As part of Parmco Appliances Ltd commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances. E&OE
Installation
and Operating
Instructions
TILTA MODELS:
T1-6-2L
T1-6HTL
T1-9HTL
727626042019
1
Advertisement
Table of Contents
Related Manuals for Parmco TILTA T1-6-2L
Summary of Contents for Parmco TILTA T1-6-2L
- Page 1 Operating Instructions TILTA MODELS: T1-6-2L T1-6HTL T1-9HTL As part of Parmco Appliances Ltd commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances. E&OE 727626042019...
-
Page 2: Warranty
• Normal or scheduled maintenance including blocked filters or ducting. Please retain this Warranty card together with receipt or other proof of purchase date when seeking service during the warranty period • Consumable items such as light bulbs. • Any damage to hobs caused by spills when cooking. • Any breakage or damage of glass items. • Any damage caused by non recommended product used for cleaning, Please contact Parmco at 09 573 5678 if your maintaining, lubricating or similar. appliance needs servicing under warranty. Please • Any aspect relating to the installation of the product, or damage caused have your model number and proof of purchase ready. during installation including blocked access for repair. Warranty repairs must be authorized by Parmco. • Any third party (including reseller) or consequential loss or damage (direct or indirect) however arising. Subject to updates without prior notice, please visit www.parmco.co.nz for E & O.E. 727626042019 the latest version. - Page 3 Parmco Appliances before any installation is carried out. We hope you enjoy your new appliance. If you would like to find out more about this product or any other products in Parmco’s extensive range, visit us on the web at www.parmco.co.nz. Regards,...
-
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION For best performance and to extend the life of your appliance we recommend that you read the instructions in this owners manual thoroughly before using your new appliance. It will provide you with all the information you need to ensure its safe installation, proper use and maintenance. -
Page 5: Installation
DO NOT use a steam cleaner to clean this appliance. Avoid improper or dangerous use of this appliance. Do not obstruct the ventilation or heat dissipation slots. This appliance is intended for indoor use only. Avoid exposing the appliance to atmospheric elements such as direct sunlight and rain. -
Page 6: Wall Fixing
Regulations concerning the discharge of air must be adhered to. Please refer to the relevant NZ standards. These hoods can be re-circulated using carbon filters available from Parmco Appliances. WALL FIXING ... - Page 7 Additional holes can be drilled through the rear of the unit to fix the unit to the packer if required. To adjust the bottom of the unit to the required depth use the screws located on the underside of the unit as per Fig 3 below. ...
- Page 8 Push the retaining lugs (F) up until the lugs can be removed. Remove the lugs and gently lift the door assembly (E) upwards and outwards simultaneously. To replace the door reverse this procedure ensuring that the lugs have been replaced and are seated correctly with the curved portion of the lug facing towards the outside of the unit.
- Page 9 Operating Instructions The Tilta units can have the fan speed and lighting preset so that it automatically operates when the front cover is extended out. The unit can also be operated manually once the front cover is extended out. The Tilta units will not operate when closed.
-
Page 10: Electrical Connection
minutes, then gently scrubbed to remove residues. Filters can be placed in the dishwasher when the detergent has a low caustic content. High caustic content dishwasher detergents may discolour the aluminium filters and result in premature failure of the aluminium mesh. Carbon Filters These filters contain activated carbon and cannot be cleaned. - Page 11 IMPORTANT: If the appliance is to be hardwired when making a fixed installation then a suitable cut-off device must be used to assure omnipolar disconnection of the mains. The cut off distance of the contacts must be at least 3mm. This appliance must be installed in full accordance with the Electrical Standards requirements of New Zealand.
- Page 12 3011000014100.03...
