MOD - 6412
STEP 1
1.1 Attach the Headboard Leg (B) & Headboard Support Wood (C) to the Headboard (A)
using hardware part BOLT (3), BOLT (4), SPRING WASHER (7), FLAT WASHER (8) &
ALLEN KEY (15).
15
3
3
7
8
3. JCBB BOLT M8 x 40mm x 4pcs
15. ALLEN KEY (BALL SHAPE) M5
Customer Service 609-256-9000 www.modway.com
C
R
B
4
4
4. JCBB BOLT M8 x 45mm x 4pcs
L
B
A
7. M8 SPRING WASHER x 8pcs
A
C
8. M8 FLAT WASHER x 8pcs
02 of 09
