88 5134 30
Concrete Chie
Dining Table
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
Hardware List
Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
A.
Table Top
1 Pc.
B.
Leg
4 Pcs.
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
Head Cap Bolt
8 Pcs. (+1 extra)
Wood Screw
5 Pcs. (+1 extra)
Tools recommended for assembly : Level
C.
Stretcher
1 Pc.
D.
Stretcher
1 Pc.
Spring Washer
8 Pcs. (+1 extra)
Flat Washer
8 Pcs. (+1 extra)
