Debug and Trace Configuration

STMicroelectronics STM32F446RE NUCLEO-64 Board

Enable ST-Link Debugger

Select Options for Target or press ALT+F7.
Go to the Debug tab and select the ST-Link Debugger.

Connect Using SWD

Click on the Settings button. On the Debug tab select the Port SW. This board
does not support JTAG.

Configure Trace using Serial Wire Viewer

Go to the Trace tab and enter the correct CPU Core Clock speed as specified in your project. Check the
Trace Enable box.
When debugging, the Status
bar shows information about
the Trace connection.
