Operating Instructions; Operating Control Panel And Remote Control - Napoleon NEFL42WM-1C Installation And Operation Manual

Once the appliance has been plugged into a grounded electrical outlet, it is ready to operate.
7.1

operating control panel and remote control

Remote Control
note:
The timer indicator on the control panel will light up to the corresponding
setting. It will have a series of different combinations to show which setting is
on. For example, the 3.5h setting will have 1/2, 1, and 2 light on to indicate it
is a total of 3.5h.
Power
Timer
Flame Control
(The flames stay on until power
is turned off. Flame must be on
for the heater to turn on).
Heater Control
(Flame must be on for the heater
to turn on).
Back Lights
Control
note:
This remote control must remain within 26 feet (8 meters) of the appliance to be effective. This range may be
reduced as the battery power is depleted.
Control Panel
Power Flame Control
Timer Back Light
Turns the appliance on / off.
Controls the timer.
The timer can be programmed to run the appliance for
specific lengths of time (30 mins. minimum to 7.5 hrs.
maximum).
Controls the height and brightness of the flame.
Turns the heater and blower on / off.
2 Settings: Low Heat and High Heat.
The heater will blow cool air for 10 seconds after
it turns off. This prevents the appliance from
overheating.
Controls LED back lights.
10 Settings: Orange, red, blue, yellow, green, purple,
azure, carmine, white, pink.
NOTE: The appliance will auto-cycle through colours
after pressing the button 11 times. It will be locked
after pressing the button 12 times, and the back lights
will be turned off after pressing the button 13 times.

7.0 operating instructions

Indicator
Heater
EN
Side View
NAPOLEON
Remote
Control
15
W415-3029 / A / 06.30.21
