- Page 1 GNV30CB In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. ver.1.0 5/20/19...
-
Page 3: Table Of Contents
Table of Contents Section 1: Safety Precautions ............. 4 Section 2: Box Contents .............. 5 Section 3: Product Overview ............6 3.1 – Monitor Buttons ............... 6 3.2 – Monitor Ports ..............6 Section 4: Stand Installation ............7 Section 5: Mount Installation ............8 Section 6: Connectivity Options .......... -
Page 4: Section 1: Safety Precautions
VIOTEK ® shall not be held responsible for injury or damage of products or persons due to failure to adhere to the aforementioned precautions or any others noted hereafter. -
Page 5: Section 2: Box Contents
Section 2: Box Contents Monitor x 1 Stand Stem x 1 Stand Base x 1 Screws x 4 (for Stand Installation) Cable Clip VESA Adapter x 1 DP Cable x 1 Power Adapter x 1 (DC 12V, 4.0A) Screwdriver x 1 User Manual x 1 Extra screws may be included as backup. -
Page 6: Section 3: Product Overview
Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Down Button: Press to move down in the menus. Up Button: Press to move up in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off. -
Page 7: Section 4: Stand Installation
Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. 1. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Next, take out the stem, cable clip, and base, use the included screwdriver and two screws to fasten base to the stem. -
Page 8: Section 5: Mount Installation
Section 5: Mount Installation 1. Open the package, take out the product with foam still attached, and gently place it on a desktop or table. Remove the extra parts and the foam covering the bottom of the monitor. If the monitor is already attached to the stand, remove it. 3. -
Page 9: Section 6: Connectivity Options
Section 6: Connectivity Options 6.1 – Connecting Your Earphones Plug in your earphones to receive audio signals from your monitor. If your earphones are connected to the monitor and audio devices are connected to your computer at the same time, the audio devices will not produce sound. Earphones and other audio devices not included. -
Page 10: Connecting The Power Cable
6.3 – Connecting the Power Cable Connect the included power cable to the power connector, and then plug the other end into an wall outlet. Power Cable 6.4 – HDMI Connectivity In order for the monitor to receive HDMI signals from the computer, use an HDMI cable to connect the monitor to the computer. -
Page 11: Section 7: Basic Operation
Section 7: Basic Operation 1. Insert one end of the DP cable into your PC’s graphics card. An HDMI cable may also be used. HDMI cable is not included. 2. Connect the other end of the cable to the corresponding connector on your monitor. -
Page 12: Section 9: Osd
Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration and parts etc. -
Page 13: Osd Menu Functions
9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description NONE Switch to DP signal input Input HDMI-1 2.0 Source NONE Switch to HDMI signal input HDMI-2 1.4 Brightness 0~100 Adjust display brightness Contrast 0~100 Adjust display contrast Brightness/ Turn on DCR function Contrast Turn off DCR function Gamma 2.0... -
Page 14: Section 10: Rgb, Led Effects And Gameplus
Main Menu Sub-Menu Options Description Multi- Multi-Window Off, PIP Mode, Select PIP/PBP modes according to the Window PBP 2Win number of input signals etc. Sub Win2 Input DP, HDMI-1, Select according to input signal for PIP/ HDMI-2 PBP mode PIP Size Adjust the PIP/PBP display window size Small, Medium, Large... -
Page 15: Section 11: Troubleshooting
Section 11: Troubleshooting The screen is blank • Press the power button to turn the monitor on. • Confirm the brightness and contrast settings are set normally. • Check if the indicator light is flashing. If so, this indicates there is no signal from your video source. -
Page 16: Section 12: Specifications
• Please adjust Clock or Auto settings. Color difference (colors are not optimized) • Adjust RGB color or reset color temperature settings. Section 12: Specifications Item Detail Model Number GNV30CB Screen Size 29.5” Curvature 1800R ≥170°(H); ≥176°(V) Viewing Angle Aspect Ratio... -
Page 17: Section 13: 1 Year Limited Hardware Warranty
Section 13: 1 Year Limited Hardware Warranty ® Your VIOTEK GNV30CB Curved Monitor (”Product”) includes a One Year Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada only and is available only to original purchasers. - Page 18 SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY.
