Fiat 500 Hybrid 2020 Owner's Handbook Manual
  1. Manuals
  2. Brands
  3. Fiat Manuals
  4. Automobile
  5. 500 Hybrid 2020
  6. Owner's handbook manual

Fiat 500 Hybrid 2020 Owner's Handbook Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

O
W
N
E
R
H
A
N
D
B
O
O
K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 500 Hybrid 2020 and is the answer not in the manual?

Questions and answers

GEORGE SFAKIANAKIS
March 13, 2025

DOES FIAT 500 HYBRID PRIMAVERA EDITION HAS HILL ASSISTANCE OPERATION

0
1 comments:
Mr. Anderson
March 13, 2025

The Fiat 500 Hybrid 2020 includes a hill holder clutch to prevent rolling backward on uphill junctions. However, the context does not specifically mention the "Primavera Edition" having this feature.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Fiat 500 Hybrid 2020

Summary of Contents for Fiat 500 Hybrid 2020

  • Page 2 For the enthusiast user who wants to have insights, curiosities and detailed information about the characteristics and functions of the vehicle, Fiat gives the opportunity to consult a dedicated section which is available in electronic format. ONLINE VEHICLE OWNER HANDBOOK The following symbol ...
  • Page 3 In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty Certificate, the detail of the terms and conditions for maintaining its validity and the range of additional services available to Fiat Customers.
  • Page 4 If after buying the car, you decide to install electrical accessories (with the risk of gradually draining the conventional lead battery), contact a Fiat Dealership. They can calculate the overall electrical requirement and check that the electric system in the car is able to support the required load.
  • Page 5 USE OF THE OWNER HANDBOOK OPERATING INSTRUCTIONS Each time direction instructions (left/right or forwards/backwards) about the vehicle are given, these must be understood as regarding an occupant in the driver's seat. Special cases not complying with this rule will be specified as appropriate in the text. The figures in the Owner Handbook are provided by way of example only: this might imply that some details of the image do not correspond to the actual arrangement of your car.
  • Page 6 WARNING Where the text refers to the "conventional battery", it means the 12 V service lead battery located in the engine compartment; where the text refers to the "auxiliary battery", it means the 12 V lithium drive battery for the hybrid system, located under the left seat.
  • Page 7 GETTING TO KNOW YOUR CAR KNOWING THE INSTRUMENT PANEL SAFETY STARTING AND DRIVING IN AN EMERGENCY MAINTENANCE AND CARE TECHNICAL SPECIFICATIONS MULTIMEDIA CONTENTS...
  • Page 9 THE KEYS........10 The handbook that you are reading IGNITION DEVICE ......11 simply and directly explains how it is THE FIAT CODE SYSTEM .... 11 made and how it works. DOORS ........12 That’s why we advise you to read it SEATS........
  • Page 10 DASHBOARD The presence, graphics and position of panels, controls, instruments and indicators may vary according to the different versions. F0S0641 A. Lights/direction indicator stalk - B. Audio controls on the steering wheel - C. Instrument panel - D. Headlight alignment corrector - E.
  • Page 11 Dashboard with Sport steering wheel F0S0642 A. Lights/direction indicator stalk - B. Audio controls on the steering wheel - C. Instrument panel - D. Headlight alignment corrector - E. Audio controls on the steering wheel - F. Windscreen wiper/washer and rear window wiper - G. Dualdrive electric power steering (CITY function) - H.
  • Page 12 THE KEYS When a speed of over 20 km/h is reached, the doors will be automatically locked if the specific function was set (for versions/markets, where provided) with the Setup menu. MECHANICAL KEY Opening the tailgate by the remote The metal insert (A) fig. 3 operates: control the ignition device;...
  • Page 13 STEERING LOCK of, as specified by law, in the special THE FIAT CODE containers, otherwise take them to a Fiat Dealership, which will deal with their SYSTEM Engagement: when the key is in disposal. position STOP, remove the key and turn the steering wheel until it is locked.
  • Page 14 DOORS WARNING 6) Before opening a door, ensure that you can do it in conditions of safety. Open the doors only when the car is stationary. OPENING/CLOSING WITH IMPORTANT To open from outside (driver side door): turn the key to position (1) fig. 6 2) Make sure to take the key with you and pull the handle.
  • Page 15 Driver side and passenger side, with position memory (for versions/markets, where provided) To bring back the seat in its initial position proceed as follows: slide the seat backwards pushing on the backrest, until the seat is locked (movement 4); adjust lever (D) fig. 11 (movement 5); raise the backrest (movement 6) until F0S0013 F0S0015...
  • Page 16 If an obstacle is present (e.g. a bag) IMPORTANT and the seat cannot be returned to its original position, the mechanism 3) The fabric upholstery of the seats has reattaches the seat only positioning been designed to withstand long-term the backrest to ensure that the seat is wear deriving from normal use of the car.
  • Page 17 STEERING WHEEL The particular shape of the head restraint deliberately interferes with the 14) 15) correct support of the rear passenger’s The steering wheel can be adjusted back on the backrest in order to force vertically. them to lift the head restraint for correct To adjust bring the lever (A) fig.
  • Page 18 REAR-VIEW mirror is automatically set for daytime use. MIRRORS DOOR MIRRORS INTERIOR MIRROR The mirror is fitted with a safety device that causes its release in the event of a Manual adjustment violent impact with the passenger. The door mirror can be adjusted from Lever (A) fig.
  • Page 19 EXTERIOR LIGHTS daytime running lights switch off and left stalk ring first to the O position (or the side lights and dipped headlights the AUTO position if the vehicle does switch on. not have a dusk sensor) and then to position .
  • Page 20 function allows turning on lights and WARNING The function can only be third press: front/rear fog lights off. low beams. activated with the ignition device at MAR. It is possible to set the headlights turning on time by pulling the left lever towards the steering wheel (unstable Function deactivation position) one or more times.
  • Page 21 WINDOW WASHING WINDSCREEN WIPERS which you are driving. Comply with legal WITH AUTOMATIC requirements. 19) 20) WIPING The right stalk controls windscreen and The stalk can be put in four different INTERIOR LIGHTS rear window wiper/washer operation. positions fig. 25: WINDSCREEN WIPER / A - windscreen wiper stationary (0) WASHER...
  • Page 22 AUTOMATIC WIPING single movement; the latter turns on automatically if you keep the lever (for versions/markets, where provided) pulled for more than half a second. The operation of the windscreen wiper Activation terminates several strokes after the The user can choose automatic wiping stalk is released;...
  • Page 23 In such conditions, the wiper may be subjected to excessive stress and the motor cut-out switch, which prevents operation for a few seconds, may intervene. If operation is not restored, contact a Fiat Dealership.
  • Page 24 CLIMATE CONTROL SYSTEM MANUAL CLIMATE CONTROL SYSTEM (for versions/markets, where provided) F0S0594...
  • Page 25   NOTE Optimal cooling/heating of the A - fan knob and climate control passenger compartment may not be system compressor button. guaranteed together with Start&Stop. B - recirculation control / air intake from To prioritise the operation of the outside knob. climate control system, deactivate the C - air distribution knob: Start&Stop function.
  • Page 26   AUTOMATIC CLIMATE CONTROL SYSTEM (for versions/markets, where provided) F0S0595...
  • Page 27   E - Passenger compartment air G - Switching off A - Climate control system compressor on/off distribution. H - Internal air recirculation on/off   By pressing the buttons, one of the five button possible air flow distribution patterns It is advisable to switch the internal air B - Adjustment of temperature can be selected: recirculation on whilst queuing or in...
  • Page 28 . The use of other coolants affects the efficiency and condition of the system. The lubricant used for the compressor is also strictly linked to the type of cooling gas, please refer to a Fiat Dealership.
  • Page 29 ELECTRIC WINDOWS WARNING 21) 22) These operate when the ignition key 21) Improper use of the electric windows can be dangerous. Before and during their is turned to MAR and for about two operation, ensure that any passengers are minutes after turning the key to STOP not at risk from the moving glass either or removing it.
  • Page 30 keep the button (B) fig. 31 pressed WARNING so that the roof closes completely in stages 23) When leaving the car (equipped with after full closing, wait for the sunroof mechanical key with a remote control), motor to stop. always remove the key from the starter switch to avoid the risk of injury to those EMERGENCY OPERATION still inside the car due to accidental...
  • Page 31 SOFT TOP goes automatically to the full opening position (vertical opening) fig. 35. Suggestions it is advisable to close the soft top when the car is parked. The closed soft top effectively protects the car from bad weather and from theft; it is advisable to put valuables in the boot and lock the lid even when the top F0S0542...
  • Page 32 roof will stop and movement will be IMPORTANT NOTES To prevent damage, do not use reversed, moving to the initial position scrapers or sprays to remove ice from The horizontal and vertical parts of (all open). the soft top can be operated at any the heated rear window.
  • Page 33 Fix&Go kit. WIND STOP car” chapter, then manually move the soft top as described above. To restore the automatic movement conditions, apply to Fiat Service Network. INITIALISATION PROCEDURE The soft top must be reinitialised after...
  • Page 34 To lift the spoiler, release the catch moving soft top roof or by objects getting sticking, apply talcum powder or products by means of the slider (A) moving it to caught and dragged by it. specifically for rubber trim (silicone spray). position 2 as shown in fig.
  • Page 35 BONNET 31) 32) 33) 34) 35) OPENING Proceed as follows: pull the lever (A) fig. 42 in the direction indicated by the arrow; F0S0101 F0S0135 Opening the tailgate with soft top all open WARNING Pressing the tailgate opening one- touch button (A) fig. 40 to automatically 27) Never exceed the maximum allowed close the soft top to spoiler position.
  • Page 36 CLOSING wiper arms are not raised from the To close the bonnet, remove the windscreen, that the vehicle is stationary and that the handbrake is engaged. bonnet stay and put it back in its own locking device, slowly lower the bonnet to about 20 cm from the engine compartment, then let it drop into position and check that it is completely...
  • Page 37 KNOWING THE INSTRUMENT PANEL This section of the handbook gives INSTRUMENT PANEL ....36 you all the information you need to DISPLAY ........38 understand, interpret and use the TRIP COMPUTER ......42 instrument panel correctly. WARNING LIGHTS AND MESSAGES ........ 45...
  • Page 38 INSTRUMENT PANEL The instrument background colour and type may vary according to the versions. VERSIONS WITH MULTIFUNCTION DISPLAY F0S0687 A. Speedometer B. Rev counter C. Multifunction display with digital fuel level gauge and digital indicator of the auxiliary battery charge level...
  • Page 39 VERSIONS WITH COLOUR DISPLAY F0S0686 A. Colour display B. "Eco Index" digital gauge C. Digital fuel level gauge D. Digital engine coolant temperature gauge E. Rev counter...
  • Page 40 DISPLAY M - Auxiliary battery charge level I - Headlight alignment position (with indicator dipped beam headlights on only) N - Speed Limiter set speed L - Time MULTIFUNCTION O - Car maintenance indicator (service) M - Eco Index DISPLAY “STANDARD” N - Digital fuel level gauge COLOUR DISPLAY SCREEN...
  • Page 41 "Trip computer" paragraph in this display, (B) fig. 49 for versions with (B) fig. 51 (for versions with colour chapter. colour display). If the conditions permit, display). the heat engine turns off after shifting to GEAR SHIFT INDICATOR neutral in order to reduce consumption (when driving on level road) ("EXTENDED S&S"...
  • Page 42 SETUP MENU ACTIVATION when you select the “Time” SET TIME submenu, pressing the MENU SET DATE button briefly the display shows the AUTOCLOSE "hours"; – UNITS press the + or button to adjust; LANGUAGE briefly pressing the MENU button BUZZER VOLUME the “minutes”...
  • Page 43 MAR. Go to a Fiat Dealership, where car maintenance. To consult the the "Service Schedule" operations will Reset tyres (iTPMS reset)
  • Page 44 – TRIP COMPUTER press the + or button to select Trip B: (“Yes” or “No”); Average Fuel Consumption B briefly press the MENU button: Average Speed B the display will show “Confirm”; Travel Distance B GENERAL INFORMATION – press the + or button to select Travel Time B (driving time) The Trip computer is used to display...
  • Page 45 Engine coolant temperature Energy Flows (versions with multifunction display) Trip A Shows the engine coolant temperature with an 8-level indicator on 4 circles fig. 53. The circles (A) are progressively coloured partially or fully from left to Energy Gain A right as the temperature increases.
  • Page 46 motor is shown by the white flows on a iTPMS SCREEN yellow background (A) from the auxiliary (for versions/markets, where provided. battery (C). For versions with colour display) The screen shows the tyre pressure Energy Consumption status. The screen of fig. 59 appears of (versions with colour display) the pressure is correct.
  • Page 47 WARNING LIGHTS AND MESSAGES IMPORTANT NOTES WARNING Warning lights are accompanied by a specific message and/or sound when implemented on the instrument panel. These indications are indicative and precautionary and as such must not be considered as exhaustive and/or alternative to the information contained in the Owner Handbook, which you are advised to read carefully in all cases.
  • Page 48 For permanent deactivation of the acoustic signal (buzzer) of the S.B.R. (Seat Belt Reminder) system contact a Fiat Dealership. The system can be reactivated at any time using the Setup Menu. EBD FAILURE The simultaneous switching on of the warning lights with the engine on indicates either an anomaly yellow of the EBD system or that the system is not available.
  • Page 49 If the warning light or the symbol on the display (together with a dedicated message on the display on some versions) remains on, contact a Fiat Dealership immediately. HYBRID SYSTEM FAILURE The warning light or symbol also appears on the display in the event of a hybrid system failure. For...
  • Page 50 MAX marks on the reservoir itself. Also check visually for any fluid leaks. If, when restarting, the warning light switches on again, contact a Fiat Dealership; If the car is used under demanding conditions (e.g. when fully loaded): slow down and, if the warning light stays on, stop the car.
  • Page 51 If the warning light switches on while driving (on some versions, together with a dedicated message on the display) you may not have steering assistance. Although it will still be possible to steer the vehicle, the effort needed to operate the steering wheel could be increased: contact a Fiat Dealership as soon as possible.
  • Page 52 If the warning light does not go off or stays on together with the LED on the ASR OFF button while driving. The display will show a dedicated message. Contact a Fiat Dealership. Hill Holder failure This warning light switches on, on some versions together with a dedicated message on the display, yellow (Versions with colour display) in the event of a Hill Holder system failure.
  • Page 53 IMPORTANT If the warning light flashes or the symbol is constantly on, depending on the versions, there is a fault in the system. If this is the case, go to a Fiat Dealership to have the system checked. REAR FOG LIGHT The warning light switches on when the rear fog light is activated.
  • Page 54 Warning light What it means Fuel cut-off system intervention/failure This warning light switches on, on some versions along with a dedicated message on the display, in the case of fuel cut-off system activation/failure. Exterior lights failure The warning light switches on when an external light failure is detected. Parking sensor failure The warning light turns on and the dedicated message is shown on the display when a parking sensor fault is detected.
  • Page 55 If this is not the case, carry out the Tyre reset procedure after restoring the normal operating conditions. If the malfunction warning persists, contact a Fiat Dealership as soon as possible. 42) 43) Green warning lights  ...
  • Page 56 Warning light What it means FOG LIGHTS The warning light comes on when the front fog lights are turned on. green LEFT DIRECTION INDICATOR The warning light turns on when the direction indicator control lever is moved downwards or, together with the right indicator, when the hazard warning light button is pressed. green RIGHT DIRECTION INDICATOR The warning light turns on when the direction indicator control lever is moved upwards or, together...
  • Page 57 Contact a Fiat Dealership immediately to have the system checked. 42) If the system signals a pressure drop on a specific tyre, it is recommended to check the pressure on all four tyres. The iTPMS does not relieve the driver from the obligation to check the tyre pressure every month;...
  • Page 58 INSTRUMENT PANEL WARNING SYMBOLS Red symbols   Symbol What it means OPEN DOORS / BONNET / BOOT (versions with colour display) The symbols on the display switches on, together with a dedicated message, on some versions, when one or more doors, the tailgate or the bonnet (for versions/markets, where provided) are not properly closed.
  • Page 59 This symbol appears in the event of an auxiliary battery failure with the corresponding dedicated message. The charge state of the auxiliary battery will not be displayed in this case. Contact a Fiat Dealership as soon as possible. HYBRID SYSTEM FAILURE...
  • Page 60 MAR-ON or, for versions/markets, where provided, every 200 km (or equivalent value in miles). Go to a Fiat Dealership, where the "Scheduled Servicing Plan" operations will be performed and the message will be reset. ASR SYSTEM OFF (colour display) The symbol lights up on the colour display together with a dedicated message when the ASR system is deactivated by pressing the ASR-OFF button on the dashboard.
  • Page 61 When the engine is started (ignition key turned to MAR position), the warning light turns on for about 8 seconds, provided that at least 5 seconds have elapsed from when it was switched off. If not, contact a Fiat Dealership. If the engine is switched off/on again in less than 5 seconds yellow the warning light may remain off.
  • Page 62 IMPORTANT If the warning light flashes or the symbol is constantly on, depending on the versions, there is a fault in the system. If this is the case, go to a Fiat Dealership to have the system checked. WARNING 44) If the warning light switches on, the degraded engine oil must be changed as soon as possible, and never more than 500 km from the first time that the warning light switches on.
  • Page 63 MESSAGES ON INSTRUMENT PANEL   Messages What it means “DUALDRIVE” ELECTRIC POWER STEERING SYSTEM ACTIVATION The indication CITY switches on when the "Dualdrive" electric power steering system is activated CITY by pressing the "CITY" button on the dashboard. The CITY indication goes off when the button is pressed again.
  • Page 64 SAFETY The chapter that you are about to ACTIVE SAFETY SYSTEMS ... 63 read is very important: it describes the DRIVING ASSISTANCE safety systems with which the vehicle is SYSTEMS ........66 equipped and provides instructions on OCCUPANT PROTECTION how to use them correctly. SYSTEMS ........
  • Page 65 ACTIVE SAFETY ESC (Electronic Stability surface where the grip of the left and right wheels varies, or on corners. Control) SYSTEM SYSTEMS This is an electronic system that System intervention The vehicle has the following active controls car stability in the event of loss A slight pulsing of the brake pedal and safety systems: of tyre grip, helping maintain directional...
  • Page 66 downhill: car stationary on a road braked) until the clutch is gradually if the slipping only involves one of with a gradient higher than 5%, engine released (holding the accelerator pedal the drive wheels, it also intervenes running, brake pressed and reverse pressed): at this point, the system automatically, braking the wheel that is gear engaged.
  • Page 67 Do not reduce pressure on the 52) For the correct operation of the ABS, brake pedal until braking is no longer the tyres must of necessity be the same make and type on all wheels, in perfect necessary. condition and, above all, of the prescribed The HBA system is deactivated when type and dimensions.
  • Page 68 DRIVING 60) The capability of the ESC system 68) Do not take unnecessary risks, even if must never be tested irresponsibly your vehicle is fitted with an ASR system. ASSISTANCE and dangerously, in such a way as to Your driving style must always be suited SYSTEMS compromise personal safety and the to the road conditions, visibility and traffic.
  • Page 69 Low tyre pressure pressure values specified in the inflation the axles) the system may give false pressure table (see "Wheels" paragraph warnings or be temporarily deactivated. The system warns the driver if one or in the "Technical specifications" more tyres are flat by switching on the If the system is temporarily deactivated chapter).
  • Page 70 SEAT BELTS Guide the belt while it is rewinding to 78) The system only warns that the tyre prevent it from twisting. Through the pressure is low: it is not able to inflate All vehicle seats are equipped with seat them.
  • Page 71 (see the following paragraphs). (fitted near the kick plate): to its normal position, make sure the NOTE Contact a Fiat Dealership to The activation of this device is indicated seat belts are positioned so they are deactivate this acoustic warning by the shortening of the metal cable.
  • Page 72 single belt to protect them both fig. 67. 82) 83) 84) In general, do not place any objects between the person and the belt. LOAD LIMITERS To increase occupant safety, the retractors of the safety belts contain a load limiter to dose the force acting on the chest and shoulders during the belt restraining action in the case of frontal collisions.
  • Page 73 82) The pretensioner may be used only SYSTEMS once. Contact a Fiat Dealership to have it as possible (at least until 3–4 years replaced after it has been deployed. CARRYING CHILDREN...
  • Page 74 WARNING 86) SEVERE DANGER! When a passenger front airbag is fitted, do not install rearward facing child restraint systems on the front passenger seat. Deployment of the airbag in a crash could cause fatal injuries to the child regardless of the severity of the collision.
  • Page 75 All restraint devices must bear the type-approval data, together with the control mark, on a label solidly fixed to the child restraint system which must never be removed. Lineaccessori MOPAR ® includes child restraint systems for each weight group. These devices are recommended having been specifically designed for Fiat vehicles.
  • Page 76 WARNING For correct installation on the vehicle, some universal child restraint systems require an accessory (base) sold separately by the restraint system's producer. Therefore, FCA recommends confirming the retailer if the desired child seat can be installed in the car by having it done, before buying the seat.
  • Page 77 INSTALLING A CHILD lower part is snug on the pelvis not the CARSEAT WITH abdomen. SEATBELTS 90) 91) 92) 93) The Universal child restraint systems installed with the seat belts only are type-approved on the basis of the ECE R44 standard and are divided into various weight groups.
  • Page 78 INSTALLING AN ISOFIX CHILD RESTRAINT SYSTEM 94) 95) 96) 97) 98) The car is equipped with ISOFIX anchorages, a new standard which makes fitting a child restraint system quick, simple and safe. The ISOFIX system lets you install the ISOFIX child restraining system without F0S0133 using the car seat belts but connecting them directly to the car seat with three...
  • Page 79 SUITABILITY OF it from the car. Do not leave it unsecured PASSENGER SEATS FOR inside the passenger compartment. In this way, in the event of sudden braking or an i-SIZE CHILD RESTRAINT accident, it will not cause injuries to the SYSTEM USE occupants.
  • Page 80 Child restraint system installation   The table provides guidelines on positioning child restraint systems on the car seats. Each child restraint system position complies with the UNECE standards   Number of seats Seat number Airbag Airbag ENABLED DISABLED Seat suitable for rearward facing child restraint systems (U) Seat suitable for forward...
  • Page 81 Number of seats Seat number Airbag Airbag ENABLED DISABLED Sear suitable for ISOFIX forward facing fixtures (F2/ F2X / F3) (IUF) U = Position suitable for a "universal" child restraint system approved for this weight category. UF = Position suitable for a "universal" forward facing child restraint system approved for this weight category. IUF = Position suitable for an "ISOFIX"...
  • Page 82 CHILD RESTRAINT SYSTEMS RECOMMENDED BY FIAT FOR YOUR CAR In the markets for which they are available, Lineaccessori MOPAR ® offers a complete range of child restraint systems to be fixed using the seat belt with three anchor points or the ISOFIX anchorages.
  • Page 83 ISOFIX anchorages Britax Römer KidFix XP (for Group 2: from 15 to 25 of the vehicle, if present. Fiat versions/markets, where provided) kg, from 95 cm to 135 cm recommends installing it using Fiat order code: 71807984 the vehicle’s ISOFIX anchor...
  • Page 84 It can only be fitted facing forwards, using the three-point seat belt and the ISOFIX anchorages Britax Römer KidFix XP (for of the vehicle, if present. Fiat versions/markets, where provided) recommends installing it using Fiat order code: 71807984 the vehicle’s ISOFIX anchor points.
  • Page 85 Main recommendations SUPPLEMENTARY Never carry children on your lap, to carry children safely: even newborns. No-one can hold a RESTRAINT SYSTEM Install the child restraint systems child in the case of a crash. (SRS) - AIRBAG If the car has been involved in a road on the rear seat, which is the most accident, replace the child restraint protected position in the event of an...
  • Page 86 occupants body and the structures volume at the moment of maximum this bag has a larger volume than the which could cause injury. It will deflate inflation fills most of the space between driver's. immediately afterwards. the steering wheel and the driver, between the lower post guard and the Front airbags are not a replacement of knees on passenger side and between...
  • Page 87 101) When an active passenger airbag is fitted, DO NOT install rear facing child restraint systems on the front seat. Deployment of the airbag in an accident could cause fatal injuries to the child regardless of the severity of the impact. 102) When there is an active passenger airbag, DO NOT install rearward facing child restraint systems on the front seat.
  • Page 88 Passenger's front airbag and child restraint systems: IMPORTANT F0S1025...
  • Page 89 shunts, roll-overs, etc.) is not a system Driver knee bag malfunction. (for versions/markets, where provided) It consists of an instantly inflating Side bag cushion contained in a special These comprise two instantly inflating compartment (C) under the lower bags located in the front seat backrests steering column guard fig.
  • Page 90 In the event of a side impact, the passenger airbag protection status. If the car to a Fiat Dealership to have the system provides best protection if the the warning light is off, passenger side...
  • Page 91 Fiat 114) Do not affix rigid objects to the coat Dealership. hooks or support handles.
  • Page 92 STARTING AND DRIVING Let’s get to the core of the vehicle: STARTING THE ENGINE ....91 seeing how you can exploit all of its PARKING THE VEHICLE ....91 potential to the full. MANUAL TRANSMISSION .... 92 We’ll look at how to drive it safely in any DUALDRIVE ELECTRIC POWER situation, so that it can be a welcome STEERING ........
  • Page 93 STOP and then back to MAR. If the warning light remains on, try with the other keys provided with the car. Contact a Fiat Dealership if you still cannot start the engine.
  • Page 94 WARNING 120) The car should be braked after a few clicks of the lever, if it is not, contact a Fiat Dealership to have it adjusted. 121) Never leave children unattended in the car. Always remove the key from the ignition when leaving the car and take it with you.
  • Page 95 DUALDRIVE versions/markets where provided, the WARNING electronic clutch control could cut in, ELECTRIC POWER interpreting the incorrect driving style STEERING 124) It is absolutely forbidden to carry as a fault. out any after-market operation involving steering system or steering column WARNING While driving in 6 th (for versions/markets, where provided) modifications (e.g.: installation of...
  • Page 96 HYBRID SYSTEM auxiliary battery and the traditional lead the Start&Stop ("EXTENDED S&S") battery. When the accelerator pedal function. In this way, the efficiency is released with the gear is engaged, of the car is increased, by reducing the BSG acts as an engine brake (e- consumption, harmful gas emissions COASTING function).
  • Page 97 Start&Stop mode will be active versions/markets where provided) the (Gear Shift Indicator) may advise whenever the engine is started. warning light or the symbol flash on shifting to neutral (N) by displaying the instrument panel. the letter "N" on the instrument panel display.
  • Page 98 126) If the conventional battery needs speed increments by 1 km/h. Holding To activate the device, turn ring (C) to be replaced, always contact a Fiat it in the SET + position, the speed Dealership. Replace the battery with a new fig.
  • Page 99 The device deactivates automatically in exceeded even with the device active the event of fault in the system. In this (e.g. in the event of overtaking). case, contact a Fiat Dealership. The device is disabled until the speed AUTOMATIC RESET OF F0S0624...
  • Page 100 (B) ACOUSTIC WARNING 130) In case of a malfunction or failure of upwards. the device, contact a Fiat Dealership. When reverse gear is engaged and 131) The electronic Cruise Control can there is an obstacle behind the car an...
  • Page 101 warning varies as the distance of the continuous sound is emitted. If there obstacle from the bumper varies. The are several obstacles, the closest one frequency of the acoustic warning: is indicated. increases as the distance between FAULT INDICATIONS car and obstacle decreases Any parking sensor faults will be becomes continuous when the indicated when reverse is engaged...
  • Page 102 Roof rack/ski rack by a Fiat Dealership. Interventions on the fuel consumption and emissions. It Remove the roof rack or the ski rack bumper that are not carried out properly is therefore advisable to move off from the roof when they are not used.
  • Page 103 REFUELLING THE Acceleration Accelerating violently severely affects consumption and emissions: acceleration should be gradual and 133) 134) 135) Before refuelling, make sure that the should not exceed the maximum fuel type is correct. Also stop the torque. engine before refuelling. CONDITIONS OF USE PETROL VERSIONS Cold starting...
  • Page 104 shown on the fuel pump (where (grass, dry leaves, pine needles, etc.): fire provided). hazard. Symbols for petrol powered cars E5: Unleaded petrol containing up to 2.7% (m/m) oxygen and with maximum 5.0% (V/V) ethanol compliant with EN228. F0S0666 E10: Unleaded petrol containing up to 3.7% (m/m) oxygen and with maximum 10.0% (V/V) ethanol compliant with EN228.
  • Page 105 IN AN EMERGENCY A punctured tyre or a burnt-out bulb? HAZARD WARNING LIGHTS ..104 At times, a problem may interfere with REPLACING A BULB ....104 our journey. REPLACING FUSES ....110 The pages on emergencies can help CHANGING A WHEEL ....116 you to deal with critical situations Fix&Go KIT ........
  • Page 106 HAZARD WARNING REPLACING A BULB LIGHTS Press button (A) fig. 94 to switch the 136) 137) 138) 139) hazard lights on/off regardless of the 36) 37) position of the ignition key. With the GENERAL device on, warning lights light INSTRUCTIONS up in the instrument panel.
  • Page 107 Light bulbs   Type Power Ref. Figure Main beams Dipped headlights Dipped headlights with gas discharge bulbs (Xenon) (for versions/markets, where provided) Front side lights / daytime running lights W21W / LL 5/21W Front direction indicators WY21W / PY24W Front direction indicators (with xenon gas PY24W discharge bulbs) Side turn light...
  • Page 108 REPLACING AN refit the rubber cap. replace the bulb-bulb holder EXTERNAL BULB assembly; refit the bulb holder in its housing FRONT LIGHT CLUSTERS (A) fig. 98 by turning it clockwise and The front light clusters contain side locking it correctly; lights, dipped headlights, main beam headlights and direction indicator bulbs.
  • Page 109 (for versions/markets, where provided) fastening clip clicks into place. Dipped beam headlights 140) (Excluding POP versions) For replacement, contact a Fiat Dipped beam headlights To replace the bulb, proceed as Dealership. follows: (POP versions only)
  • Page 110 If the guard flap is not present, contact a Fiat Dealership to have the bulb replaced. Fog lights To replace a fog light, contact a Fiat F0S0054 Dealership. fit the new bulb, making the outline REAR LIGHT CLUSTERS...
  • Page 111 REVERSING LIGHT/REAR FOG reinsert the bulb/bulb holder unit (B) by turning it clockwise; LIGHT reconnect the electrical connector Where the respective flap is provided, (A); proceed as follows to replace the bulb: refit the flap and check that it is From inside the bumper, operate the correctly locked.
  • Page 112 37) Where possible, it is advisable to have WARNING bulbs changed at a Fiat Dealership. The correct operation and direction of the external lights are absolutely essential for 136) Modifications or repairs to the electric the safety of the car and of compliance system that are not carried out properly with the law.
  • Page 113 145) Before replacing a fuse, make sure that the ignition key has been removed and that all the other services are switched off and/or disengaged. 146) Contact Fiat Dealership if a safety system (airbags, brakes), engine system (engine, gearbox) or steering system F0S0677 F0S0606 general protection fuse blows.
  • Page 114 DASHBOARD FUSE BOX F0S0172   USERS FUSE AMPERE Headlight alignment corrector 5 (*) Diagnosis socket, radio, climate control, EOBD Brake light switch, instrument panel node Central door locking Windscreen/rear window washer pump Driver side electric window...
  • Page 115 USERS FUSE AMPERE Passenger side electric window Parking sensor, control backlighting, electric mirrors Climate control, brake lights, clutch, electric sunroof, electric mirrors Instrument panel node (*)(for versions/markets, where applicable)
  • Page 116 ENGINE COMPARTMENT JUNCTION BOX F0S0607   USERS FUSE AMPERE HI-FI Climate control electric fan Headlight washers Horns Main-beam headlights Electric roof motor Heated rear window Fog lights...
  • Page 117 USERS FUSE AMPERE Front power socket (with or without cigar lighter)
  • Page 118 CHANGING A WHEEL on boats. RAISING WITH A JACK AND REPLACING A GENERAL WHEEL INSTRUCTIONS To change a wheel, proceed as follows: 147) 148) 149) 150) 151) 152) 153) 154) 155) stop the car in a position that is not JACK dangerous for oncoming traffic where Please note that:...
  • Page 119 if the car is equipped with side skirts, to let the jack pass under the car, the latter must be tilted (as shown in fig. 120); F0S0671 F0S0631 hold the extractor with two fingers, make sure that the jack fig. 123 is insert the tab between the tyre and positioned correctly;...
  • Page 120 components of the jack (screws and fit the standard wheel inserting the 4 once the normal wheel has been joints) can also cause injuries: avoid bolts into the holes; fitted, insert the press-fit hub cap, using the wrench provided, tighten touching them.
  • Page 121 Never apply a wheel cap on a space-saver wheels and vice versa: we advise you wheel. to contact a Fiat Dealership. Never go 149) If you change the type of wheel (alloy IMPORTANT under the raised vehicle: use it only in rims instead of steel rims and vice versa) the positions indicated.
  • Page 122 41) Contact a Fiat Dealership as soon as possible to have the correct tightening of the wheel bolts checked. Fix&Go KIT (for versions/markets, where provided) 157) 158) DESCRIPTION P2000158 P2000162 The Fix&Go quick tyre repair kit stop the engine, engage the hazard remove the cap from the tyre valve fig.
  • Page 123 1.8 bar / 26 psi, restore the pressure by approximately 10 m to promote specific label appears on the pressure and drive safely to a Fiat Dealership as the distribution of sealant; stop the gauge (7), stop the compressor by soon as possible.
  • Page 124 Fix&Go cartridges, 6 mm. Show the cartridge and the label to 44) 45) 46) the personnel who must handle the tyre which can be purchased from the Fiat If the battery is flat, the engine may treated with the TireKit. Dealership.
  • Page 125 Furthermore, conventional battery fluid is Fiat Dealership. converter and damage it beyond repair. poisonous and corrosive: avoid contact with skin and eyes. Keep naked flames...
  • Page 126 (B) fig. 133 from automatic disconnection of the system by a Fiat Dealership. its housing in the tool box; auxiliary battery from the electrical fully tighten it on the threaded pin.
  • Page 127 other towed) aligned as much as possible along the same centre line. 166) Whilst towing, remember that the assistance of the brake servo and the electric power steering is not available, therefore greater force needs to be exerted on the brake pedal and more effort is required on the steering wheel.
  • Page 128 MAINTENANCE AND CARE Correct servicing permits the SCHEDULED SERVICING ... 127 performance of the car to be CHECKING LEVELS ....132 maintained over time, as well as limited CONVENTIONAL BATTERY ..135 running costs and safeguarding the AUXILIARY BATTERY ....136 efficiency of the safety systems.
  • Page 129 Correct servicing is crucial for guaranteeing a long life for the car under the best conditions. For this reason, Fiat has planned a series of checks and services at fixed distance and/or time intervals, as described in the Service Schedule.
  • Page 130 SERVICE SCHEDULE WARNING Once you have carried out the last intervention in the table, continue with the scheduled servicing, maintaining the frequency indicated in the plan by marking each operation with a dot or dedicated note. Warning: simply restarting the maintenance from the start of the plan may cause the allowed interval to be exceeded for some operations!  ...
  • Page 131 Thousands of miles Thousands of kilometres Years Check cleanliness of bonnet and luggage compartment locks, cleanliness and lubrication of linkage Check soft top operation while closing and opening; check of seals and lubrication of canvas sliding side guide (only cabrio versions) Check handbrake lever travel and adjust, if necessary Visually inspect condition and wear of front/rear disc brake pads (for versions/markets, where provided) and operation of pad wear...
  • Page 132 Thousands of miles Thousands of kilometres Years Check the auxiliary drive belt tension, and replace if necessary (for dusty roads only) (5) (1) Topping up must be carried out with the fluids indicated in this Owner Handbook and only after checking that the system is undamaged. (2) If the vehicle is used in dusty areas, this filter should be replaced every 15,000 km/9,000 mi.
  • Page 133 (electrolyte) of the conventional LUBRICANTS products, which battery; have been designed and produced visually inspect conditions of the specifically for Fiat cars (see table accessory drive belts; “Capacities” in the “Technical check and, if necessary, change specifications” section). engine oil and replace oil filter;...
  • Page 134 CHECKING LEVELS 167) 168) 47) 48) 1.0 FireFly versions F0S0676 A. Engine coolant - B. Engine oil cap / filler - C. Brake fluid - D. Conventional lead battery - E. Engine oil dipstick attached to the cap - F. Windscreen washer fluid WARNING 167) Never smoke while working in the engine compartment: gas and inflammable vapours may be present, with the risk of fire.
  • Page 135 IMPORTANT 47) When topping up, take care not to mix up the various types of fluids: they are not compatible with each other and could seriously damage the car. 48) The use of products with specifications other than those indicated above could cause damage to the engine not covered by the warranty.
  • Page 136 ENGINE OIL BRAKE FLUID WARNING After adding or changing the oil, let the engine turn over for a few Check the oil level a few minutes (about Check that the fluid is at the maximum 5) after the engine has stopped, with seconds and wait a few minutes after level (the fluid level in the reservoir must turning it off before you check the level.
  • Page 137 REPLACING THE not start the engine and contact your Fiat WARNING CONVENTIONAL Dealership immediately. 51) Prevent brake fluid, which is highly BATTERY 169) The cooling system is pressurised. corrosive, from coming into contact If required, replace the conventional If necessary, only replace the plug with with painted parts.
  • Page 138 (anti-theft, etc.), go to a Fiat Dealership, panel, possibly with the corresponding which will suggest the most suitable devices and advise you whether a higher dedicated message.
  • Page 139 BRAKES RAISING THE a Fiat Dealership to restore correct operation. WINDSCREEN WIPER Depending on the version/market, BLADES the vehicle may be equipped with Lift the windscreen wiper arm and mechanical wear detectors for the position the blade so that it forms a 90°...
  • Page 140 REPLACING THE REAR WINDOW WIPER BLADE Proceed as follows: raise the cover (A) fig. 139 and remove the arm from the car, undoing the nut (B) that fixes it to the pivot pin; correctly position the new arm and tighten the nut fully; lower the cover.
  • Page 141 WHEELS AND TYRES BODYWORK and/or polishes should not be used for cleaning the car. Bird droppings must be washed off immediately and thoroughly as the acid 181) 182) 183) 184) PRESERVING THE Check the pressure of each tyre, they contain is particularly aggressive. BODYWORK including the space-saver spare wheel, Avoid (if at all possible) parking the...
  • Page 142 If high pressure jets or cleaners WARNING In case of water stains do not direct the jet towards the drop are used to wash the vehicle, keep (rings) on the wrapping, remove it, catcher area around the engine oil cap to avoid splashing oil in the engine a distance of at least 40 cm from washing again and drying it with a...
  • Page 143 INTERIOR LEATHER PARTS (for versions/markets, where provided) Regularly check that water is not Use only water and neutral soap to trapped under the mats (due to water clean these parts. Never use alcohol dripping off shoes, umbrellas, etc.), as or alcohol-based products. Before this could cause oxidation of the sheet using a specific product for cleaning metal.
  • Page 144 TECHNICAL SPECIFICATIONS IDENTIFICATION DATA ....143 Everything you may find useful for ENGINE ........145 understanding how your car is made WHEELS........146 and works is contained in this chapter DIMENSIONS ......151 and illustrated with data, tables and WEIGHTS ......... 152 graphics.
  • Page 145 F0S0113 (where provided). second axle (rear). Engine marking. Alternatively, depending on the version, I Engine type. the Fiat Colour Code may be integrated VEHICLE L Bodywork version code. in the type-approval data summary IDENTIFICATION M Spare part number. plate (field N fig. 142).
  • Page 146 ENGINE MARKING It is stamped on the cylinder block and includes the type and the engine serial number.
  • Page 147 ENGINE GENERAL INFORMATION 1.0 FireFly Engine code 46341162 Cycle Otto Number and position of cylinders 3 cylinders in line 70 × 86.5 Piston bore and stroke (mm) Total displacement (cm³) Compression ratio 12:1 Maximum power (EC) (kW) Maximum power (EEC) (HP) 6000 corresponding engine speed (rpm) Maximum torque (EEC) (Nm)
  • Page 148 WHEELS RIMS AND TYRES Pressed steel or alloy rims. Tubeless radial carcass tyres. All approved tyres are listed in the registration document. WARNING If there are any discrepancies between the Owner Handbook and the registration document, take the information from the latter.
  • Page 149 RIMS AND TYRES PROVIDED   Space-saver wheel (*) Versions Wheels Tyres Snow tyres Rim - Tyre 5½J x 14 H2-ET35 175/65 R14 86T (**) 175/65 R14 82Q (M+S) 6J x 15 H2-ET35 185/55 R15 82H (***) 185/55 R15 82Q (M+S) 4.00Bx14 ET43 –...
  • Page 150 COLD TYRE INFLATION PRESSURE (bar) 187) 188) 189) When the tires are warm, the inflation pressure should be + 0.3 bar in relation to the recommended figure. With snow tyres, add +0.2 bar to the pressure value prescribed for other standard tyres. However, recheck that the value is correct with the tyre cold.
  • Page 151 The use of snow chains should be in other models, nor use the space-saver The Fiat Dealership will be happy to compliance with local regulations of wheel of other models on your car. The...
  • Page 152 of unsuitable tyres and wheel caps may cause sudden decrease of tyre pressure. 195) Remember that the road holding qualities of your car also depend on correct tyre pressures. 196) If tyre pressure is too low, it may overheat and be severely damaged as a result.
  • Page 153 DIMENSIONS Dimensions are expressed in mm and refer to the car equipped with its original tyres. Height is measured with car unladen. BOOT CAPACITY: capacity (VDA standards): 185 litres. F0S0605   Versions 1.0 FireFly 3571 2300 1488 (*) 1413 1627 1407 (*) Minor variations in size may be possible, depending on the dimensions of the rims.
  • Page 154 WEIGHTS   Versions 1.0 FireFly Unladen weight (with all fluids, fuel tank filled to 90% and without optional equipment) (kg): Kerb weight (kg): 1055 Payload including the driver (kg) (*) Maximum permitted load (kg) (**) - front axle: – rear axle: - total: 1360 Towable loads (kg)
  • Page 155 REFUELLING 1.0 FireFly Prescribed fuels and original lubricants Fuel tank (petrol - litres): Unleaded petrol with RON no lower than 95 (EN228 specifications) including a reserve of (litres): 50% mixture of distilled water and PARAFLU UP Engine cooling system (litres): Engine sump (litres): SELENIA ECO2 Engine sump and filter (litres):...
  • Page 156 FLUIDS AND LUBRICANTS Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements of the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission specifications.
  • Page 157 Original fluids and Features Specification Applications lubricants Synthetic fluid for brake and clutch systems. TUTELA TOP 4/S Hydraulic brakes and Brake fluid Exceeds specifications 9.55597 or MS.90039 Contractual Technical hydraulic clutch controls F.M.V.S.S. no. 116 DOT Reference N° F005.F15 4, ISO 4925 SAE J1704. Protective agent with antifreeze action with Cooling circuits...
  • Page 158 PERFORMANCE Max. speed in km/h that can be reached after initial car use.   Versions Maximum speed (km/h) 167 (in 5 th gear) 1.0 FireFly...
  • Page 159 FUEL CONSUMPTION AND CO 2 EMISSIONS The fuel consumption and CO 2 emission figures declared by the manufacturer are determined on the basis of the type-approval tests laid down by the applicable standards in the country where the car is registered. The type of route, traffic conditions, weather conditions, driving style, general condition of the car, trim level/equipment/accessories, use of the climate control system, car load, presence of roof racks and other situations that adversely affect the aerodynamics or wind resistance lead to different fuel consumption values than those measured.
  • Page 160 PRESCRIPTIONS FOR HANDLING THE CAR AT THE END OF ITS LIFE FCA has been committed for many years to safeguarding the environment through the constant improvement of its production processes and manufacturing products that are increasingly "eco-compatible". To provide the best possible service in terms of compliance with environmental laws and European Directive 2000/53/EC governing cars at the end of their life, FCA is offering its customers the chance to hand over their car at the end of its life without incurring any additional costs.
  • Page 161 MULTIMEDIA TIPS, CONTROLS AND GENERAL INFORMATION ... 160 This chapter describes the main functions of the Uconnect™ Radio, USB SOURCE ......161 Uconnect™ 5" LIVE, Uconnect™ UCONNECT™ RADIO ....162 5" Nav LIVE, Uconnect™ 7" HD LIVE Uconnect™ 5" Radio LIVE/ NAV and Uconnect™...
  • Page 162 In case of loss of the car radio the system will ask the user to enter increased when receiving traffic passport, contact the Fiat Dealership, the secret code according to the information and news. taking an ID document and the car procedure described in the paragraph ownership documents.
  • Page 163 Immediately stop using the system in the event of a fault. Otherwise the system might be damaged. Contact a Fiat Dealership as soon as possible to have the system repaired. USB SOURCE To activate the USB mode, insert the corresponding device into the USB port on the central tunnel in the car.
  • Page 164 UCONNECT™ RADIO CONTROLS ON FRONT PANEL F0S0711  ...
  • Page 165 FRONT CONTROL PANEL SUMMARY TABLE   Button Functions Mode Ignition Short button press Switching off Short button press Volume adjustment Turning the knob clockwise/anticlockwise Volume activation/deactivation (Mute/Pause) Short button press Exit the selection/return to previous screen Short button press Scrolling the list or tuning to a radio station or select Turning the knob clockwise/anticlockwise BROWSE previous/next track...
  • Page 166 Button Functions Mode Scan of lower frequencies until released/Fast rewind of Long button press USB track Search for next radio station or selection of USB next track Short button press Scan of higher frequencies until released/Fast forward of Long button press USB track Shuffle of USB tracks Short button press...
  • Page 167 CONTROLS ON THE STEERING WHEEL (where provided) The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
  • Page 168   Button Interaction (pressure/rotation) Deactivate/reactivate the microphone during a phone conversation Activation/deactivation of the USB source Pause Activation/deactivation of the radio source Mute function Short press: volume increase/decrease in single steps +/– Long press: volume continuous increase/decrease until released Short press (Radio mode): selection of next/previous station Long press (Radio mode): scan higher/lower frequencies until released Short press (USB mode): selection of previous/next track Long press (USB mode): fast forward/rewind until released...
  • Page 169 SWITCHING THE SYSTEM list of the FM/DAB stations that can be DAB station list ON/OFF received. Press the BROWSE ENTER The system is switched on/off by button/knob to display: AM/FM radio station storage pressing the button/knob the list of all DAB stations; The preset stations are available in all Turn the button/knob clockwise the list of stations filtered by...
  • Page 170 song has been playing for less than 3 Track information display Off, Volume Limited at Power On, seconds. Auto-On Radio. Press the INFO button to select the Radio Menu: Browse FM Station information displayed while playing Fast forward/rewind through tracks List, Traffic Announcement (TA), (Artist, Album, Genre, Name, Folder, Press and hold down the...
  • Page 171 Uconnect™ 5" Radio LIVE/ NAV LIVE Controls on front panel F0S0712  ...
  • Page 172 Front control panel summary table   Button Functions Mode Ignition Short button press Switching off Short button press Volume adjustment Left/right rotation of knob Volume activation/deactivation (Mute/Pause) Short button press Display on/off Short button press Exit the selection/return to previous screen Short button press Settings Short button press...
  • Page 173 Controls on the steering wheel The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
  • Page 174 Controls on steering wheel summary table   Text Interaction (pressure/rotation) Acceptance of incoming call; Answering the second incoming call and putting the active call on hold; Last 10 calls list on the instrument panel (with call browsing active and phone paired only) Rejection of incoming call;...
  • Page 175 Switching the system Audio menu NOTE The Uconnect™ system may on/off not support some USB keys: in this The following adjustments can be The system is switched on/off by case, it will not automatically switch carried out using the "Audio" menu: from "Radio"...
  • Page 176 select the Bluetooth® Media the phone (where provided), the Radio activate the Bluetooth® function on source; may change the track being played if the mobile phone; press the "Add Device" button; the device is connected via USB after press the PHONE button on the front search for Uconnect™...
  • Page 177 consider the first associated device as options "Listen", "Call" or "Ignore" can Start without me. favourite. be selected. Where are you? Are you there yet? NOTE To ensure proper operation Press the button to access the I need directions. after updating the phone software, it is list of SMS messages received by I'm lost.
  • Page 178 Uconnect™ on the www.fiat.it website. Further information about the LIVE experience. Start the Uconnect™ LIVE App eco:Drive™ functions is available in...
  • Page 179 These messages previous trip (the “trip” starts when www.fiat.it or www.driveuconnect.eu. are only displayed with the ignition the ignition key is turned to the MAR key at STOP and when a delay in the...
  • Page 180 system switching off is set. The data the details of the faults of the car which Press the “Nav” button to show the are automatically transferred to the caused a warning light to switch on. navigation map on the display. devices when the engine is switched The car's status can be viewed on both To plan a route, do the following:...
  • Page 181 NOTE: The navigation system volume phones or multimedia players, is not Connect the USB device prepared can only be adjusted during navigation recommended. with the computer. TomTom HOME is when the system provides voice started automatically. To prepare a USB device, proceed as indications.
  • Page 182 Select "Done" when the process is power supply before the update is Global complete. complete. The system cannot be used The following voice commands can be until the update is completed correctly. NOTE Don’t disconnect the USB given after pressing the button on the If the update is interrupted, the system device from the computer while steering wheel...
  • Page 183 Tune in channel DAB Media The following voice commands can be given after pressing the button on the steering wheel Play song... Play album… Play artist… Play genre… Play playlist… Play podcast… Play audiobook… Select the source View Navigation (Uconnect™ 5" Nav LIVE only) The following voice commands can be given after pressing the button on the...
  • Page 184 Uconnect™ 7 HD LIVE/ NAV LIVE Controls on front panel F0S0713  ...
  • Page 185 Front control panel summary table   Button Functions Mode Ignition Short button press Switching off Short button press Volume adjustment Left/right rotation of knob Volume activation/deactivation (Mute/Pause) Short button press Display on/off Short button press Exit the selection/return to previous screen Short button press BACK Scrolling the list or tuning to a radio station...
  • Page 186 Summary table of display buttons   Button Functions Mode Radio Access to the Radio mode Press button Media Source selection: USB, Bluetooth® Press button Phone Phone data display Press button Access the additional functions (e.g. Compass display, Uconnect™ Press button Uconnect™...
  • Page 187 Controls on the steering wheel The controls for the main system functions are present on the steering wheel to make control easier. The activation of the function selected is controlled, in some cases, by how long the button is pressed (short or long press) as described in the table below.
  • Page 188 Controls on steering wheel summary table   Buttons Interaction Acceptance of incoming call Answering the second incoming call and putting the active call on hold Last 10 calls list on the instrument panel (with call browsing active and phone paired only) Activation of voice recognition Interruption of the voice message in order to give a new voice command Interruption of voice recognition...
  • Page 189 Switching the system At the bottom: display of the following After Media mode is selected, the on/off buttons: following information is shown on the "Browse": list of the radio stations The system is switched on/off by display: available; pressing the button/knob At the top: information on the track : selecting previous/next being played and the following graphic...
  • Page 190 "Audio": access to the "Audio vehicle socket first, never from the if the pairing procedure is completed Settings" screen. device. successfully, a screen is displayed. Answer “Yes" to the question to pair NOTE The USB ports handle Track selection the Bluetooth® audio device as data transmission from the Pen Use this function to scroll through and favourite (the device will have priority...
  • Page 191 list of Bluetooth® devices on the display and call contacts from the when prompted by the mobile phone and make a new pairing. registers of previous calls; phone, use its keypad to enter the PIN pair up to 10 phones/audio device code shown on the system display or USB SOURCE to make access and connection easier...
  • Page 192 selecting "Phonebook"; option is usually available on the phone, (*) Only use the numbers listed, selecting "Recent"; in the Bluetooth® connections menu otherwise the system will not take the selecting "Dial"; for a device registered as Uconnect™. message. After enabling this function on the FAVOURITES DO NOT DISTURB FUNCTION mobile phone, it must be disconnected...
  • Page 193 “Radio”; Uconnect™ LIVE services setup as consumption and emissions are "Trip". concerned. using the radio The "Settings" section can be In addition, the data can be saved Uconnect™ LIVE on a USB flash drive, and the data accessed through the icon in SERVICES analysis can be made on your personal...
  • Page 194 Recording and transferring trip On the first connection, you will have Apple CarPlay and data to perform the setup procedure that Android Auto appears on the smartphone. You can The trip data can be stored in the (for versions/markets, where provided) system memory and transferred using only perform this procedure with the The Apple CarPlay and Android Auto...
  • Page 195 Language; Navigation The function is enabled by default. Display; With the Apple CarPlay and Android NOTES Units; Auto applications, the user can choose Bluetooth® is disabled while Apple Voice commands; to use the navigation system on their CarPlay is being used Time &...
  • Page 196 The navigation longer hear voice instructions. You will activated. Otherwise, the button will system can also be updated at the Fiat still receive information such as traffic appear greyed out (and the function will Dealership (the dealer may charge for information and warning sounds.
  • Page 197 Repeat Play song... Voice tutorial Play album… Play artist… Phone Play genre… The following voice commands can be Play playlist… given after pressing the button on the Play podcast… steering wheel Play audiobook… Call... Select the source... Dial... View... Redial Navigation (Uconnect™...
  • Page 198 WARNING 199) Do not carry out other operations during installation and wait for its completion, in order not to affect correct operation of the radio. 200) Where provided, the my:Car™ app is not intended to replace the Owner Handbook of the car.
  • Page 199 MOPAR ® CONNECT PRIVACY MODE activation contact the Fiat Dealership or contact Customer Care. procedure (where provided) Proceed as follows: OFFICIAL TYPE These services let you keep your car take note of the total odometer APPROVALS under control at all times and receive reading;...
  • Page 201 Oil change? The experts recommend PETRONAS Selenia The engine of your car is factory filled with PETRONAS Selenia. This is an engine oil range which satisfies the most advanced international specifications. Its superior technical characteristics allow PETRONAS Selenia to guarantee the highest performance and protection of your engine. The PETRONAS Selenia range includes a number of technologically advanced products: PETRONAS Selenia K Power PETRONAS Selenia Multipower Gas...
  • Page 204 MAINTAIN YOUR VEHICLE IN TIP TOP CONDITIONS WITH Mopar Vehicle Protection offers a series of service contracts that are designed to give all our customers the pleasure of driving their vehicle without any hitch's and concerns. Our product portfolio consists of a wide and flexible range of extended warranty and maintenance plans endorsed by FCA.
  • Page 205 NOTES...
  • Page 207 CONTENTS Display ....38 Fuel consumption ... 157 Doors ....12 Fuel cut-off system .
  • Page 208 Official type approvals ..197 Soft top ....29 phone mode ... . . 169 Spark plugs (type) .
  • Page 209 Settings ....162 System on/off ... . 162 arning lights on panel ..45 Weights .
  • Page 210 FCA Italy S.p.A. - MOPAR - Technical Service Operations - Service Library Largo Senatore G. Agnelli, 3 - 10040 Volvera - Torino (Italy) Print no. 603.85.049 - 03/2020 - 4th Edition...
  • Page 211 At Fiat Service authorised workshops you can find technicians directly trained by us, offering quality and professionalism for all service operations. Fiat workshops are always close to you for the regular servicing operations, season checks and practical recommendations by our experts.
  • Page 212 The data contained in this publication is intended merely as a guide. FCA Italy S.p.A. reserves the right to modify the models and versions described in this booklet at any time for technical and commercial reasons. If you have any further questions please consult your FIAT dealer. Printed in recycled paper without chlorine.

This manual is also suitable for:

500c hybrid 2020

Table of Contents

Save PDF
