modway 6412 Manual page 3

MOD - 6412
STEP 2
2.1 Attach the Headboard Support Rail (D) to the Headboard (A) using hardware part
BOLT (3), SPRING WASHER (7), FLAT WASHER (8) & ALLEN KEY (15).
2.2 Loosen the pre-inserted bolt on the Headboard (A) & Footboard (E)
using hardware part ALLEN KEY (15).
STEP 2.1
15
3
7
8
15
STEP 2.2
15
3. JCBB BOLT M8 x 40mm x 2pcs
Customer Service 609-256-9000 www.modway.com
7. M8 SPRING WASHER x 2pcs
D
8. M8 FLAT WASHER x 2pcs
A
E
15. ALLEN KEY (BALL SHAPE) M5
03 of 09
