IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
G.
Top
1 pc.
I.
Shelf
4 pcs.
J.
Back Rail
4 pcs.
O.
Top
1 pc.
Hardware List
Cam Lock
28 pcs.(+6 extra)
Cam Lock Screw
28 pcs.(+2 extra)
Carton 20 05523 0691 is also needed for assembly.
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8" Drill Bit
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
20 05523 0692
Pantry
K.
Upright
1 pc.
Adjustable Pin
16 pcs. (+1 extra)
M3x15
Wood Screw
28 pcs. (+1 extra)
L.
M.
Back Panel
Upright
2 pcs.
1 pc.
Bracket
2 pcs.
Magnet
4 pcs.
888-680-7460, 877-831-0319
H.
Bottom
1 pc.
N.
Back Panel
2 pcs.
P.
Bottom
1 pc.
M4x45
Machine Screw
4 pcs.
Knob
4 pcs.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Homestyles 20 05523 0692
Summary of Contents for Homestyles 20 05523 0692
- Page 1 4 pcs. 28 pcs. (+1 extra) 4 pcs. Carton 20 05523 0691 is also needed for assembly. Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8” Drill Bit Home Styles Customer Service: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 Assembly Instructions 2/6 IMPORTANT Ÿ Use a soft cloth between these parts and the floor. Ÿ Do not use power tools above 8 volts to assemble. Ÿ Do not tighten all the screws until each part is properly assembled. Ÿ The unit must be level to work properly.
- Page 3 Assembly Instructions 3/6 STEP 3 Attach Upright (K) to Back Rail (J). Slide Back Panels (L) into position. Attach Back Rail (J) to unit. Attach Side Panels (C) and (D) to unit with Cam Locks. (See Figure 3) Attach Bottom (H) to unit with Cam Locks.
- Page 4 Assembly Instructions 4/6 STEP 5 Attach Upright (M) to Back Rail (J). Slide Back Panels (N) into position. Attach Back Rail (J) to unit. Attach Side Panels (E) and (F) to unit with Cam Locks. Attach Bottom (P) to unit with Cam Locks. Cam Lock Cam Lock STEP 6...
- Page 5 Assembly Instructions 5/6 STEP 7 Place top unit onto base unit. Insert Adjustable Pins into side panels at desired level. Place Shelves (I) into position. Figure 6 Figure 7 Adjustable Pin Wood Screw Bracket STEP 8 Attach Brackets to unit with Wood Screws. (See Figure 6 ) Level unit by adjusting the adjustable levelers on bottom of unit.
-
Page 6: Hardware List
Assembly Instructions /6 IMPORTANT Ÿ To help reduce the risk of the unit tipping over, the Tip-over Restraint must be installed following these instructions exactly. STEP 9 Anchor in wall Wall Screw Pre-drilled hole Bracket Place unit at desired location. on wall at top of unit 3/8”... - Page 7 Home Styles is under no obligation to provide replacement parts. Parts are not available for fully assembled items nor are parts available for sale. Replacements for missing or damaged hardware or parts may be requested at: www.homestyles-furniture.com/customer-service/replacement-parts Home Styles Customer Service: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
