Parts included:
• 6 Short drawer side panels (E)
• 3 Short drawer back panels (G)
• 3 Short drawer front panels (H)
• 3 Short drawer front face (I)
E
F
I

Shorter Drawers:

4. Fasten four (4) cam posts into the drawer side panels (E), insert cam locks into the drawer box front panel
(G)
box rear panel and then connect to one of the side panels. Please note that the drawer box side that has the pre-
drilled holes closer to one end should be mounted to the front panel.
5. Slide bottom panel (H)
finished side is facing up.
6. Connect and fasten the other side panel
7. Attach Drawer Front (I)
for hardware). Please note that on the three top drawers there is more space to the top than to the bottom. (A).

Tall Drawer:

8. Repeat step 5-7. Please note that on the bottom drawer there is more space from the pre-drilled holes to the bottom
than to the top.

Drawer Slide:

9. Separate male and female members by pushing down black pin (see image above), fasten female member into the pre
drilled holes on the sides of the drawer boxes keeping it flush to the front.
10. Install the male member on to the interior side panels using the pre-drilled holes on each side.
11. Gently slide the drawer boxes into the carcass until slides click into one another.
Assembly Instructions - Drawer Box
(D18, D24, and D30)
• 2 Short drawer side panels (E)
• 1 Short drawer back panels (G)
• 1 Short drawer front panels (H)
• 1 Short drawer front face (I)
H
into the opening of side panel (E), front panel (F), and drawer box rear panel
(E) to complete the drawer box construction.
to front panel of drawer box
www.modularclosets.com •
• 4 Drawer Slide (Set)
• 16 - 3/4" Screw
• 16 - 5/8" Screw
• 8 - 1" Screw
G
(F) using the outer pre-drilled holes (the 3 holes in the center are
Page 2 of 2
Tools required:
• Phillips screwdriver
Optional:
• Power screwdriver
• Mallet
E
(F)
(G) so that the
and drawer
