3.0 installation
EN
WARNING
!
•
Risk of fi re! The power cord must not be pinched against a sharp edge. Secure cord to avoid tripping or
snagging to reduce the risk of fi re, electric shock, or personal injury. Do not run cord under carpeting. Do not
cover cord with throw rugs, runners, or similar items. Arrange cord away from traffi c areas and where it will not
be tripped over.
•
Risk of fi re! To prevent a possible fi re, do not block air intake or exhaust in any manner. Do not use on soft
surfaces where openings may become blocked.
•
Risk of fi re! Do not blow or place insulation against the appliance.
•
This electric appliance is tested and listed for use only with the approved optional accessories. Use of optional
accessories not specifi cally tested for this electric appliance could void the warranty and/or result in a safety
hazard.
•
If the information in these instructions is not followed exactly, a fi re or explosion may result causing property
damage, personal injury, or death. Do not store or use gasoline or other fl ammable vapors in the vicinity of this
or any other appliance.
•
This appliance is heavy. It is highly recommended that two people install this appliance.
•
If your appliance is equipped with a heater, ensure the heater vents cannot, in any way, be covered as it may
create a fi re hazard.
•
Do not run the power cord horizontally, directly below the appliance.
Your NEFL42WM-1C is wall-mounted. Select a suitable location that is not susceptible to moisture and is away
from drapes, furniture and high traffic areas.
3.1
minimum clearance to combustibles
WARNING
!
•
When using paint or lacquer to finish a mantel, the paint or lacquer must be heat resistant to prevent
discoloration.
note:
The power switch is located on the top left hand side of the appliance. Ensure to maintain access to this switch
at all times.
Measurements are taken from the glass front.
Bottom
Sides
Back
Top
MANTEL
FLOOR
10
W415-3029 / A / 06.30.21
note:
Follow all national and local electrical codes.
2" (51mm)
6" (152mm)
0"
39" (1000mm) to ceiling
39" (1000mm) to mantel
39"
12"
(1000mm)
(305mm)
6"
REAR VIEW
(152mm)
2"
(51mm)
6"
(152mm)
Side View (Wall Mount)
42.5
Mantel
39"
(1000mm)
Floor
