- Page 1 ASSEMBLY INSTRUCTIONS Description : DOUBLE BUTTERFLY LEAF TABLE Item No : T-4268XBT AND T-4268XBB ITEM NO. : T-4268XBT AND T-4268XBB Printed in Vietnam REVISED FEB 04, 2015 THIS ITEM IS PACKED IN 2 CARTON - 1 -...
- Page 2 When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts: Description Sketch Description Sketch Pedestal Crossbar ITEM NO. : T-4268XBT AND T-4268XBB Printed in Vietnam REVISED FEB 04, 2015 THIS ITEM IS PACKED IN 2 CARTON - 2 -...
- Page 3 STEP 1 Attach crossbar (D) and legs (C) to pedestals (B) with nuts (1), and washers (2) and (3) as shown below. Tighten with the wrench (4). ITEM NO. : T-4268XBT AND T-4268XBB Printed in Vietnam REVISED FEB 04, 2015...
- Page 4 STEP 3 Place the plates on top of the pedestal (B), attach with washers (6) and (2) and nuts (3). Tighten with the Wrench (4) as shown below. ITEM NO. : T-4268XBT AND T-4268XBB Printed in Vietnam REVISED FEB 04, 2015...
- Page 5 Carefully put the pedestal block on the bottom side of the table top, attach the top to plate with bolts and washers (from step 2) and tighten with the Allen key (5). ITEM NO. : T-4268XBT AND T-4268XBB Printed in Vietnam...
- Page 6 Place the leaf in the center of the open table top. Push the table top closed. Lock the mechanism underneath 2 sides of the table top as shown below. ITEM NO. : T-4268XBT AND T-4268XBB Printed in Vietnam REVISED FEB 04, 2015...
