Digital Watchdog Snapit DWC-HD421D Manual page 22

5 IMAGE
CHROMA
SHARPNESS 5
MIRROR OFF
FLIP OFF
E-Edge OFF
HLMASK OFF
CONTRAST NORMAL
COLOR SET COLOR1
HUE CONTROL
RETURN
E-Edge
ON/OFF Edge enhancement. If enabled, edges and fine lines will appear sharper in the image.
HLMASK
OFF High Lux Masking masks ares in the image that
are overly exposed to light.
ON If ON is selected, you can adjust the masking level
and color. adjust the level from 0 (only areas with a
lot of light will be masked)~10.
You can also modify the mask's color from the available
8 options - BLK, WHT, YEL, CYN, GRN, MAG, RED,
and BLU
RETURN
22
CHROMA
0~20
7
SHARPNESS
0~10
MIRROR
ON/OFF
FLIP
ON/OFF
Chroma sets the quality of the color that embraces both
hue and saturation. White, black and grays have 0 chroma.
The higher numbers accentuate the brighter colors in the
image. Default is 7.
Sets the image's sharpness. The higher the number,
the sharper lines and details will appear in the image.
However, the sharper the image, the more digital
noise will be visible.
Flips the image horizontally. OFF is the default.
Flips the image vertically. OFF is the default.
HLMASK
LEVEL 10
COLOR BLK
RETURN
