EEI -1324
DESK
Thank you for purchasing the MODWAY DESK！
Before you start, here is some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the desk, we recommend that it is assembled by two adults, on a carpeted or
padded area, in the room that it is intended for. Approximate assembly time: 45 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of small children.
Hardware:
a
c
e
g
j
m
Customer Service 908-368-1025︱www.modwayfurniture.com
Cam Post
x22
Screw M4x35mm
x4
Screw M4x14mm
x8
Bolt M6x30mm
x8
Bolt M6x65mm
x4
Leveler
x4
b
d
f
h
k
Cam
x22
Dowel
x20
Drawer Guides
x1 set
Bolt M6x35mm
x8
Allen Wrench x1
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for modway EEI -1324
Summary of Contents for modway EEI -1324
- Page 1 EEI -1324 DESK Thank you for purchasing the MODWAY DESK！ Before you start, here is some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. 2.Owing to the size and weight of the desk, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 EEI -1324 DESK Component: Side Panel Top Panel Center Divide Panel Side Divide Panel Drawer Front Bottom Panel Left Drawer Side Right Drawer Side Drawer Bottom Drawer Back Top Rail Bottom Rail Customer Service 908-368-1025︱www.modwayfurniture.com Page 2 of 7...
- Page 3 EEI -1324 DESK HOW TO USE CAN AND CAM POST HARDWARE Note cam arrow direction Turn cam clockwise 1/2 turn Note cam arrow direction STEP 1: Place 1pc Side Drawer Front (F1),1pc Side Drawer Back (F4),1pc Left Drawer Side (F3), 1pc Right Drawer Side (F4) and 1pc Side Drawer Bottom (F5) together as shown.
- Page 4 EEI -1324 DESK STEP 2: Insert 11pcs Cam Post (a) into the corresponding holes on the bottom of Top Panels (A) as shown. Use Phillips Head Screwdriver (not included) to tighten the Cam Posts (a) clockwise until secure. Insert 8pcs Dowel (d) into the corresponding holes on the bottom Top Panels (A) as shown.
- Page 5 EEI -1324 DESK STEP 4: Please put the Top Panel (A)) upside down on a carpeted or padded surface. Place the Left Side Panels (B) and Right Side Panel (C) to the Top Panel (A) as shown. Attach them by using 8pcs Cam (b).
- Page 6 EEI -1324 DESK STEP 6: Attach the Top Rail (H) and Bottom Rail (J) to 1pc Leg (G) by using 4pcs Bolt (h) as shown. Use Allen Wrench (n) to tighten all the Bolts (h) clockwise until secure. Repeat the same steps for the remaining other Leg (G).
- Page 7 EEI -1324 DESK STEP 8: Place the assembled drawer to the assembled desk as shown. Attach them by using 4pcs Screw (e). Use Phillips Head Screwdriver (not include) to tighten the Screws (e) clockwise until secure. Rotate the adjustable feet on bottom of each leg to desired height and leveling according to your floor surface.
