Kwikset SMARTCODE 916 Installation And User Manual page 3

7
Pair the lock with your smart home system
Initiate the pairing process at your smart
A
home controller. Refer to your smart home
system instructions for more information.
8
Add user codes (30 max)
It is recommended that you add and delete all user codes through your smart home system.
If your system does not allow this, codes may be added directly to the lock as shown here.
Programming information
A
Mastercode: For enhanced security, a
mastercode may be used when adding and
deleting user codes. For more information
about the mastercode, download the
SmartCode 916 Programming and
Troubleshooting Guide at www.kwikset.com.
Programming Timeout :During
programming, if the screen is not pressed
for 20 seconds, the system will time out
(indicated by three beeps and the "X" pattern
flashing three times), and you will need to
restart the procedure.
F
What digits and sounds did the lock produce?
Checkmark symbol with one beep
9
Test the lock (review normal operation)
Confirm that the code(s) added in previous step can unlock the door.
Activating the Screen
Option 1 Option 2
Touch screen with Touch lower left
palm or back of area of screen
hand until digits (where checkmark
illuminate. is located) until
digits illuminate.
10
Re-key the lock (if needed) and install the battery cover
A
Optional: Re-key the lock.
a
K
IMPORTANT:
Remove battery
pack before
re-keying.
When prompted by your smart home
B
system to initiate pairing at the lock, press
button "A" on the lock interior four times.
button "A"
Make sure the door
B
is open. Press the
Program button once.
1x
Programming was successful.
*Beeping sound will only be heard if switch #3 (on the lock interior) is in the on positon. See "Switches and Status LED Colors" on page 4.
Locking the Door
1. Activate the screen.
Option 3
2. Press Lock symbol.
Touch screen
Note: If no user codes
with three or
are programmed, the
more fingers until
door cannot be locked
digits illuminate.
via touchscreen.
b
Re-key the lock
to work with your
existing key. See
the supplied
SmartKey Re-key
instructions for
more information.
H
If the pairing process is successful, re-name the
C
lock in your system (if applicable).
If the pairing process is unsuccessful, press button "B" nine times.
D
Perform steps 7A-7C again.
If pairing is still unsuccessful, consult the Programming and
button "B"
Troubleshooting Guide on the SmartCode 916 page at www.kwikset.com.
Press checkmark
C
symbol once.
or
Move swiftly through
programming, as the system
will time out if no button is
pressed for 20 seconds.
Unlocking the Door
1. Activate the screen.
2. If SecureScreen™ is enabled, touch
the random digits that appear.
3. Enter user code.
If you press the wrong digit while entering
a user code, you can press the Lock symbol
once to clear the digits entered previously and
immediately restart the code entry process.
c
K
Reinstall
battery
pack.
3 / 4
Enter user code. A total
D E
of 30 user codes may
be programmed.
Each user code must be
a unique code between 4
and 8 digits, depending on
your smart home system.
"X" pattern with three beeps
3x
Programming was unsuccessful.
Make sure the user code is Make sure the lock has
not a duplicate and that it room for an additional code.
is between 4 and 8 digits If all user code positions
during your next attempt. are filled, delete a code to
make room for this one.
SecureScreen™
SecureScreen is an added-security feature
that displays random digits before you enter
a user code to unlock the door. This feature
ensures that there are fingerprints on all
digits so that codes cannot be identified by
examining the touchscreen for finger prints.
B
Install the battery cover.
a
b
M
Press lock symbol once.
If desired, this feature
can be disabled by
turning switch #4 to
the off position. See
"Switches" on page 4.
actual
size
V
V (x3)
