PART & DESCRIPTIONS*
1
Lens
Power Input Connctor
2
12VDC/24VAC Dual Voltage
UTP
3
4
RS-485
Primary Video BNC-Output Connector
5
Bubble Dome Cover
6
Upper Case
7
Camera Control Board
8
Secondary Video-BNC
9
Output Connector
Mounting Screws
10
5
9
1
10
7
6
2
3
4
8
NO IR
IR
5
