CONNECTING TO MONITORS*
Use the diagram below to connect the camera to a Monitor or CRT Monitor.
DC 12V / AC 24V
CCTV Monitor
IR
NO IR
Second Video Output
Monitor
300.0mm(11.8")
Power Connection: 12VDC & 24VDC Dual Voltage (Auto Polarity Detection and Protection)
All cameras are equipped with a second video output for on-site configuration.
