Kwikset Smartcode 910 Installation And User Manual

66071 001
Rev 01
Z Wave® Plus
Installation and User Guide
Required tools
4 AA Batteries Ruler Phillips head screwdriver
Additional Tools (depending on application)
Hammer Wood block
1 Prepare the door and check dimensions
If drilling a new door, use the supplied template and the complete
door drilling instructions available at www.kwikset.com/doorprep.
Measure to con irm that the hole in
A
the door is either 2 1/8" (54 mm) or
1 1/2" (38 mm).
2 1/8"
54 mm
or
1 1/2"
38 mm
Note: Additional door preparation may be
required for doors with 1 1/2" (38 mm) holes.
Consult the deadbolt drilling instructions at
www.kwikset.com/doorprep.
2 Install the latch and strike
A
Is the door edge chiseled?
YES
or
chiseled
Use latch "A". If the Use latch "B" (not
latch bolt is not already included). If the latch
extended, extend the bolt is not already
latch bolt as shown. extended, extend the
latch bolt as shown.
A
Kwikset
Technical Support
1 866 863 6584
www.kwikset.com
Measure to con irm that the backset is
B
either 2 3/8" or 2 3/4" (60 or 70 mm).
b a
2 3/8" or 2 3/4"
c k
s e
t
60 or 70 mm
B
Hold the latch in front of the door hole, with the latch
face lush against the door edge.
NO
not
chiseled
A
B
C
Is the D-shaped hole centered in the door hole?
YES
D-shaped hole
No adjustment is required.
Proceed to next step.
1 / 4
Parts in the box
Latch Exterior
Assembly
A
F
W
B
Mounting
"B" is not included. If needed,
please contact Kwikset to order Plate
a drive-in latch for your lock.
Strike Adapter
ring
C D
SmartKey
Tool
Keys
E
C
Measure to con irm that the hole in
the door edge is 1" (25 mm).
1"
25 mm
actual
size
N
D
Which latch are you installing?
Latch "A"
B
NO
or
D-shaped hole
Rotate latch face as
shown to extend latch.
E
Install strike on the door frame.
A
Make sure the hole in the door frame is drilled a
minimum of 1" (25 mm) deep.
B
Interior
Assembly
K L M
Fasteners
03809 46780
Q
N
G
P S
48654 27526 64109
T
H
U V
Measure to con irm that the door is
D
between 1 3/8" and 1 3/4"* (35 mm
and 44 mm*) thick.
1 3/8" – 1 3/4"*
35 – 44 mm*
*Service kits for 2 1/4" (57 mm) thick doors
are available through Kwikset.
P Q
S
Latch "B"
or
B
A
N or P
(2x)
wood
block
Longer screws
install closest to
the door jamb.
S (2x)
C
Q (2x)
door frame
