nanoPARADE B
Code
Power consumption
Electrical class
Weight
Operating temperature
Startup temperature
IP rating
IK rating
Size
Nano Parade B 1
Nano Parade B 2
Nano Parade B 3
Nano Parade B 4
Griven S.r.l. - Via Bulgaria, 16
46042 Castel Goffredo
Mantova - Italy
User's Manual
Rev. 1.00
Date: 02/12/2021
Nano Parade B 1
AL8301
0.18A @ 24V / 4.5W
0.2 Kg / 0.44 lb
320 mm
[12.5"]
620 mm
[24.4"]
920 mm
[36.2"]
1220 mm
[48"]
Tel. +39.0376.779483
© Copyright Griven 2017 - Griven reserves the right to make
changes to this product and related instructions at any time
E-mail: sales@griven.com
without prior notice and such changes shall be effective
Web: www.griven.com
immediatly
Nano Parade B 2
AL8303
0.35A @ 24V / 8.5W
III
0.4 Kg / 0.88 lb
-20°C to 50°C / (-4°F to 122°F)
-20°C to 50°C / (-4°F to 122°F)
IP67
IK10
.
551159
Nano Parade B 3
AL8305
0.51A @ 24V / 12.5W
0.6 Kg / 1.32 lb
Nano Parade B 4
AL8307
0.69A @ 24V / 16.5W
0.8 Kg / 1.76 lb
30 mm
[1.18"]
