- Page 1 ASSEMBLY INSTRUCTIONS Description : STORAGE CHEST 22 IN Item No. : TC-922 ITEM NO.: TC-922 Printed in Vietnam REVISED OCT 31, 2014 - 1 -...
- Page 2 Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your product. Protect the surface of the product with cloth if you are using any product with rubber feet or base. ASSEMBLY TOOLS REQUIRED NOT INCLUDED ITEM NO.: TC-922 Printed in Vietnam REVISED OCT 31, 2014 - 2 -...
- Page 3 Description Sketch Description Sketch Bolt Hinge (M6x30mm) Spring screw washer (M4x15mm) (Φ6.5x11mm) Flat washer Allen key (Φ6.5x13mm) (4x80mm) ITEM NO.: TC-922 Printed in Vietnam REVISED OCT 31, 2014 - 3 -...
- Page 4 Insert suppport bottom panel (C) into the unit all the way. Then attach Front panel (D) to the unit with Bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (6). ITEM NO.: TC-922 Printed in Vietnam...
- Page 5 Attach top (A) to the unit with screws (5), as shown below. Tighten with a screwdriver. STEP 4 Attach hinge (4) to the unit with screws (5) as shown below. ITEM NO.: TC-922 Printed in Vietnam REVISED OCT 31, 2014...
