- Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION INSTRUCTIONS Model: AC-24344 Kendal Lighting (BC) Inc. #110, 6780 Dennett Place Delta, BC V4G 1N4 Canada Tel: (604) 952-5510 Fax: (604) 952-5513 CETL LISTED MODEL: BF947 Weight of Fan: 4.7 Kgs...
-
Page 2: Tools And Materials Required
1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Blade set (3) Hanger bracket Canopy Canopy cover Downrod assembly Coupling cover Fan motor assembly LED light kit... -
Page 3: Safety Rules
3. SAFETY RULES 7. For fans with manual reverse, do not 1. To reduce the risk of electric shock, insure electricity has been turned off at the circuit operate reversing switch while fan blades are in motion. Fan must be turned off and breaker or fuse box before beginning. -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. Use appropriate fasteners and building materials. -
Page 5: Hanging The Fan
5. HANGING THE FAN REMEMBER to turn off the power. Follow the CUL Listed steps below to hang your fan properly: electrial Step 1. Pass the 120-volt supply wires through Hanger Washers bracket the center hole in the ceiling hanger bracket as shown in Fig. -
Page 6: Make The Electric Connections
6. MAKE THE ELECTRIC CONNECTIONS WARNING: To avoid possible electrical Receiver shock, be sure electricity is turned off at the Hanger main fuse box before wiring. bracket Step 1. (Fig. 8) Insert the receiver into the hanger bracket with the flat side of the receiver facing the ceiling. -
Page 7: Installation Of Safety Support
7. INSTALLATION OF SAFETY SUPPORT An additional safety cable is provided to prevent the fan from falling. Secure the safety cable to Hanger bracket Safety cable the ceiling joist with screw and washer, as illustrated in Figure 10. Figure 10 8. -
Page 8: Attaching The Fan Blades
9. ATTACHING THE FAN BLADES Step 1. Remove the six blade screws from the fan motor assembly. (Fig. 12) Step 2. Attach the blade to the fan motor Fan motor assembly assembly using two blade screws. Attach the other blades to the fan motor assembly. (Fig. Blade screws Figure 12 Blade... -
Page 9: Installing The Battery
11. INSTALLING THE BATTERY Remove the back cover on the transmitter and install a 12V battery included with the remote control. (Fig. 15) 12. LEARNING PROCESS NOTE: After turning the AC power back on, do not press any other button on the remote control before pressing the button. -
Page 10: Operating Your Transmitter
14. OPERATING YOUR TRANSMITTER Restore power to ceiling fan and test for proper operation. A. 1,2,3,4,5,6 buttons: These six buttons are used to set the fan speed as follows: 1 = low speed 2 = medium low speed 3 = medium speed 4 = medium high speed Figure 18 5 = high speed 6 = Extra high speed... -
Page 11: Care Of Your Fan
15. CARE OF YOUR FAN Here are some suggestions to help maintain your fan. 1. Because of the fan's natural movement some connections may become loose. Check the support connections, brackets and blade attachments twice a year. Make sure they are secure. (It is not necessary to remove fan from the ceiling). -
Page 12: Troubleshooting
16. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds noisy. 1.
