1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Blade set (5) Hanger bracket Canopy Canopy cover Downrod assembly Coupling cover Fan motor assembly Flywheel...
3. SAFETY RULES 1. To reduce the risk of electric shock, insure 7. For fans with manual reverse, do not electricity has been turned off at the circuit operate reversing switch while fan blades are in motion. Fan must be turned off and breaker or fuse box before beginning.
4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials.
5. HANGING THE FAN REMEMBER to turn off the power. Follow the CUL Listed steps below to hang your fan properly: electrial Step 1. Pass the 120-volt supply wires through Hanger Washers bracket the center hole in the ceiling hanger bracket as shown in Fig.
6. MAKE THE ELECTRIC CONNECTIONS WARNING: To avoid possible electrical Receiver shock, be sure electricity is turned off at the Hanger bracket main fuse box before wiring. Step 1. (Fig. 8) Insert the receiver into the hanger bracket with the flat side of the receiver facing the ceiling.
7. INSTALLATION OF SAFETY SUPPORT An additional safety cable is provided to prevent the fan from falling. Secure the safety cable to Hanger bracket Safety cable the ceiling joist with screw and washer, as illustrated in Figure 10. Figure 10 8.
9. ATTACHING THE FAN Blade screws BLADES Step 1. Remove the ten blade screws from Fan motor the fan motor assembly. (Fig. 12) assembly Step 2. Remove the ten flywheel screws from the flywheel. (Fig. 13) Figure 12 Step 3. Attach one of the five blades to the fan Flywheel screws motor assembly using two blade screws.
Page 9
10. ATTACHING THE LED LIGHT KIT NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. Wire connectors Step 1.
11. INSTALLING THE BATTERY Remove the back cover on the transmitter and install a 12V battery included with the remote control. (Fig. 18) 12. LEARNING PROCESS NOTE: After turning the AC power back on, do not press any other button on the remote control before pressing the button.
14. OPERATING YOUR TRANSMITTER Restore power to ceiling fan and test for proper operation. A. 1,2,3,4,5,6 buttons: These six buttons are used to set the fan speed as follows: 1 = low speed 2 = medium low speed 3 = medium speed 4 = medium high speed Figure 21 5 = high speed 6 = Extra high speed...
15. CARE OF YOUR FAN Here are some suggestions to help maintain your fan. 1. Because of the fan's natural movement some connections may become loose. Check the support connections, brackets and blade attachments twice a year. Make sure they are secure. (It is not necessary to remove fan from the ceiling).
16. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds noisy. 1.
