Outdoor 8x5W eNodeB
Quick Guide
P/N: 1701000180
Document version: 01
All rights reserved © Baicells Technologies Co., Ltd.

Advertisement

Table of Contents
loading

Summary of Contents for Baicells Nova846

  • Page 1 Nova846 Outdoor 8x5W eNodeB Quick Guide P/N: 1701000180 Document version: 01 All rights reserved © Baicells Technologies Co., Ltd.
  • Page 2: Product Overview

    20 MHz bandwidth. Using a Nova846 in DC mode simplifies and streamlines the deployment of split sectors. In addition to having the option to operate Nova846 in either CA or DC mode, HaloB (an embedded MME option) comes as a default feature in the base software.
  • Page 3  Integration as required, easy to installation and deployment, accurate coverage and improved network capacity. Appearance The appearance of Nova846 is shown in Figure 1-1. Figure 1-1 Nova846 Appearance The interfaces and indicators Nova846 are shown in Figure 1-2.
  • Page 4 Power interface: -48V (-40.5V to 57V) DC ANT0~ANT7 Connect to external antenna 0 to antenna 7, N-type connector. CAL/GPS CAL is used for antenna phase alignment. GPS is used to connect to external GPS antenna, N-type connector. The Nova846 interface indicators are described in Table 1-2.
  • Page 5: Technical Specification

    Table 1-2 Nova846 Interface Indicators Identity Color Status Description Steady On Power on Green No power supply No alarm Steady On The system exists alarms. Steady On The device has been powered on. Fast flash: 0.125s Green Data is transmitting.
  • Page 6: Software Specification

    Item Description ≤ 300W Power consumption Power +40.5V to 57 V DC, Nominal +54VDC Weight 11.0kgs RSSI , VSWR, TSSI(transmission signal strength), Basic report function temperature, etc. Cooling Method Natural convection cooling @ vertical installation Room temperature: <2.5 Noise Figure All temperature: <3.5 ≥...
  • Page 7: Environment Specification

    Item Description DL: QPSK, 16QAM, 64QAM, 256QAM* Voice Solution VoLTE, Circuit Switched Fallback (CSFB)* Traffic Offload Local breakout Self-organizing network:  Automatic setup  Automatic Neighbor Relation (ANR)  PCI confliction detection RAN Sharing Multi-Operator Core Network (MOCN)* HaloB Supported Network Mgmt TR-069 Support remote/local maintenance...
  • Page 8: Installation Material

    Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 9: Installation Tool

    Item Description Optical fiber Single mode optical fiber Antenna Omnidirectional, or directional antenna Ground cable The diameter of grounding cable must be 10mm or greater. Installation Tool Knife Vise Wrench Cross screw driver Tape measure Percussion drill and Cable vice hammer some drill heads NOTE: Other accessories have been packed in the packing box.
  • Page 10: Install On Pole

    NOTE: The eNB may adopt different models of GPS antenna, so the GPS antenna may not the same as above figure. But the installation steps that fix it on the eNB is the same. Weatherproofing To protect the connection points from weather and climate, clean each connection point before installing cold shrink tubes, per the following figure.
  • Page 11: Install On Wall

    Following steps introduce how to fix the pre-assembled eNB on a pole. Install on Wall Take apart assembly bracket first, only remains the wall bracket, as shown in Figure 2-3. Figure 2-3 Wall Bracket...
  • Page 12: Connect Cable

    Following steps introduce how to fix the pre-assembled eNB on a wall. Connect Cable...
  • Page 13 NOTE: According to the requirements of the site, both DC and AC power supply are provided to support different requirements of installation site. If DC power is selected, the power cable connects to the DC power supply directly. If AC power is selected, the power cable must connect to the AC power supply through a DC-AC adaptor.
