PART & DESCRIPTIONS*
3
7
w/o IR
1
8
5
4
2
Lens
1
Power input Connctor
2
12VDC Voltage
BNC (HD-SDI) + RS485
3
Bubble Dome
4
Upper Case
5
6
Camera Control Board
6
2nd Video Connector
7
Mounting Screws
8
IR
5
