and integration instructions and warnings are
not followed.
Before using this D8 Plus hoist, each operator
should become thoroughly familiar with all warnings,
instructions and recommendations in this ADDENDUM.
Retain these instructions for future reference and use.
Forward these safety instructions to the operator.
Failure to operate the equipment as directed in
these safety instructions may cause injury.
SAFETY INSTRUCTIONS AND GUIDELINES
P/N: 192070212 (REV AA) December 2019
