C
D
E
F
G
CADD
Ambulatory Infusion System with
Programmed Intermittent Bolus
Quick Reference Card for Clinicians
A.
Battery Compartment
B.
Display
C.
Indicator Lights
D.
USB Port
E.
Blue AC Power Light
F.
AC Power Jack
B
-Solis v 3.0
®
G.
H.
I.
J.
K.
A
Remote Dose Cord Jack
Keypad
Cassette Latch
Cassette/Keypad Lock
Power Switch
K
J
I
H
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Smiths Medical CADD Solis v 3.0
Summary of Contents for Smiths Medical CADD Solis v 3.0
- Page 1 CADD -Solis v 3.0 ® Ambulatory Infusion System with Programmed Intermittent Bolus Quick Reference Card for Clinicians Battery Compartment Remote Dose Cord Jack Display Keypad Indicator Lights Cassette Latch USB Port Cassette/Keypad Lock Blue AC Power Light Power Switch AC Power Jack...
- Page 2 Setting up the Pump for a New Patient Prepare the pump for a new patient Begin without the cassette attached to the pump. Insert four new 1.5 volt AA alkaline batteries or a rechargeable battery pack. Press the power switch to turn the pump on. Start New Patient Screen displays “Do you want to start a new patient?”...
- Page 3 Changing a patient’s current program while the pump is running With the pump running, all parameters can be changed except reservoir volume. Edit the program Scroll or to highlight the patient specific parameter you want to change. Press Select. Unlock the keypad using the security code or the pump key.
-
Page 4: Screen Saver
Changing a patient’s current program with the pump stopped Stop the pump Press Stop/Start. “Stop Pump?” displays. Press Yes. Edit the program Scroll or to highlight the patient specific parameter you want to change. Press Select. Unlock the keypad using the security code or the pump key. - Page 5 Resetting the reservoir volume without changing the tubing Changing the IV bag without changing the tubing. Stop the pump Press Stop/Start. “Stop Pump?” displays. Press Yes. Aseptically remove the empty IV bag from the tubing and attach the new IV bag. Reset reservoir volume Scroll ...
-
Page 6: Viewing Reports
Viewing reports Pump may be running or stopped to view reports. Pump reports should be cleared in accordance with institution policy. Option 1: From the home screen press Reports. Scroll or to the desired report and press Select. Press Back to return to the Reports menu, and then press Back again to return to the home screen. - Page 7 Alarms High Priority Alarm If the pump is running, it always stops when a high priority alarm is activated. Accompanied by a red screen, it continues until acknowledged or until the condition that triggered the alarm goes away. Medium Priority Alarm This alarm does not stop the pump.
-
Page 8: Troubleshooting
Troubleshooting Screen is blank and alarm is sounding. Alarm Priority High. The pump has lost power and is no longer delivering. The pump was delivering and the batteries were removed or the battery door was opened. Clear this alarm by replacing the batteries or closing the battery door, then turn the pump back on. - Page 9 Troubleshooting continued Downstream occlusion. Clear occlusion between pump and patient. Alarm Priority High. The pump has detected high pressure, which may be resulting from a downstream blockage, kink in the fluid path, or a closed tubing clamp. Delivery pauses and resumes if the occlusion is removed. Remove the obstruction or stop the pump to silence the alarm for 2 minutes, then remove the obstruction and restart the pump.
- Page 10 Find your local contact information at www.smiths-medical.com/customer-support/contact-us Smiths Medical is part of the global technology business Smiths Group plc. Please see the Instructions for Use/Operator’s Manual for a complete listing of the indications, contraindications, warnings and precautions. CADD and the Smiths Medical design mark are trademarks of Smiths Medical.
