Black Electric Dual Motor Desk Frame
Instruction Manual
SKU: DESK-V122EB
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v122eb
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-V122EB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vivo DESK-V122EB

Summary of Contents for Vivo DESK-V122EB

  • Page 1 Black Electric Dual Motor Desk Frame Instruction Manual SKU: DESK-V122EB Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v122eb GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...

  • Page 2: Electrical Safety Instructions

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.

  • Page 3: Tools Needed

    TOOLS NEEDED Phillips Screwdriver Drill ASSEMBLY STEPS STEP 1 Attach Left Crossbar (A) and Right Crossbar (B) to Legs (D) using M6x12 Flat Head Screws (S-A) and 4mm Allen Wrench (T-A). B S-A...
  • Page 4 STEP 2 Secure Side Brackets (F) using M6x12 Flat Head Screws (S-A) and 4mm Allen Wrench (T-A). STEP 3 Insert Rubber Pads (H) into desktop mounting holes in Left Crossbar (A), Right Crossbar (B), and Side Brackets (F).
  • Page 5 STEP 4 Flip leg assemblies upside down and place the Feet (C) on Legs (D) as shown. Insert and tighten M6x35 Screws (S-B) using 4mm Allen Wrench (T-A). Screw Foot Pads (E) into Feet (C). STEP 5 Insert Crossbar (G) into Left Crossbar (A) and Right Crossbar (B). Adjust the desk frame assembly to the desired length and then insert M6x12 Screws (S-C) into Left Crossbar (A) and Right Crossbar (B).
  • Page 6 STEP 6 Place the assembled frame upside down on the tabletop. Adjust width as needed, and drill 10mm deep pilot holes using a 1/8” (3mm) drill bit. Secure the frame to the tabletop using M5x16 Screws (S-D). Tighten with a Phillips screwdriver. STEP 7 Place Control Panel (I) at the desired location, making sure the cables from one Leg (D) and Extension Cable (J) are able to reach the Control Panel (I), and mark drilling locations.
  • Page 7 STEP 8 Turn the desk right side up and plug AC Adapter (K) into an AC power outlet. Manage cables using Cable Clips (L). Adjust Foot Pads (E) to sit level if necessary. Refer to Controller User Guide for operational instructions.
  • Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
