INSTALLATION
INSTRUCTIONS
FOR PX SERIES
REMOTE HYDRAULIC VALVE KIT
1. PACKING LIST & ACTUAL IMAGE
2. GENERAL SAFETY INFORMATION
3. INSTALLATION INSTRUCTION
D.D KIT 1 #. TG14-A0003E
KIT 2 #. TG14-A0004E
(DETENT)
KIT 3 #. TG14-A0005E
(DETENT FLOAT)
U.S.A KIT 1 #. PXA104
KIT 2 #. PXA105
(DETENT)
KIT 3 #. PXA106
(DETENT FLOAT)
Koerilenstraat 2, 3199LR, Maasvlakte-Rotterdam The Netherlands
SERVICE SUPPORT DIVISION / DAEDONG INDUSTRIAL Co.,Ltd.
35, Nongongjungang-ro 34-gil Nongong-eup, Dalseong-gun, Daegu, KOREA 42984
- 1 -
KIOTI TRACTOR DIVISION / DAEDONG-USA, Inc.
6300 Kioti Dr. Wendell, NC 27591
Toll Free:1877-GO-KIOTI
Tel:1-919-374-5100 Fax:1-919-374-5001
http://www.kioti.com
DAEDONG KIOTI EUROPE B.V
Tel:+31 (0)181 35 30 25
http://www.kioti.eu
Tel:82-53-610-3350 Fax:82-53-610-3359
http://www.daedong.co.kr
Printed in Korea. JUN.2019
