Note: This only works with Fenix ARB-L18 Series battery.

Headband Assembly

Note: The headband is factory assembled by default.
1. Adjust the headband by sliding the buckle to the required length.
2. Assemble top headband to better fix the headlamp. First fix the headband mount to the
headband, then fix one side of the top headband to the headlamp holder, and the other end to
the top headband mount.

Usage and Maintenance

Disassembling the sealed head can cause damage to the lamp and will void the warranty.
l
Fenix recommends using an excellent quality Fenix battery.
l
If the lamp will not be used for an extended period, remove the battery, or the lamp could
l
be damaged by electrolyte leakage.
Take out the battery to prevent accidental activation during storage or transportation.
l
Long-term use can result in O-ring wear. To maintain a proper water seal, replace the ring
l
with an approved spare.
Periodic cleaning of the battery contacts improves the lamp's performance as dirty contacts
l
may cause the lamp to flicker, shine intermittently or even fail to illuminate for the following
reasons:
A: The battery needs replacing.
Solution: Replace the battery (Ensure battery is inserted according to the manufacturer's
specifications).
B: The contact point or contact of the battery or headlamp is dirty.
Solution: Clean the contact points with a cotton swab soaked in rubbing alcohol.
If the above methods don't work, please contact the distributor.

Included

Fenix HM60R Headlamp, Fenix ARB-L18-2600 Li-ion battery, USB Type-C charging cable, Spare
O-ring, User manual, Warranty card
