Kwikset SMARTCODE 916 Installation And User Manual page 2

4
Install the exterior touchscreen
A
What is the diameter of the hole in the door?
Diameter is 2-1/8"
(54 mm)
or
2-1/8"
54 mm
"D" is required for installation.
Install "D" on "F".
F
D
B
Locate screws for step 3C and keep them within reach.
T
5
Install the interior assembly
A
Remove battery cover and battery pack from interior assembly.
a
Make sure turnpiece is in
the vertical position.
c
Make sure
turnpiece shaft is
rotated as shown.
L
6
Install the batteries and perform the door handing process
This step will teach your lock the orientation of your door and is crucial to lock operation.
Install 4 AA batteries in battery pack.
A
W
K
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
C
Install exterior touchscreen and mounting plate.
Diameter is 1-1/2"
(38 mm)
1-1/2"
38 mm
"D" is not needed for
installation. Discard "D".
D
b
L
M
d
K
Do not install
batteries until step 6.
L
Make sure the door is open, and
B
insert the battery pack.
K
a
F
Cable goes
underneath latch.
c
Keep parallel to
edge of door.
T (2x)
Tighten
screws evenly.
B
Install interior assembly onto mounting plate.
a
L
align
Ensure tight cable
connection.
c
After a few seconds, the latch bolt will retract and extend on
C
its own to learn the orientation of the door. This is called the
door handing process, and it is crucial to lock operation.
If the touchscreen indicates a failure, attempt this procedure again.
D
If the door handing process is still unsuccessful after a second
attempt, perform the "Manual Door Handing" procedure on page 4.
2 / 4
actual
size
T
b
Support exterior
assembly during
mounting plate
installation.
G
Route cable through
center hole, then push
cable into bottom hole.
d
E
Insert key and
test latch. If latch
does not extend or
retract smoothly,
T
adjust screws (T).
Remove key when
finished and make
sure the latch bolt
is fully extended.
b
Lay excess cable flat inside the
bottom of the interior housing.
d
U
(2x)
bottom
hole
Once the door handing process
is complete, the touchscreen
will indicate success or failure:
Success:
flashing checkmark
symbol and single
column of digits
actual
size
U
Failure:
flashing
"X" pattern
