- Page 1 Fold- Away Bar HZ1020R0TX- Walnut For assistance with assembly, contact: HZ1021R0TX- Black Southern Enterprises, Inc. Customer Service 1-800-633-5096 service@seidal.com Assembly Instructions wwww.seidal.com Supports up to 100Lb...
- Page 2 HZ1020R0TX-Walnut/ HZ1021R0TX-Black Fold-Away Bar Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 HZ1020R0TX-Walnut/HZ1021R0TX-Black Fold-Away Bar Hardware List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 4 HZ1020R0TX-Walnut/HZ1021R0TX-Black Fold-Away Bar Assembly Instructions Attach top shelf (F) and bottom Figure 1 shelf (G) to middle panel (I) by using cam bolts (1), cam locks (2), and wood dowels (3) as shown. Turn the cam locks clockwise to secure panels in place.
- Page 5 HZ1020R0TX-WALNUT/HZ1021R0TX-BLAC HZ1020R0TX-Walnut/HZ1021R0TX-Black Fold-Away Bar Assembly Instructions Attach top panel (A) and base (J) to left panel(D) and right panel (E) by using cam bolts (1), cam locks(2) wood dowels(3),long bolts(5) and flat washer (6) as shown. Figure 3 Attach left door (B) and right...
- Page 6 HZ1020R0TX-Walnut/HZ1021R0TX-Black Fold-Away Bar Assembly Instructions Attach top back panel (K), middle back panel (L) and lower back panel (M) to the back of the unit by using Phillip screws (8) as shown. Figure 5 Please mount at least 1 screw into a wall stud.
- Page 7 HZ1020R0TX-WALNUT/HZ1021R0TX-BLACK FOLD-AWAY BAR Assembly Instructions Attach knobs (11) to left door (B) and right door(C) by using 2 pcs bolt (12),then, attach to the wall by using wall anchors (9), wall screws (10) and flat washers (13) as shown. Insert drawers (H) as shown.
- Page 8 Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
