WARNING
!
• Power supply service must be completed prior to finishing to avoid reconstruction.
• Heat vents and air openings cannot be covered in any circumstances.
5.1

front surround removal / installation

With one hand on the front surround to prevent it from falling, remove the two screws (1 per side) from the
A.
top of the appliance (Fig. 5-1). Set the screws aside.
Carefully lift the front surround up and away from the appliance (Fig. 5-2). Place it face down on a soft,
B.
non-abrasive surface.
Reverse these steps to install the front surround.
C.
5.2

crystal media installation

note:
The glass front / surround must be removed and the appliance must be mounted in its final location before
crystals are installed.
Clean crystal media: Crystal media may have a fine oil residue that
A.
needs to be cleaned prior to installation. Clean the crystal with mild
dish soap, drain, rinse thoroughly and dry before placing into the
tray.
Carefully place crystals into the bottom tray on the front of the
B.
appliance as illustrated. Apply an even layer from side to side. Re-
secure the glass panel.
5.3

LED back lights

Before operating appliance, ensure to plug in LED back lights as below.
Repeat on
opposite side.
Fig. 5-1

5.0 finishing

Fig. 5-2
