FIAT 500 ABARTH

2 0 1 3

O W N E R ' S M A N U A L

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the 500 ABARTH and is the answer not in the manual?

Questions and answers

Summary of Contents for Fiat 500 ABARTH

Page 1 FIAT 500 ABARTH 2 0 1 3 O W N E R ’ S M A N U A L...
Page 2 WARNING! FIAT is a registered trademark of Fiat Group Marketing & Corporate Communication S.p.A., used under license by Driving after drinking can lead to an accident. Your Chrysler Group LLC.
Page 3: Introduction 3
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. . . 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 VEHICLE IDENTIFICATION NUMBER ..7 HOW TO USE THIS MANUAL ....5 VEHICLE MODIFICATIONS/ALTERATIONS .
Page 6: Introduction
- all essentials that are maintaining its validity traditional to our vehicles. • the range of additional services available to FIAT This Owner’s Manual has been prepared with the assis- Group Automobiles customers tance of service and engineering specialists to acquaint NOTE: After reviewing the owner information, it you with the operation and maintenance of your vehicle.
Page 7: How To Use This Manual
INTRODUCTION 5 When it comes to service, remember that your authorized Since the specification of your vehicle depends on the studio knows your vehicle best, has factory-trained tech- items of equipment ordered, certain descriptions and nicians and genuine parts, and cares about your satisfac- illustrations may differ from your vehicle’s equipment.
Page 8 6 INTRODUCTION...
Page 9: Vehicle Identification Number
INTRODUCTION 7 WARNINGS AND CAUTIONS This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire Owners Manual, you may miss important information.
Page 10: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A WORD ABOUT YOUR KEYS ... . .11 ▫ Remote Key Unlock, Driver Door/All Doors 1st Press .......16 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Power Window Switches ....24 ▫ Supplemental Restraint System (SRS) — Air Bags....... .39 LIFTGATE .
Page 13: A Word About Your Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 The vehicle is supplied with a code card containing key A WORD ABOUT YOUR KEYS code numbers to order duplicate keys, and the autho- The key fob contains the Remote Keyless Entry (RKE) rized studio that sold you your new vehicle has the key transmitter with an integrated key.
Page 14 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Before exiting a vehicle, always turn the ignition to the OFF/LOCK position, apply the parking brake, shift the transmission into REVERSE gear, and remove the key fob from the ignition. When leav- ing the vehicle, always lock your vehicle.
Page 15: Locking Doors With A Key
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key-In-Ignition Reminder WARNING! (Continued) Opening the driver’s door when the key is in the ignition • Do not leave children or animals inside parked and the ignition switch position is OFF/LOCK, sounds a vehicles in hot weather.
Page 16: Replacement Keys
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A key which has not been programmed is also Replacement Keys considered an invalid key, even if it is cut to fit the NOTE: Only keys that have been programmed to the ignition switch lock cylinder for that vehicle.
Page 17: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 General Information The Sentry Key® system complies with FCC rules part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...
Page 18: Remote Key Unlock, Driver Door/All Doors 1St Press
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE within five seconds, to unlock all doors and the liftgate. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on. Remote Key Unlock, Driver Door/All Doors 1st Press This feature lets you program the system to unlock either the driver’s door or all doors on the first push of the...
Page 19 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Power Top Open. The roof will stop opening when- WARNING! (Continued) ever the unlock button on the key fob is released, or • Never place any extremities (hands, feet, etc.) near when it reaches the spoiler position the convertible top components, the upper wind- NOTE: If your power convertible top does not open with shield area, the shelf area behind the rear seats, or...
Page 20: To Lock The Doors And Liftgate
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Press the mechanical key release button and release To Lock The Doors And Liftgate the mechanical key to access the battery case screw Press and release the LOCK button on the RKE transmit- located on the side of the Key Fob.
Page 21 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 Key Fob Screw Location Battery Case Removed 3. Take out the battery case. Remove and replace the 4. Refit the battery case inside the Key Fob and turn the battery observing its polarity. screw to lock it into place.
Page 22: General Information
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If your RKE transmitter fails to operate from a normal General Information distance, check for these two conditions: This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the 1.
Page 23 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 WARNING! (Continued) • For personal security and safety in the event of an collision, lock the vehicle doors as you drive as well as when you park and leave the vehicle. • Before exiting a vehicle, always apply the parking brake, shift the transmission into PARK, and re- move the Key Fob from the ignition.
Page 24: Power Door Locks
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks WARNING! (Continued) A power door lock switch is incorporated into the door • Do not leave the Key Fob in or near the vehicle, or handle. Push or pull the handle to lock or unlock the in a location accessible to children, and do not doors and liftgate.
Page 25: To Change Autoclose Setting
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 To change the Autoclose setting in the EVIC, proceed as follows: 1. Briefly press the MENU ESC button “On” or “Off” will flash on the display (according to the previous setting). 2. Press the + or – button for setting. 3.
Page 26: Power Windows
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE POWER WINDOWS Power Window Switches There are single window controls located on the shifter bezel, below the climate controls, which operate the driver and passenger door windows. The window con- trols will operate when the ignition switch is in the ON/RUN position.
Page 27: Liftgate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 down automatically. To cancel the Auto-Down move- To open the liftgate, squeeze the liftgate release handle ment, operate the switch in either the up or down and pull the liftgate open with one fluid motion. direction and release the switch.
Page 28: Occupant Restraints
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS WARNING! Some of the most important safety features in your • Driving with the liftgate open can allow poisonous vehicle are the restraint systems: exhaust gases into your vehicle. You and your •...
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 • All seat belt systems (except the driver’s) include Here are some simple steps you can take to minimize the Automatic Locking Retractors (ALRs), which lock the risk of harm from a deploying air bag: seat belt webbing into position by extending the belt 1.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ride properly buckled up in the rear seat. Never allow 5. If the air bag system in this vehicle needs to be children to slide the shoulder belt behind them or under modified to accommodate a disabled person, contact their arm.
Page 31: Lap/Shoulder Belts
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 and cause a collision that includes you. This can happen WARNING! (Continued) far away from home or on your own street. • Being too close to the steering wheel or instrument Research has shown that seat belts save lives, and they panel during Advanced Front Air Bag deployment can reduce the seriousness of injuries in a collision.
Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Wearing your belt in the wrong place could make • It is dangerous to ride in a cargo area, inside or your injuries in a collision much worse. You might outside of a vehicle.
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 the belt. Slide the latch plate up the webbing as far as 3. When the belt is long enough to fit, insert the latch necessary to allow the belt to go around your lap. plate into the buckle until you hear a “click.”...
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • A belt that is worn under your arm is dangerous. • A belt buckled into the wrong buckle will not Your body could strike the inside surfaces of the protect you properly.
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 4. Position the lap belt across your thighs, below your WARNING! abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is •...
Page 36: Lap/Shoulder Belt Untwisting Procedure
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. 1. Position the latch plate as close as possible to the The belt will automatically retract to its stowed posi- anchor point.
Page 37: Automatic Locking Retractor Mode (Alr) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 Restraints” section. The chart below defines the type of out only the amount of webbing necessary to comfort- feature for each seating position. ably wrap around the occupant’s mid-section. Slide the latch plate into the buckle until you hear a click. Driver Passenger Automatic Locking Retractor Mode (ALR) —...
Page 38: Energy Management Feature
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Engage The Automatic Locking Mode WARNING! 1. Buckle the combination lap and shoulder belt. • The belt and retractor assembly must be replaced if 2. Grasp the shoulder portion and pull downward until the seat belt assembly Automatic Locking Retractor the entire belt is extracted.
Page 39: Seat Belt Pretensioners
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 Seat Belt Pretensioners Enhanced Seat Belt Use Reminder System (BeltAlert®) The seat belts for both front seating positions are equipped with pretensioning devices that are designed to BeltAlert® is a feature intended to remind the driver and remove slack from the seat belt in the event of a collision.
Page 40: Seat Belt Extender
WARNING! BeltAlert® can be enabled or disabled by your autho- Using a seat belt extender when not needed can rized studio. FIAT Group Automobiles S.p.A. does not increase the risk of injury in a collision. Only use recommend deactivating BeltAlert®.
Page 41: Seat Belts And Pregnant Women
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 In addition, the vehicle is equipped with a Supplemental Seat Belts And Pregnant Women Driver Side Knee Air Bag mounted in the instrument We recommend that pregnant women use the seat belts panel below the steering column.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Driver and Front Passenger Advanced Front This vehicle is equipped with Supplemental Side Air Bag Air Bags are certified to the Federal regulations for Inflatable Curtains (SABIC) to protect the driver, front, Advanced Air Bags.
Page 43: Advanced Front Air Bag Features
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Air Bag System Components • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, and Seat Track Position Sensors Your vehicle may be equipped with the following air bag system components: Advanced Front Air Bag Features •...
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE side impact. The SAB are marked with an air bag label WARNING! (Continued) sewn into the outboard side of the front seats. • Do not put anything on or around the air bag covers or attempt to open them manually.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 deploys independently; a left side impact deploys the left air bag only and a right-side impact deploys the right air bag only. Supplemental Side Air Bag Inflatable Curtain (SABIC) Supplemental Side Air Bag Inflatable Curtains (SABIC) may offer side-impact protection to front and rear seat outboard occupants in addition to that provided by the body structure.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system includes side impact sensors that are cali- WARNING! brated to deploy the Seat-Mounted Side Air Bags (SAB) and SABIC during impacts that require air bag occupant • Your vehicle is equipped with left and right protection.
Page 47: Air Bag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Knee Impact Bolsters WARNING! (Continued) The Knee Impact Bolsters help protect the knees of the • Your vehicle is equipped with SABIC air bags, do driver and front passenger, and position the front occu- not have any accessory items installed which will pants for the best interaction with the Advanced Front alter the roof, including adding a sunroof to your...
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ORC deploys the Advanced Front Air Bags, Supplemen- hand, depending on the type and location of impact, tal Driver Side Knee Air Bag, Supplemental Side Air Bag Advanced Front Air Bags may deploy in crashes with Inflatable Curtain (SABIC), Supplemental Seat-Mounted little vehicle front-end damage but that produce a severe Side Air Bags (SAB), and front seat belt pretensioners, as...
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 ON/RUN or START position. If the key is in the OFF/ noted that could affect the air bag system. The diagnos- LOCK position, or not in the ignition, the air bag system tics also record the nature of the malfunction.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE quantity of non-toxic gas is generated to inflate the Advanced Front Air Bags, it signals the inflator units. A Advanced Front Air Bags. Different air bag inflation rates large quantity of non-toxic gas is generated to inflate the are possible, based on several factors, including the Supplemental Driver Side Knee Air Bag.
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 between the occupant and the door. The SAB fully inflate milliseconds (about one-quarter of the time that it takes in about 10 milliseconds. The side air bag moves at a very to blink your eyes) with enough force to injure you if you high speed and with such a high force that it could injure are not belted and seated properly, or if items are you if you are not seated properly, or if items are...
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE power remains intact, depending on the nature of the Carefully check the vehicle for fuel leaks in the engine event, the ORC will determine whether to have the compartment and on the ground near the engine com- Enhanced Accident Response System perform the follow- partment and fuel tank before resetting the system and ing functions:...
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Customer Action Customer Will See 1. Turn ignition OFF. (Turn Signal Switch Must be placed in Neutral State). 2. Turn ignition ON. Left Turn Light is OFF. Right Turn Light BLINKS. 3. Turn Right Turn Signal Switch ON. Right Turn Light is ON SOLID.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If a reset procedure step is not completed within 45 floor. They are not caused by contact with chemicals. seconds, then the turn signal lights will turn off and the They are not permanent and normally heal quickly. reset procedure must be performed again in order to be However, if you haven’t healed significantly within a successful.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 Do not drive your vehicle after the air bags have de- Maintaining Your Air Bag System ployed. If you are involved in another collision, the air bags will not be in place to protect you. WARNING! •...
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light WARNING! (Continued) • Do not attempt to modify any part of your air bag You will want to have the air bags ready to system. The air bag may inflate accidentally or may inflate for your protection in a collision.
Page 57: Event Data Recorder (Edr)
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 NOTE: If the speedometer, tachometer, or any engine • How various systems in your vehicle were operating; related gauges are not working, the Occupant Restraint • Whether or not the driver and passenger safety belts Controller (ORC) may also be disabled.
Page 58: Child Restraints
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To read data recorded by an EDR, special equipment is Children 12 years or younger should ride properly required, and access to the vehicle or the EDR is needed. buckled up in a rear seat, if available. According to crash In addition to the vehicle manufacturer, other parties, statistics, children are safer when properly restrained in such as law enforcement, that have the special equip-...
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 NOTE: WARNING! • For additional information, refer In a collision, an unrestrained child can become a www.seatcheck.org or call 1–866–SEATCHECK. Cana- projectile inside the vehicle. The force required to dian residents should refer to Transport Canada’s hold even an infant on your lap could become so website for additional information: great that you could not hold the child, no matter...
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight or Age Recommended Type of Child Restraint Infants and Children who are two years old or Either an Infant Carrier or a Convertible Toddlers younger and who have not reached the Child Restraint, facing rearward in the rear...
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Infants And Child Restraints reach the highest weight or height allowed by their convertible child seat. Safety experts recommend that children ride rearward- facing in the vehicle until they are two years old or until WARNING! they reach either the height or weight limit of their rear facing child safety seat.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE have outgrown the rear-facing weight or height limit of WARNING! their rear-facing convertible child seat. Children should remain in a forward-facing child seat with a harness for • Improper installation can lead to failure of an as long as possible, up to the highest weight or height infant or child restraint.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Children Too Large For Booster Seats 4. Is the lap part of the belt as low as possible, touching the child’s thighs and not their stomach? Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend 5.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Recommendations For Attaching Child Restraints Restraint Type Combined Use any attachment method shown with an “X” Below Weight of the LATCH – LATCH – Child + Child Lower Anchors Seat Belt + Top Lower Anchors Seat Belt Only Restraint...
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Lower Anchors and Tethers for Children (LATCH) Your vehicle is equipped with the child restraint anchor- Restraint System age system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH- equipped child seats.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH Positions For Installing Child Restraints In This Vehicle Lower Anchorage Symbol 2 anchorages per • seating position Top Tether Anchorage Symbol •...
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 What is the weight limit (child’s weight + 65 lbs (29.5 kg) Use the LATCH anchorage system until weight of the child restraint) for using the the combined weight of the child and the LATCH anchorage system to attach the child child restraint is 65 lbs (29.5 kg).
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Can two child restraints be attached using Never “share” a LATCH anchorage with a common lower LATCH anchorage? two or more child restraints. If the center position does not have dedicated LATCH lower anchorages, use the seat belt to in- stall a child seat in the center position next to a child seat using the LATCH anchor-...
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage sym- bols on the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Locating The LATCH Anchorages Center Seat LATCH WARNING! In addition, there are tether strap anchorages behind each rear seating position located on This vehicle does not have a center seating position. the back of the seat. Do not use the center lower LATCH anchorages to install a child seat in the center of the back seat.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 2. Loosen the adjusters on the lower straps and on the 5. If the child restraint has a tether strap, connect it to the tether strap of the child seat so that you can more top tether anchorage.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Stow An Unused ALR Seatbelt WARNING! When using the LATCH attaching system to install a Improper installation of a child restraint to the child restraint, stow all ALR seat belts that are not being LATCH anchorages can lead to failure of the re- used by other occupants or being used to secure child straint.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Installing Child Restraints Using The Vehicle Seat retract back into the retractor. If it is locked, the ALR will Belt make a clicking noise while the webbing is pulled back into the retractor. For additional information on ALR, The seat belts in the passenger seating positions are refer to the “Automatic Locking Mode”...
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Systems for Installing Child Restraints in this Vehicle...
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to the with the seat belt to attach a forward...
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing A Child Restraint with a Switchable back into the retractor. As the webbing retracts, you Automatic Locking Retractor (ALR) will hear a clicking sound. This means the seat belt is now in the Automatic Locking mode. 1.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 9. Test that the child restraint is installed tightly by 3. Slide the latch plate into the buckle until you hear a pulling back and forth on the child seat at the belt “click.”...
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Any seat belt system will loosen with time, so check the Installing Child Restraints Using The Top Tether belt occasionally, and pull it tight if necessary. Anchorage If the buckle or the cinching latch plate is too close to the 1.
Page 79: Transporting Pets
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 3. Attach the tether strap hook of the child restraint to WARNING! the top tether anchorage as shown in the diagram. • An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.
Page 80: Engine Break-In Recommendations
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Pets should be restrained in the rear seat in pet harnesses “Maintenance Procedures” in “Maintaining Your Ve- or pet carriers that are secured by seat belts. hicle”. ENGINE BREAK-IN RECOMMENDATIONS CAUTION! A long break-in period is not required for the engine and Never use Non-Detergent Oil or Straight Mineral Oil drivetrain (transmission and axle) in your vehicle.
Page 81: Exhaust Gas
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Exhaust Gas WARNING! WARNING! • Do not leave children or animals inside parked vehicles in hot weather. Interior heat build-up may Exhaust gases can injure or kill. They contain carbon cause serious injury or death. monoxide (CO), which is colorless and odorless.
Page 82: Safety Checks You Should Make Inside The Vehicle
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside The WARNING! (Continued) Vehicle • If it is necessary to sit in a parked vehicle with the Seat Belts engine running, adjust your heating or cooling controls to force outside air into the vehicle.
Page 83 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 Air Bag Warning Light Defroster Check operation by selecting the defrost mode and place The light should come on and remain on for the blower control on high speed. You should be able to four to eight seconds as a bulb check when the feel the air directed against the windshield.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Always Pedals that cannot move freely can cause loss of properly reinstall and secure floor mats that have vehicle control and increase the risk of serious per- been removed for cleaning.
Page 85: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 Door Latches Periodic Safety Checks You Should Make Outside The Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS POWER CONVERTIBLE TOP — IF EQUIPPED . .88 ▫ Heated Mirrors — If Equipped ... .95 ▫ Lowering The Power Top....88 ▫...
Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ EZ Entry Feature ..... .106 ▫ Lane Change Assist ....114 ▫...
Page 89 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 ▫ To Vary The Speed Setting ....123 ▫ Wind Buffeting ..... . .131 ▫...
Page 90: Power Convertible Top - If Equipped
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: POWER CONVERTIBLE TOP — IF EQUIPPED On vehicles equipped with a power convertible top, the • The power top buttons will operate when the ignition power convertible top switch is located on the overhead switch is turned to the ACC/ON/RUN position.
Page 91: Raising The Power Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 NOTE: Vertical movement only operates in auto open/ NOTE: Rail lubrication is recommended every 2000 close mode. cycles, or if scratching noises due to dust are present. Refer to “Fluids, Lubes, and Genuine Part” in “Maintain- Raising The Power Top ing Your Vehicle”...
Page 92: Power Convertible Top Relearn Procedure
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE closing to the one-quarter open and three-quarter open CAUTION! (Continued) comfort stops), or if the remote keyless power top • Use care when washing the vehicle, water pressure function is inoperable, or if the trunk lid does not open - directed at the weather strip seals may cause water the following relearn procedure may be necessary.
Page 93: Wind Stop
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 7. CONTINUE to hold the CLOSED button until the top Wind Stop begins to cycle fully open, then release the CLOSED The Wind Stop installs in the backseat area of the vehicle. button. The Wind Stop will not interfere with power top opera- At the end of step 7 the top will automatically cycle to the tion.
Page 94: Automatic Dimming Mirror - If Equipped
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: This feature is disabled when the vehicle is moving in reverse. Adjusting Rearview Mirror Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare Automatic Dimming Mirror from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror.
Page 95: Power Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Power Mirrors The power mirror controls are located on the driver’s door trim panel.
Page 96: Folding Mirrors
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using the mirror control switch, press on any of the four arrows for the direction that you want the mirror to move. WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are.
Page 97: Heated Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature can be activated whenever you turn on the rear window defroster if equipped. Some vehicles may not be equipped with rear window defroster, in this case the heated mirrors will still function as intended.
Page 98: Blue&Me™ Hands-Free Communication
Overview voice recognition system is of the “speaker independent” Windows Mobile™-based FIAT BLUE&ME™ is a per- type. sonal telematic system enabling you to use communica- With this system you can also play your favorite music...
Page 99: The Hands-Free Kit
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 your mobile phone manually and visually using the The Hands-Free Kit steering wheel controls and the instrument panel multi- The basic characteristic of this hands-free kit is voice function display. recognition with Bluetooth® wireless technology. With this system you can make and receive calls safely and securely by using either voice commands or buttons on the steering wheel.
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For further details on the mobile phones supported by list or directly pronouncing the phone number, to BLUE&ME™, refer to section BLUE&ME™ SUPPORTED answer a call and also to answer another incoming MOBILE PHONES. phone call.
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 (LAST CALLS and PHONEBOOK ) and the media • To Answer A Call — you can answer an incoming call player. To activate settings when travelling you can only by pressing the MENU/Phone button on the steering use voice commands.
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After pairing and connecting your phone with the NOTE: Not all mobile phones support the SMS text BLUE&ME™ system, you can make phone calls by message reader function or automatic phonebook trans- speaking keywords or pressing buttons on the steering fer via Bluetooth®.
Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 • To call the SMS text sender using the buttons on the In this way, while you are driving you can play your steering wheel or voice commands. favorite music collections. • To delete individual messages or the entire inbox using •...
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: WARNING! • The media player does not support audio files com- • Operating certain parts of this system while driv- pressed with other formats and DRM (Digital Right ing can distract your attention away from the road, Management) protected audio files.
Page 105: Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 WARNING! (Continued) WARNING! • Keep the User’s Guide in the car: when kept in the • It is dangerous to ride in a cargo area, inside or car, the User’s Guide will be a ready reference for outside of a vehicle.
Page 106: Front Seats Forward/Rearward Adjustment
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Seats Forward/Rearward Adjustment Your vehicle may be equipped with either an adjusting handle or adjusting bar that is located at the front of the seats, near the floor. Adjusting Bar — If Equipped While sitting in the seat, lift up on the adjusting handle or bar and move the seat forward or rearward.
Page 107: Recline Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked.
Page 108: Seat Height Adjustment
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seat Height Adjustment EZ Entry Feature The driver’s seat height can be raised or lowered by The driver and front passenger seats have an EZ entry using a lever, located on the outboard side of the seat. feature for rear seat passengers.
Page 109: Memory Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Lift the seatback upright and push the seat rearward to fore/aft (memory) position on the tracks. This results in its locked position once the rear passengers are seated. the seat back memory being set only – The track will then be locked forward of its last set fore/aft memory posi- Memory Feature tion.
Page 110: Head Restraints
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Head Restraints WARNING! Head restraints are designed to reduce the risk of injury • Persons who are unable to feel pain to the skin by restricting head movement in the event of a rear- because of advanced age, chronic illness, diabetes, impact.
Page 111: To Open And Close The Hood
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Rear Head Restraints To raise the head restraint, pull upward on the head restraint. To lower the head restraint, press the push button, located at the base of the head restraint, and push downward on the head restraint.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Hood Release Lever Hood Safety Latch Location 2. Rotate the safety catch under the front edge of the Lift the hood prop rod that clips to the right side (left side hood, near the center, and raise the hood. when standing in front of the hood) of the engine compartment.
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 WARNING! Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.
Page 114: Lights
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Multifunction Lever The multifunction lever, located on the left side of the steering wheel, controls the operation of the headlights, headlight beam selection, passing light and turn signals. NOTE: The external lights can only be turned on with the ignition in the ON/RUN position.
Page 115: High Beams
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 High Beams Daytime Running Lights — If Equipped To activate the Daytime Running Lights (DRL), rotate the With the low beams activated, push the multi- end of the multifunction lever to the O symbol. function lever towards the instrument panel to NOTE: The low beams and side/taillights will not be on turn on the high beams.
Page 116: Lane Change Assist
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lane Change Assist Tap the lever up or down once, without moving beyond the detent, and the turn signal (right or left) will flash three times then automatically turn off. Follow Me Home/Headlight Delay When this feature is selected the driver can choose to have the headlights remain on for a preset period of time.
Page 117: Interior Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 Deactivation on the right light and press the switch to the left to turn on the left light. Pull the multifunction lever toward the steering wheel and hold it for more than two seconds. CAUTION! Interior Lights Before getting out of the vehicle be sure that the...
Page 118: Front Fog Lights - If Equipped
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When the doors are locked with the Key Fob the lights will turn off. Interior Light Timing (On/Right Position) • When all doors are closed a 15 minute timer is activated. NOTE: The timer is deactivated when the key is moved into the ON/RUN position.
Page 119: Windshield Wipers And Washers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 WINDSHIELD WIPERS AND WASHERS The windshield wiper/washer lever is located on the right side of the steering column. NOTE: The windshield wipers/washers will only oper- ate with the ignition in the ON/RUN position. Front Windshield Wiper Operation There are five different modes of operation for the front windshield wipers.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The Intermittent function only has one detent Front Windshield Washer Operation but wiper delay will vary with changes in vehicle speed. Pull the windshield wiper/washer lever toward the As vehicle speed increases the delay time will decrease. steering wheel to activate the washers.
Page 121: Rear Windshield Wiper
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 CAUTION! (Continued) • Always remove any buildup of snow that prevents the windshield wiper blades from returning to the off position. If the windshield wiper control is turned off and the blades cannot return to the off position, damage to the wiper motor may occur.
Page 122: Tilt Steering Column - If Equipped
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Windshield Washer Operation Push the windshield wiper/washer lever toward the instrument panel to activate the rear washer. Push and hold the lever for more than a half second and the wipers will activate automatically for three cycles after the lever is released.
Page 123: Electronic Speed Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death.
Page 124: To Activate
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control system has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 125: To Deactivate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Pressing the RES (+) button once will result in a 1 mph To Deactivate (1.6 km/h) increase in set speed. Each subsequent tap of A soft tap on the brake pedal, pushing the CANC button, the button results in an increase of 1 mph (1.6 km/h).
Page 126: Rear Park Assist - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using Electronic Speed Control On Hills REAR PARK ASSIST — IF EQUIPPED The transmission may downshift on hills to maintain the The Rear Park Assist system provides an audible indica- vehicle set speed. tion of the distance between the rear fascia/bumper and a detected obstacle when backing up, e.g.
Page 127: Rear Park Assist Alerts
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 corners of the rear fascia/bumper, depending on the Rear Park Assist Alerts location, type and orientation of the obstacle. If an obstacle is behind the vehicle when REVERSE gear If several obstacles are detected, the Rear Park Assist is engaged, an audible alert is activated.
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Audible And Visual Signals Supplied By The Rear Park Assist System SIGNAL MEANING INDICATION Obstacle Distance An obstacle is present within the Audible signal (dashboard loud- sensors’ field of view speaker) • Sound pulses emitted at a rate that increases as the distance de- creases.
Page 129: Failure Indications
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 While audible signals are emitted, the audio system is not The sensors and wiring are tested continuously when the muted. ignition is in the ON/RUN position. Failures are indi- cated immediately if they occur when the system is ON. The audible signal is turned off immediately if the distance increases.
Page 130: Park Assist System Usage Precautions
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Objects such as bicycle carriers, etc., must not be Park Assist System Usage Precautions placed within 12 in (30 cm) from the rear fascia/ NOTE: bumper while driving the vehicle. Failure to do so can •...
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 CAUTION! (Continued) WARNING! (Continued) • The vehicle must be driven slowly when using • Before using ParkSense®, it is strongly recom- Rear Park Assist in order to be able to stop in time mended that the ball mount and hitch ball assem- when an obstacle is detected.
Page 132: Power Sunroof - If Equipped
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof roof switch is located in the overhead • Never leave children in a vehicle with the key in console. the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch.
Page 133: To Open
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 To Open Pinch Protect Feature Press and hold the power sunroof switch rearward for This feature will detect an obstruction in the opening of approximately one second and the sunroof will stop at the sunroof during Express Close operation.
Page 134: Emergency Operation
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Emergency Operation In case of electrical failure the sunroof can be operated with the hex wrench that is located in the glove box. There is a plug located in the rear of the sunroof opening at the center of the vehicle.
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded, the fuse protecting the system will need to be replaced. •...
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. •...
Page 137: Cigar Lighter - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 CIGAR LIGHTER — IF EQUIPPED CAUTION! WARNING! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in When the cigar lighter is in use it becomes very hot. use (i.e., cellular phones, etc.).
Page 138: Cupholders
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For rear passengers, there are cupholders located on the CUPHOLDERS floor between the front driver and passenger seats. For the driver and front passenger, cupholders are lo- cated on the floor console between the front seats. Rear Cupholders Front Cupholders...
Page 139: Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 STORAGE CARGO AREA FEATURES The rear seatbacks have a fold down feature to allow Glove Box Compartment increased cargo capacity. The glove box is located on the right side of the instru- ment panel. Pull outward on the door latch to open the Push down the release button, located at the outboard glove box.
Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Seat Release Buttons Folded Rear Seats...
Page 141: Rear Window Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 REAR WINDOW FEATURES CAUTION! Rear Window Defroster Failure to follow these cautions can cause damage to the heating elements: The rear window defroster button is located in the • Use care when washing the inside of the rear center of the instrument panel, below the radio.
Page 143: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT PANEL FEATURES ..143 ▫ Trip Computer ..... . .161 TURBO BOOST GAUGE .
Page 144 142 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Quick Guide ......178 ▫ CD Player Operation ....204 ▫...
Page 145: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 143 INSTRUMENT PANEL FEATURES 1 — Side Vent 7 — Passenger Air Bag 13 — Storage Compartment 2 — Multifunction Lever – Light Control 8 — Glove Compartment 14 — Shift Lever 3 — Instrument Cluster And Warning Lights 9 —...
Page 146: Turbo Boost Gauge
144 UNDERSTANDING YOUR INSTRUMENT PANEL TURBO BOOST GAUGE Your vehicle is equipped with a boost gauge and inte- grated shift light indicator located to the left of the instrument cluster. The boost gauge indicates the intake manifold pressure relative to barometric pressure. The engine management system in your vehicle intelligently regulates intake manifold pressure based on environ- mental (ambient) and engine operating conditions.
Page 147: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 145 INSTRUMENT CLUSTER...
Page 148: Instrument Cluster Descriptions
146 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Rear Defrost Button INSTRUMENT CLUSTER DESCRIPTIONS 1. Glow Plug Light — If Equipped Press and release this button to turn on the rear window defroster. This indicator will illuminate The Glow Plug light will flash during engine oil when the rear window defroster is on.
Page 149 UNDERSTANDING YOUR INSTRUMENT PANEL 147 6. Park/Headlight ON Indicator / Follow Me Home CAUTION! (Continued) (Headlight Delay) Indicator — If Equipped • Do not use scrapers, sharp instruments, or abrasive This indicator will illuminate when the park window cleaners on the interior surface of the lights or headlights are turned on.
Page 150 148 UNDERSTANDING YOUR INSTRUMENT PANEL Failure, External Light Failure, Fuel Cut-Off Intervention, 11. Seat Belt Reminder Light Fuel Cut-Off Not Available, Parking Sensor Failure. When the ignition switch is first turned to ON/ 9. Air Bag Warning Light RUN, this light will turn on if the driver’s seat belt is unbuckled, a chime will sound.
Page 151 UNDERSTANDING YOUR INSTRUMENT PANEL 149 vehicle is experiencing a problem with the charging should turn off. If the light remains lit with the engine system. Obtain SERVICE IMMEDIATELY. See an autho- running, your vehicle will usually be drivable; however, rized studio. see an authorized studio for service as soon as possible.
Page 152 150 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle placard or tire inflation pressure label, you should Your vehicle has also been equipped with a TPMS determine the proper tire inflation pressure for those malfunction indicator to indicate when the system is not tires.) operating properly.
Page 153 UNDERSTANDING YOUR INSTRUMENT PANEL 151 17. Oil Pressure Warning Light CAUTION! This light indicates low engine oil pressure. The The TPMS has been optimized for the original light should turn on momentarily when the engine is equipment tires and wheels. TPMS pressures and started.
Page 154 152 UNDERSTANDING YOUR INSTRUMENT PANEL Certain conditions, such as a loose or missing gas cap, WARNING! poor fuel quality, etc., may illuminate the MIL after engine start. The vehicle should be serviced if the light A malfunctioning catalytic converter, as referenced stays on through several of your typical driving cycles.
Page 155 UNDERSTANDING YOUR INSTRUMENT PANEL 153 If the light turns on while driving, safely pull over and WARNING! stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the ve- Driving a vehicle with the red brake light on is hicle.
Page 156 154 UNDERSTANDING YOUR INSTRUMENT PANEL The light also will turn on when the parking brake is Activation/Malfunction Indicator Light comes on con- applied with the ignition switch in the ON/RUN posi- tinuously with the engine running, a malfunction has tion. been detected in the ESC system.
Page 157 Anti-Lock the vehicle. Contact a Fiat studio if you still cannot start brakes. If the ABS light does not turn on when the the engine.
Page 158 156 UNDERSTANDING YOUR INSTRUMENT PANEL 26. Temperature Gauge WARNING! The temperature digital scale shows engine coolant tem- A hot engine cooling system is dangerous. You or perature. Any reading within the normal range indicates others could be badly burned by steam or boiling that the engine cooling system is operating satisfactorily.
Page 159 UNDERSTANDING YOUR INSTRUMENT PANEL 157 as it was before the repair or service. If s/he cannot do so, 28. Fuel Gauge / Fuel Door Reminder then the odometer must be set at zero, and a sticker must The fuel door reminder indicates that the fuel filler door be placed in the door jamb stating what the mileage was is located on the right side of the vehicle.
Page 160: Electronic Vehicle Information Center (Evic)
158 UNDERSTANDING YOUR INSTRUMENT PANEL The EVIC consists of the following: ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) • System Status The Electronic Vehicle Information Center (EVIC) fea- • Vehicle Information Warning Message Displays tures a driver-interactive display that is located in the instrument cluster.
Page 161: Electronic Vehicle Information Center (Evic) Setup Menu
UNDERSTANDING YOUR INSTRUMENT PANEL 159 Press the DOWN button to scroll downward The setup menu can be activated by pressing the SET through the displayed menu and the related options ESC button. Single presses on the UP or DOWN or to decrease the value displayed. buttons will scroll through the setup menu op- tions.
Page 162 160 UNDERSTANDING YOUR INSTRUMENT PANEL • Button Volume Selecting An Option Of The Main Menu With Sub- menu • Hill Start 1. Briefly press the SET ESC button to display the first • GSI Shift Up submenu option. • Daylights (D.R.L.) 2.
Page 163: Change Engine Oil Indicator System
UNDERSTANDING YOUR INSTRUMENT PANEL 161 6. Press and hold the SET ESC button to return to the indicator system (after performing the scheduled main- main menu (short hold) or the main screen (longer tenance), refer to the following procedure. hold). 1.
Page 164: Trip Button
162 UNDERSTANDING YOUR INSTRUMENT PANEL • Disconnecting/Reconnecting the battery resets the Trip Button system. The TRIP button, located on the right steering column stalk, can be used to display and to reset the previously NOTE: If the reset operation occurs in the presence of described values.
Page 165: Trip Functions
UNDERSTANDING YOUR INSTRUMENT PANEL 163 • Average speed B Trip Functions Both trip functions are resettable (reset — start of new • Travel time B (driving time). trip). NOTE: “Trip B” functions may be excluded (see “Trip B “Trip A” can be used to display the figures relating to: Data”).
Page 166: Personal Settings
164 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The range depends on several factors: driving Travel Time style, type of route (freeway, residential, mountain roads, This value shows the time elapsed since the last reset. etc.), conditions of use of the car (load, tire pressure, etc.). Trip planning must take into account the above notes.
Page 167 UNDERSTANDING YOUR INSTRUMENT PANEL 165 2. Briefly press the SET ESC button to go back to the speed. Pressing the UP or DOWN buttons menu screen or press and hold the SET ESC (approxi- selects the speed limit. Press SET ESC to confirm mately one second) to go back to the main screen selection.
Page 168 166 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Press the DOWN button. “Off” will flash on the 3. Briefly press the SET ESC button to go back to the display. menu screen, or press and hold the SET ESC button (approximately one second) to go back to the main 3.
Page 169 UNDERSTANDING YOUR INSTRUMENT PANEL 167 4. When accessing the “Time” sub-menu item, briefly • When accessing the “Mode” submenu, briefly press press the SET ESC button and “hours” will flash on the SET ESC button. The previously set display the display. format will flash on the display.
Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Press the UP or DOWN button for setting. See Radio (Repeat Audio Information) With this function active, the EVIC display shows infor- 3. Briefly press the SET ESC button and “month” will mation relevant to the sound system. flash on the display.
Page 171 UNDERSTANDING YOUR INSTRUMENT PANEL 169 If the radio has BLUE&ME™, refer to the appropriate Autoclose “BLUE&ME™ User’s Manual” for further information. With this function active, the doors will automatically lock at when the vehicle’s speed exceeds 15 mph Speed Display (24 km/h).
Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL Units (Set Units) 5. Press the UP or DOWN button for setting. This function may be used to set the measurement unit in 6. Briefly press the SET ESC button to return to the three submenus: “Distance,” “Temperature” and “Fuel sub-menu.
Page 173 UNDERSTANDING YOUR INSTRUMENT PANEL 171 3. When accessing the “Temperature” submenu: briefly To set the required language, proceed as follows: press the SET ESC button. Either “°F” or “°C” will 1. Briefly press the SET ESC button. The previously set appear on the display (according to the previous “language”...
Page 174 SET ESC button Indication) (approximately one second) to go back to the main This function will only be displayed after a FIAT Group screen without storing the settings. Automobiles studio has deactivated the S.B.R. system.
Page 175 UNDERSTANDING YOUR INSTRUMENT PANEL 173 Proceed as follows to switch this function on or off: 2. Press the UP or DOWN button for setting. 1. Briefly press the SET ESC button. “On” or “Off” will 3. Briefly press the SET ESC button to go back to the flash on the display (according to previous setting).
Page 176: Sales Code (Rab) Radio
174 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Briefly press the SET ESC button to go back to the SALES CODE (RAB) RADIO menu screen, or press and hold the button (approxi- mately one second) to go back to the main screen without storing the settings.
Page 177: Suggestions
UNDERSTANDING YOUR INSTRUMENT PANEL 175 If the radio has BLUE&ME™, refer to the appropriate WARNING! “BLUE&ME™ User’s Manual” for further information. Having the volume turned up high can cause the The instructions for use are given below and we recom- driver to not be able to hear important traffic sounds, mend you to read them carefully.
Page 178 176 UNDERSTANDING YOUR INSTRUMENT PANEL • Do not stick labels on the CD surface or write on the recorded surface with pencils or pens. The presence of dirt, scratches or distortions on the CDs could cause skipping and poor sound quality while it is •...
Page 179: Technical Specifications
UNDERSTANDING YOUR INSTRUMENT PANEL 177 copied is often shown in very small letters or is • Two 100 mm diameter full range speakers, one speaker difficult to read on the actual CD cover where it may in each of the rear side panels. be, for example, “COPY CONTROL”, “COPY PRO- •...
Page 180: Understanding Your Instrument Panel ▫ Quick Guide
178 UNDERSTANDING YOUR INSTRUMENT PANEL Quick Guide Radio Controls BUTTON GENERAL FUNCTIONS MODE Short button press Short button press TUNER AM, FM, SAT (if equipped) source Short repeated button press selection A-B-C Cycles A, B, C presets for AM, FM, Short repeated button press SAT (if equipped) MEDIA...
Page 181 UNDERSTANDING YOUR INSTRUMENT PANEL 179 BUTTON GENERAL FUNCTIONS MODE AUDIO Audio adjustments: tones Menu activation: short button press (BASS), high tones (TREBLE), left/ Adjustment type selection: press right balance (BALANCE), front/ rear balance (FADER) Adjustment of values: press (Information Button) Song, Artist, Album, Genre, Playlist, Folder information (if available) in CD, Media Player and Satellite (if so...
Page 182 180 UNDERSTANDING YOUR INSTRUMENT PANEL BUTTON GENERAL FUNCTIONS MODE +Vol/–Vol Volume adjustment Press + button: volume increase Press – button: volume decrease BUTTON RADIO FUNCTIONS MODE Radio Station Search: Automatic search: press buttons • Automatic Search (long press for fast for- •...
Page 183: General Information
UNDERSTANDING YOUR INSTRUMENT PANEL 181 BUTTON CD FUNCTIONS MODE CD ejection Short button press Previous/next track play Short button press CD track fast forward/rewind Long button press Previous/next folder play (for CD- Short button press MP3) • Manual storing of 25 stations (base radio) and 40 General Information stations (if equipped with Satellite): 15 on FM band (5 The radio offers the following functions:...
Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL CD Section CD/MP3 Section • Track selection (forward/backward) • MP3-Info function (ID3-TAG) • Fast forward/rewind through tracks • Folder selection (previous/next) • CD Display function: display of track number and on • Track selection (forward/backward) mp3 discs (song title, artist) and time elapsed since •...
Page 185: Functions And Adjustments
UNDERSTANDING YOUR INSTRUMENT PANEL 183 Audio Section Functions And Adjustments • Mute/pause function Turning The Car Radio On The car radio comes on when the (ON/OFF) button • Soft mute function is pressed briefly. • Loudness function When the car radio is turned on and the on volume limit •...
Page 186 184 UNDERSTANDING YOUR INSTRUMENT PANEL Selecting The Radio Functions Press the button again to deactivate the MUTE function. The volume will gradually increase until it By pressing the TUNER button briefly and repeatedly, reaches the previously set level. the following audio sources can be selected cyclically: When the volume level is changed using the dedicated •...
Page 187 UNDERSTANDING YOUR INSTRUMENT PANEL 185 Use the buttons to scroll through the Menu • USER EQUALIZER — if equipped (customized equal- functions. To change the setting of the selected func- ization adjustment) tion, use the buttons. Tone Adjustment The current status of the selected function appears on the Proceed as follows: display.
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL Balance Adjustment Fader Adjustment Proceed as follows: Proceed as follows: 1. Press AUDIO button. 1. Press AUDIO button. 2. Press the button to set “Balance” in the 2. Press the button to set “Fader” in the AUDIO menu.
Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 Loudness Function — If Equipped To activate the equalizer, use the AUDIO button or to select one of the adjustments: The Loudness function improves the volume of the sound while listening at low volumes, increasing the bass •...
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL User EQ Settings Function — If Equipped 6. To store the setting, press the MENU or AUDIO buttons. To set a personalized equalizer adjustment: Menu 1. Press AUDIO button. MENU Button Functions 2. Use the buttons to set EQ function.
Page 191 UNDERSTANDING YOUR INSTRUMENT PANEL 189 The functions managed by the Menu are: inside the passenger compartment. To activate/ deactivate the function, use the buttons. The wording • Speech Volume “Speed volume” appears on the display, followed by the • Aux Audio Offset current status of the function: •...
Page 192 190 UNDERSTANDING YOUR INSTRUMENT PANEL – If the volume level is between the minimum and Radio Off Function maximum values, the radio will come on at the This function makes it possible to set the radio switching same volume as before it was switched off. off mode by choosing between two methods.
Page 193: Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 191 System Reset Function To select the Radio function when another audio source is being listened to, briefly press the TUNER button. This function is used to restore all settings to the factory values. The options are: Once the Radio mode has been activated, the display will show the name (RBDS stations only) or the frequency of •...
Page 194 192 UNDERSTANDING YOUR INSTRUMENT PANEL Preset Buttons Automatic Tuning The buttons numbered from 1 to 5 are used to set the Briefly press the button to start the automatic following pre-selections: tuning search for the next station that can be received in the selected direction.
Page 195: Siriusxm Satellite Radio - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 193 Stereophonic Broadcasters every NASCAR race, college sports and more. The big- gest and most compelling names in talk with Howard If the incoming signal is weak, the reproduction is Stern and Martha Stewart, laugh-out-loud comedy with automatically switched from Stereo to Mono.
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL SiriusXM Satellite Radio Program Types Re-Subscribe To SiriusXM Satellite Radio Program Types can be selected by pressing the New vehicle purchasers or lessees will receive a free buttons. The Program Type will change to the next limited time subscription to SiriusXM Satellite Radio category and the radio will then tune to first station in with their radio.
Page 197 SIRIUS data services or its use in vehicles. The following are instructions for retrieving the Elec- tronic Serial Number (ESN) from FIAT 500 NAFTA model SiriusXM and all related marks and logos are trademarks radios: of SiriusXM Radio Inc.
Page 198: Cd Player
196 UNDERSTANDING YOUR INSTRUMENT PANEL It is advisable to use original CDs to ensure optimal CD Player playing. If CD-R/RWs are used, we recommend using Introduction good quality media that are burned at the slowest speed This chapter describes the operation of the CD player possible.
Page 199 UNDERSTANDING YOUR INSTRUMENT PANEL 197 Press the button with the radio turned on, to A CD which cannot be read will not be ejected until these activate the motorized CD ejection system. After ejec- functions are over. At the end, with the CD mode tion, the last audio source listened to before playing activated, the display will show the wording “CD Disc the CD will be heard.
Page 200: Cd Mp3 Player
198 UNDERSTANDING YOUR INSTRUMENT PANEL If the track has been played for more than 3 seconds, CD MP3 Player pressing the button, starts the track again from the Introduction beginning. In this case, if you want to play the This chapter describes the operation of the CD MP3 previous track, press the button twice consecu- player.
Page 201 UNDERSTANDING YOUR INSTRUMENT PANEL 199 The specifications and operating conditions for playing Selecting MP3 Sessions With Hybrid Discs MP3 files are the following: If a hybrid disc is inserted (Mixed Mode, Enhanced, CD-Extra) also containing MP3 files, the radio automati- •...
Page 202: Troubleshooting
200 UNDERSTANDING YOUR INSTRUMENT PANEL When one of the ID3-TAG pieces of information is chosen Structure Of The Folders to be displayed (Title, Artist, Album) and this informa- The radio with MP3 player: tion has not been recorded for the track played, the text •...
Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 Source Can Not Be Selected The Duration Of The Mp3 Tracks Is Not Correctly Displayed. Nothing has been loaded. Load the CD or the MP3 CD to be listened to. In some cases (due to the recording mode) the duration of the MP3 tracks can be displayed incorrectly.
Page 204: Ipod®/Usb/Media Player Control - If
202 UNDERSTANDING YOUR INSTRUMENT PANEL iPod®/USB/MEDIA PLAYER CONTROL — IF EQUIPPED This feature allows an iPod® or external USB device to be plugged into the USB port, located in the glove compart- ment. 1 — iPod® Or External USB Device Holder 2 —...
Page 205: Steering Wheel Audio Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 203 The right-hand control is a rocker-type switch with a STEERING WHEEL AUDIO CONTROLS pushbutton in the center and controls the volume and The remote sound system controls are located on the rear mode of the sound system. Pressing the top of the rocker surface of the steering wheel.
Page 206: Radio Operation
204 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Operation Operating Instructions — Hands-Free Phone (If Equipped) Pressing the top of the switch will “Seek” up for the next listenable station and pressing the bottom of the switch Refer to the appropriate Blue&Me™ User’s Manual for will “Seek”...
Page 207: Radio Operation And Mobile Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 205 5. Store the disc in its case after playing. RADIO OPERATION AND MOBILE PHONES Under certain conditions, the mobile phone being on in 6. Do not expose the disc to direct sunlight. your vehicle can cause erratic or noisy performance from 7.
Page 208: Manual Heating And Air Conditioning
206 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Temperature Control Manual Heating And Air Conditioning Rotate this control to regulate the temperature of the air inside the passenger compartment. Rotating the dial to the left into the blue area of the scale indicates cooler temperatures, while rotating to the right into the red area indicates warmer temperatures.
Page 209 UNDERSTANDING YOUR INSTRUMENT PANEL 207 NOTE: • Panel Air is directed through the outlets in the instru- • Continuous use of the Recirculation mode may make ment panel. These outlets can be adjusted to direct the inside air stuffy and window fogging may occur. airflow.
Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL require extra heat to the windshield. This setting is 5. A/C Button good for maintaining comfort while reducing mois- Press this button to engage the Air Conditioning. A light ture on the windshield. will illuminate when the Air Conditioning system is •...
Page 211: Operating Tips Chart
UNDERSTANDING YOUR INSTRUMENT PANEL 209 Operating Tips Chart...
Page 212: Automatic Temperature Control (Atc) - If Equipped
210 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control (ATC) — If Equipped • The Automatic Temperature Control (ATC) allows the driver to select individual comfort settings. • The system provides set-and-forget operation for op- timum comfort and convenience. • The system can be controlled manually, if desired. The ATC system automatically maintains the interior comfort level desired by the driver and passenger.
Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 2. A/C Button reducing moisture on the windshield. Performing this function will cause the ATC to switch into manual mode. Press and release to change the current Air Conditioning 6. Front Defrost (A/C) setting. Performing this function will cause the ATC to switch into manual mode.
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The center instrument panel outlets can be aimed NOTE: so that they are directed toward the rear seat passengers • When in Defrost mode, the Recirculation button will for maximum airflow to the rear. flash if pressed.
Page 215 UNDERSTANDING YOUR INSTRUMENT PANEL 213 3. When the system is set up for your comfort level, it is To provide you with maximum comfort in the Automatic not necessary to change the settings. You will experi- mode during cold start-ups, the blower fan will remain ence the greatest efficiency by simply allowing the on low until the engine warms up.
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL Blower Control The operator can also select the direction of the airflow by selecting one of the following positions. There are 12 fixed blower speeds. Use Panel Mode the blower control up or down buttons to regulate the amount of air forced Air comes from the outlets in the instrument through the system in any mode you...
Page 217 UNDERSTANDING YOUR INSTRUMENT PANEL 215 Floor Mode Defrost Mode Air comes from the floor outlets. A slight amount Air comes from the windshield and side window of air is directed through the defrost and side demister outlets. Use Defrost mode with maxi- window demister outlets.
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL Air Conditioning (A/C) Recirculation Control The Air Conditioning (A/C) button allows the operator to manually activate or deactivate the air conditioning When outside air contains smoke, odors, or system. When in A/C mode with the ATC set to a cool high humidity, or if rapid cooling is desired, temperature, dehumidified air flows through the air you may wish to recirculate interior air by...
Page 219: Operating Tips Chart
UNDERSTANDING YOUR INSTRUMENT PANEL 217 Operating Tips Chart...
Page 220 218 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Summer Operation Windows will fog on the inside when the humidity inside NOTE: In some cases during high temperature opera- the vehicle is high. This often occurs in mild or cool tion, the air conditioning system performance may be temperatures when it’s rainy or humid.
Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air using the high blower setting. This will ensure adequate system lubrication to minimize the possibility of compressor damage when the air conditioning system is started again.
Page 223 STARTING AND OPERATING CONTENTS STARTING PROCEDURES ....224 ▫ Recommended Shift Speeds ....228 ▫...
Page 224 222 STARTING AND OPERATING SPORT MODE ......236 ▫ Tire Identification Number (TIN)...249 BRAKE SYSTEM .
Page 225 STARTING AND OPERATING 223 ▫ Tire Spinning ......261 ▫ E-85 Usage In Non-Flex Fuel Vehicles ..273 ▫...
Page 226: Starting Procedures
224 STARTING AND OPERATING STARTING PROCEDURES Manual Transmission Before starting your vehicle, adjust your seat, adjust both Apply the parking brake, place the shift lever in NEU- inside and outside mirrors, and fasten your seat belts. TRAL, and press the clutch pedal before starting the vehicle.
Page 227: Cold Weather Operation
STARTING AND OPERATING 225 Cold Weather Operation CAUTION! To prevent possible engine damage while starting at low Use of the recommended SAE 5W-40 synthetic en- temperatures, this vehicle will inhibit engine cranking gine oil and adhering to the prescribed oil change when the ambient temperature is less than –22°...
Page 228: If Engine Fails To Start
226 STARTING AND OPERATING 3. If the engine fails to start within 10 seconds, turn the CAUTION! ignition switch to the STOP (OFF/LOCK) position, wait 5 seconds to allow the starter to cool, then repeat • Do not attempt to push or tow your vehicle to get it the “Extended Park Starting”...
Page 229: Manual Transmission
STARTING AND OPERATING 227 shut off to circulate coolant through the turbocharger. Although the pump is rubber-mounted for quiet opera- tion, it is normal to hear it running during this time. MANUAL TRANSMISSION Five-Speed Manual Transmission WARNING! You or others could be injured if you leave the vehicle unattended without having the parking brake fully applied.
Page 230: Recommended Shift Speeds
228 STARTING AND OPERATING Use each gear in numerical order; do not skip a gear. Be Recommended Shift Speeds sure the transmission is in first gear, not third, when To use your manual transmission for optimal fuel starting from a standing position. Damage to the clutch economy, it should be upshifted as listed in the following can result from starting in third gear.
Page 231: Downshifting
STARTING AND OPERATING 229 When turning a corner or driving up a steep grade, Downshifting downshift early so that the engine will not be overbur- Proper downshifting will improve fuel economy and dened. prolong engine life. DRIVING ON SLIPPERY SURFACES CAUTION! Acceleration If you skip a gear while downshifting or downshift...
Page 232: Traction
230 STARTING AND OPERATING 4. Keep tires properly inflated. WARNING! (Continued) 5. Maintain sufficient distance between your vehicle and and possibly have a collision. Accelerate slowly and the vehicle in front of you to avoid a collision in a carefully whenever there is likely to be poor traction sudden stop.
Page 233: Shallow Standing Water
STARTING AND OPERATING 231 WARNING! (Continued) CAUTION! (Continued) Furthermore, flowing and/or rising water can carry • Determine the condition of the road or the path your vehicle away swiftly. Failure to follow this that is under water and if there are any obstacles in warning may result in injuries that are serious or the way before driving through the standing water.
Page 234: Power Steering
232 STARTING AND OPERATING CAUTION! (Continued) WARNING! (Continued) • Getting water inside your vehicle’s engine can • Getting water inside your vehicle’s engine can cause it to lock up and stall out, and cause serious cause it to lock up and stall out, and leave you internal damage to the engine.
Page 235 STARTING AND OPERATING 233 Refer to “Electronic Vehicle Information (EVIC)” in “Un- WARNING! derstanding Your Instrument Panel” for further informa- tion. Continued operation with reduced or no power steer- ing assist could pose a safety risk to yourself and If the Steering icon is displayed and the “SERVICE others.
Page 236: Parking Brake
234 STARTING AND OPERATING PARKING BRAKE Before leaving the vehicle, make sure that the parking brake is fully applied. Also, be certain to leave manual transmission in REVERSE or first gear. The parking brake lever is located in the center console. To apply the parking brake, pull the lever up as firmly as possible.
Page 237 STARTING AND OPERATING 235 should always be applied whenever the driver is not in WARNING! (Continued) the vehicle. • Be sure the parking brake is fully disengaged before driving; failure to do so can lead to brake WARNING! failure and a collision. •...
Page 238: Starting And Operating Sport Mode
236 STARTING AND OPERATING SPORT MODE In Sport mode, the engine is more responsive to the throttle pedal, and provides more maximum torque by increasing turbo boost pressure. Steering feedback is improved, and steering effort is slightly higher. This driving mode is useful for spirited driving. 1.
Page 239: Brake System
STARTING AND OPERATING 237 BRAKE SYSTEM Four-Wheel Anti-Lock Brake System (ABS) In the event power assist is lost for any reason (for The Four-Wheel ABS is designed to aid the driver in example; repeated brake applications with the engine maintaining vehicle control under adverse braking con- off), the brakes will still function.
Page 240: Electronic Brake Control System
238 STARTING AND OPERATING When you are in a severe braking condition involving the WARNING! use of the ABS, you will experience some pedal drop as the vehicle comes to a stop. This is the result of the • Pumping the Anti-Lock Brakes will diminish their system reverting to the base brake system.
Page 241: Anti-Lock Brake System (Abs)
STARTING AND OPERATING 239 “pump” the brakes). Do not reduce brake pedal pressure Anti-Lock Brake System (ABS) unless braking is no longer desired. Once the brake pedal This system aids the driver in maintaining vehicle control is released, the BAS is deactivated. under adverse braking conditions.
Page 242: Traction Control System (Tcs)
240 STARTING AND OPERATING period of time after the driver takes his foot off the brake Traction Control System (TCS) pedal. If the driver does not apply the throttle during this This system monitors the amount of wheel spin of each of short period of time, the system will release brake the driven wheels.
Page 243: Electronic Stability Control (Esc)
STARTING AND OPERATING 241 Electronic Stability Control (ESC) WARNING! This system enhances directional control and stability of There may be situations on minor hills (i.e., less than the vehicle under various driving conditions. ESC cor- 2.5%), with a loaded vehicle, or while pulling a rects for oversteering or understeering of the vehicle by trailer, when the system will not activate and slight applying the brake of the appropriate wheel to assist in...
Page 244 242 STARTING AND OPERATING WARNING! The Electronic Stability Control (ESC) cannot pre- vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ESC cannot prevent all accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 245 STARTING AND OPERATING 243 ESC Operating Modes To turn ESC on again, momentarily press the switch again. This will restore the normal ESC On mode of The ESC system has three available operating modes. operation. Full On WARNING! This is the normal operating mode for ESC. Whenever the vehicle is started, the ESC system will be in On mode.
Page 246: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
244 STARTING AND OPERATING OFF switch for five seconds. After five seconds, the ESC (ACC/ON/RUN) position for four seconds. If the ESC OFF Indicator Light will illuminate, and the “ESC OFF” Activation/Malfunction Indicator Light comes on con- message will display in the EVIC. To turn ESC ON again, tinuously with the engine running, a malfunction has momentarily press the ESC OFF switch.
Page 247: Tire Safety Information
STARTING AND OPERATING 245 NOTE: TIRE SAFETY INFORMATION Tire Markings • The ESC Activation/Malfunction Indicator Light and the ESC OFF Indicator Light come on momentarily each time the ignition switch is turned ON. • Each time the ignition is turned ON, the ESC system will be ON even if it was turned off previously.
Page 248 246 STARTING AND OPERATING NOTE: • Temporary spare tires are high-pressure compact spares designed for temporary emergency use only. • P (Passenger) - Metric tire sizing is based on U.S. Tires designed to this standard have the letter “T” or design standards.
Page 249 STARTING AND OPERATING 247 Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 250 248 STARTING AND OPERATING EXAMPLE: R = Construction code — R means radial construction — D means diagonal or bias construction 15 = Rim diameter in inches (in) Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol —...
Page 251: Tire Identification Number (Tin)
STARTING AND OPERATING 249 EXAMPLE: Load Identification: ..blank..= Absence of any text on the sidewall of the tire indicates a Standard Load (SL) tire Extra Load (XL) = Extra load (or reinforced) tire Light Load (LL) = Light load tire C, D, E, F, G = Load range associated with the maximum load a tire can carry at a specified pressure Maximum Load—...
Page 252 250 STARTING AND OPERATING EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation — This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)
Page 253: Tire Terminology And Definitions
STARTING AND OPERATING 251 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 254: Tire Loading And Tire Pressure
252 STARTING AND OPERATING Tire And Loading Information Placard Tire Loading And Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire Placard Location...
Page 255 STARTING AND OPERATING 253 NOTE: Under a maximum loaded vehicle condition, This placard tells you important information about gross axle weight ratings (GAWRs) for the front and rear the: axles must not be exceeded. For further information on 1) Number of people that can be carried in the ve- GAWRs, vehicle loading, and trailer towing, refer to hicle.
Page 256 254 STARTING AND OPERATING 2. Determine the combined weight of the driver and 6. If your vehicle will be towing a trailer, load from your passengers that will be riding in your vehicle. trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available 3.
Page 257 STARTING AND OPERATING 255...
Page 258: Tires - General Information
256 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 259: Tire Inflation Pressures
STARTING AND OPERATING 257 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the vehicle driver’s side B-Pillar. to the other can cause the vehicle to drift to the right or left.
Page 260: Tire Pressures For High Speed Operation
258 STARTING AND OPERATING defined as the tire pressure after the vehicle has not been Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) driven for at least three hours, or driven less than 1 mile during operation.
Page 261: Radial Ply Tires
STARTING AND OPERATING 259 Tire Repair WARNING! If your tire becomes damaged, it may be repaired if it High speed driving with your vehicle under maxi- meets the following criteria: mum load is dangerous. The added strain on your • The tire has not been driven on when flat. tires could cause them to fail.
Page 262: All Season Tires - If Equipped
260 STARTING AND OPERATING Snow tires generally have lower speed ratings than what All Season Tires – If Equipped was originally equipped with your vehicle and should All Season tires provide traction for all seasons (spring, not be operated at sustained speeds over 75 mph summer, fall and winter).
Page 263: Spare Tire Matching Original Equipped Tire And Wheel - If Equipped
STARTING AND OPERATING 261 sidewall. Use summer tires only in sets of four; failure to Refer to “Freeing A Stuck Vehicle” in “What To Do In do so may adversely affect the safety and handling of Emergencies” for further information. your vehicle.
Page 264: Life Of Tire
262 STARTING AND OPERATING tread wear indicators, the tire should be replaced. Refer to “Replacement Tires” in this section for further infor- mation. Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: •...
Page 265: Replacement Tires
STARTING AND OPERATING 263 Information placard or the Vehicle Certification Label for WARNING! the size designation of your tire. The Load Index and Speed Symbol for your tire will be found on the original Tires and the spare tire should be replaced after six equipment tire sidewall.
Page 266 264 STARTING AND OPERATING WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 267: Tire Chains (Traction Devices)
STARTING AND OPERATING 265 These effects can be reduced by timely rotation of tires. TIRE CHAINS (TRACTION DEVICES) The benefits of rotation are especially worthwhile with Due to limited clearance, tire chains or traction devices aggressive tread designs such as those on all season type are not recommended.
Page 268: Tire Pressure Monitoring System (Tpms)
266 STARTING AND OPERATING The suggested rotation method is the “rearward cross” TIRE PRESSURE MONITORING SYSTEM (TPMS) shown in the following diagram. This rotation pattern The Tire Pressure Monitor System (TPMS) will warn the does not apply to some directional tires that must not be driver of a low tire pressure based on the vehicle recom- reversed.
Page 269 STARTING AND OPERATING 267 also increase as the vehicle is driven - this is normal and driven for up to 20 minutes above 15 mph (24 km/h) in there should be no adjustment for this increased pres- order for the TPMS to receive this information. sure.
Page 270 268 STARTING AND OPERATING NOTE: CAUTION! • The TPMS is not intended to replace normal tire care • The TPMS has been optimized for the original and maintenance, or to provide warning of a tire equipment tires and wheels. TPMS pressures and failure or condition.
Page 271: Base System
STARTING AND OPERATING 269 • Seasonal temperature changes will affect tire pressure, The TPMS consists of the following components: and the TPMS will monitor the actual tire pressure in • Receiver Module the tire. • Four Tire Pressure Monitoring Sensors Base System •...
Page 272 270 STARTING AND OPERATING vehicle may need to be driven for up to 20 minutes above 3. Snow or ice around the wheels or wheel housings. 15 mph (24 km/h) to receive this information. 4. Using tire chains on the vehicle. Check TPMS Warnings 5.
Page 273: General Information
STARTING AND OPERATING 271 Monitoring Telltale Light will flash on and off for 75 Enhanced TPM System seconds and then remain on solid and the Tire When the vehicle is equipped with an enhanced TPM Pressure Monitoring Unavailable message will be system, the driver can view text messages showing the displayed.
Page 274: Fuel Requirements
272 STARTING AND OPERATING The tire pressure sensors are covered under one of the Light spark knock at low engine speeds is not harmful to following licenses: your engine. However, continued heavy spark knock at high speeds can cause damage and immediate service is United States MRXC4W4MA4 required.
Page 275: Gasoline/Oxygenate Blends
STARTING AND OPERATING 273 The manufacturer supports the use of reformulated gaso- Problems that result from using methanol/gasoline lines. Properly blended reformulated gasolines will pro- blends are not the responsibility of the manufacturer. vide excellent performance and durability of engine and While MTBE is an oxygenate made from Methanol, it fuel system components.
Page 276: Mmt In Gasoline
274 STARTING AND OPERATING To fix a Non-FFV vehicle inadvertently fueled once with without MMT be used in your vehicle. The MMT content E-85 perform the following: of gasoline may not be indicated on the gasoline pump, therefore, you should ask your gasoline retailer whether •...
Page 277: Fuel System Cautions
STARTING AND OPERATING 275 Fuel System Cautions CAUTION! (Continued) • The use of fuel additives, which are now being CAUTION! sold as octane enhancers, is not recommended. Follow these guidelines to maintain your vehicle’s Most of these products contain high concentrations performance: of methanol.
Page 278: Carbon Monoxide Warnings
276 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! (Continued) • Guard against carbon monoxide with proper main- WARNING! tenance. Have the exhaust system inspected every Carbon monoxide (CO) in exhaust gases is deadly. time the vehicle is raised. Have any abnormal Follow the precautions below to prevent carbon conditions repaired promptly.
Page 279: Adding Fuel
STARTING AND OPERATING 277 ADDING FUEL CAUTION! Fuel Filler Cap (Gas Cap) • Damage to the fuel system or emission control The gas cap is located on the passenger side of the system could result from using an improper fuel vehicle.
Page 280: Loose Fuel Filler Cap Message
278 STARTING AND OPERATING • If the gas cap is not tightened properly, the MIL will WARNING! come on. Be sure the gas cap is tightened every time the vehicle is refueled. • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank is Loose Fuel Filler Cap Message being filled.
Page 281: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 279 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Manual Transmission Flat Tow NONE Transmission in NEUTRAL Dolly Tow Front Rear NOT ALLOWED On Trailer NOTE: Vehicles equipped with manual transmissions CAUTION! may be recreationally towed (flat towed) at any legal highway speed, for any distance, if the manual transmis-...
Page 283 WHAT TO DO IN EMERGENCIES CONTENTS HAZARD WARNING FLASHERS ...282 ▫ Preparations For Jacking ....294 IF YOUR ENGINE OVERHEATS .
Page 284: Hazard Warning Flashers
282 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel below the radio. potential for overheating by taking the appropriate ac- tion.
Page 285: Tirefit Kit - If Equipped
WHAT TO DO IN EMERGENCIES 283 CAUTION! WARNING! (Continued) to cool. Never try to open a cooling system pressure Driving with a hot cooling system could damage cap when the radiator or coolant bottle is hot. your vehicle. If the pointer rises to the H (red) mark, the instrument cluster will sound a chime.
Page 286: Tirefit Storage
284 WHAT TO DO IN EMERGENCIES TIREFIT Storage TIREFIT Kit Components And Operation The TIREFIT kit is located under the front driver’s seat. TIREFIT Components TIREFIT Kit Location 1. Sealant Bottle 2. Deflation Button 3. Pressure Gauge...
Page 287: Tirefit Usage Precautions
WHAT TO DO IN EMERGENCIES 285 4. Power Button • The Sealant Bottle (1) and Sealant Hose (6) are a one tire application use. After each use, always replace 5. Mode Select Knob these components immediately at an authorized stu- 6.
Page 288 286 WHAT TO DO IN EMERGENCIES Air Mode when inflating such items to avoid injecting WARNING! (Continued) sealant into them. The TIREFIT Sealant is only in- – If the tire has any damage from driving with tended to seal punctures less than ¼ in (6 mm) extremely low tire pressure.
Page 289: Sealing A Tire With Tirefit
WHAT TO DO IN EMERGENCIES 287 Sealing A Tire With TIREFIT WARNING! (Continued) (A) Whenever You Stop To Use TIREFIT: • Take care not to allow the contents of TIREFIT to come in contact with hair, eyes, or clothing. TIRE- 1.
Page 290 288 WHAT TO DO IN EMERGENCIES (B) Setting Up To Use TIREFIT: (C) Injecting TIREFIT Sealant Into The Deflated Tire: 1. Turn the Mode Select Knob (5) to the Sealant Mode position. • Always start the engine before turning ON the TIRE- FIT kit.
Page 291 WHAT TO DO IN EMERGENCIES 289 the Sealant Hose (6) to the valve stem. Check that the If the sealant (white fluid) does flow through the Mode Select Knob (5) is in the Sealant Mode position Sealant Hose (6): and not Air Mode. Press the Power Button (4) to turn 1.
Page 292 290 WHAT TO DO IN EMERGENCIES If the tire does not inflate to at least 26 psi (1.8 Bar) storage location. Quickly proceed to (D) “Drive Ve- pressure within 15 minutes: hicle”. • The tire is too badly damaged. Do not attempt to drive CAUTION! the vehicle further.
Page 293 WHAT TO DO IN EMERGENCIES 291 3. Uncoil the Air Pump Hose (7) (black in color) and WARNING! screw the fitting at the end of hose (7) onto the valve stem. TIREFIT is not a permanent flat tire repair. Have the tire inspected and repaired or replaced after using 4.
Page 294 292 WHAT TO DO IN EMERGENCIES 2. Disconnect the TIREFIT kit from the valve stem, (F) Sealant Bottle And Hose Replacement: reinstall the cap on the valve stem and unplug from 12 1. Uncoil the Sealant Hose (6) (clear in color). Volt outlet.
Page 295: Jacking And Tire Changing - If Equipped
WHAT TO DO IN EMERGENCIES 293 6. Verify that the cap is installed on the fitting at the end WARNING! (Continued) of the Sealant Hose (6) and return the hose to its • Being under a jacked-up vehicle is dangerous. The storage area (located on the bottom of the air pump).
Page 296: Jack Location
294 WHAT TO DO IN EMERGENCIES Jack Location Preparations For Jacking The jack and jack wrench tool are stowed in a bag under 1. Park the vehicle on a firm level surface, avoiding ice or the front driver’s seat. slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic, pull far enough off...
Page 297: Jacking Instructions
WHAT TO DO IN EMERGENCIES 295 5. Turn Off the ignition. Jacking Instructions WARNING! Block both the front and rear of the Carefully follow these tire changing warnings to wheel diagonally opposite the jacking help prevent personal injury or damage to your position.
Page 298 296 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a jack. • Do not get under the vehicle when it is on a jack. If you need to get under a raised vehicle, take it to a Jack Warning Label service center where it can be raised on a lift.
Page 299 WHAT TO DO IN EMERGENCIES 297 2. Loosen, but do not remove, the wheel bolts by turning them to the left one turn while the wheel is still on the ground. NOTE: There are front and rear jacking locations on each side of the body (as indicated by the triangular lift point symbol on the sill molding).
Page 300 298 WHAT TO DO IN EMERGENCIES 3. Turn the jack screw to the left until the jack can be WARNING! placed under the jacking location. Once the jack is positioned, turn the jack screw to the right until the Raising the vehicle higher than necessary can make jack head is properly engaged with the lift area closest the vehicle less stable.
Page 301: Jump-Starting Procedure
WHAT TO DO IN EMERGENCIES 299 that you have tightened the bolts correctly, have them WARNING! checked with a torque wrench by your authorized studio or service station. To avoid the risk of forcing the vehicle off the jack, do not fully tighten the wheel bolts until the vehicle 9.
Page 302: Preparations For Jump-Start
300 WHAT TO DO IN EMERGENCIES NOTE: When using a portable battery booster pack, Preparations For Jump-Start follow the manufacturer’s operating instructions and The battery in your vehicle is located on the left side of precautions. the engine compartment. WARNING! Do not attempt jump-starting if the battery is frozen.
Page 303 WHAT TO DO IN EMERGENCIES 301 2. Turn off the heater, radio, and all unnecessary electri- WARNING! cal accessories. • Take care to avoid the radiator cooling fan when- 3. Remove the protective cover over the remote positive ever the hood is raised. It can start anytime the (+) battery post.
Page 304: Jump-Starting Procedure
302 WHAT TO DO IN EMERGENCIES 2. Connect the opposite end of the positive (+) jumper Jump-Starting Procedure cable to the positive (+) post of the booster battery. WARNING! 3. Connect the negative end (-) of the jumper cable to the negative (-) post of the booster battery.
Page 305 WHAT TO DO IN EMERGENCIES 303 5. Start the engine in the vehicle that has the booster If frequent jump-starting is required to start your vehicle, battery, let the engine idle a few minutes, and then you should have the battery and charging system in- start the engine in the vehicle with the discharged spected at your authorized studio.
Page 306: Freeing A Stuck Vehicle
304 WHAT TO DO IN EMERGENCIES NOTE: Press the ESC Off switch, to place the Electronic FREEING A STUCK VEHICLE Stability Control (ESC) system in Partial Off mode, If your vehicle becomes stuck in mud, sand or snow, it before rocking the vehicle. Refer to “Electronic Brake can often be moved using a rocking motion.
Page 307: Towing A Disabled Vehicle
WHAT TO DO IN EMERGENCIES 305 TOWING A DISABLED VEHICLE WARNING! This section describes procedures for towing a disabled Fast spinning tires can be dangerous. Forces gener- vehicle using a commercial wrecker service. ated by excessive wheel speeds may cause damage, or even failure, of the axle and tires.
Page 308: Manual Transmission
306 WHAT TO DO IN EMERGENCIES Proper towing or lifting equipment is required to prevent Manual Transmission damage to your vehicle. Use only tow bars and other • Vehicle can be flat towed (all four wheels on the equipment designed for this purpose, following equip- ground) with the transmission in NEUTRAL.
Page 309 MAINTAINING YOUR VEHICLE CONTENTS ENGINE COMPARTMENT — 1.4L TURBO ..309 ▫ Maintenance-Free Battery ....317 ONBOARD DIAGNOSTIC SYSTEM — OBD II . .310 ▫ Air Conditioner Maintenance ... . .318 EMISSIONS INSPECTION AND MAINTENANCE ▫...
Page 310 308 MAINTAINING YOUR VEHICLE ▫ Appearance Care And Protection From ▫ Front Turn Signal, Parking And Daytime Running Corrosion ......336 Lamps .
Page 311: Engine Compartment - 1.4L Turbo
MAINTAINING YOUR VEHICLE 309 ENGINE COMPARTMENT — 1.4L TURBO 1 — Engine Coolant Reservoir 5 — Battery 2 — Engine Oil Dipstick 6 — Engine Oil Fill 3 — Brake Fluid Reservoir 7 — Washer Fluid Reservoir 4 — Front Distribution Unit (Fuses)
Page 312: Onboard Diagnostic System - Obd Ii
310 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and drivability.
Page 313 MAINTAINING YOUR VEHICLE 311 Indicator Light (MIL)” is functioning and is not on when 2. As soon as you cycle the ignition switch to the ON the engine is running, and that the OBD II system is position, you will see the MIL symbol come on as part ready for testing.
Page 314: Replacement Parts
312 MAINTAINING YOUR VEHICLE you may need to do nothing more than drive your STUDIO SERVICE vehicle as you normally would in order for your OBD II Your authorized studio has the qualified service person- system to update. A recheck with the above test routine nel, special tools, and equipment to perform all service may then indicate that the system is now ready.
Page 315: Maintenance Procedures
MAINTAINING YOUR VEHICLE 313 MAINTENANCE PROCEDURES CAUTION! (Continued) The pages that follow contain the required maintenance • Your vehicle has been built with improved fluids services determined by the engineers who designed your that protect the performance and durability of your vehicle.
Page 316 314 MAINTAINING YOUR VEHICLE fully warmed engine is shut off. Do not check oil level CAUTION! before starting the engine after it has sat overnight. Checking engine oil level when the engine is cold will Do not overfill the engine with oil. Overfilling the give you an incorrect reading.
Page 317 MAINTAINING YOUR VEHICLE 315 Engine Oil Selection engine oil filler cap location, refer to “Engine Compart- ment” in “Maintaining Your Vehicle” for further informa- For best performance and maximum protection for tur- tion. bocharged engines under all types of operating condi- tions, the manufacturer recommends synthetic engine Materials Added To Engine Oil oils that are API Certified and meet the requirements of...
Page 318: Engine Oil Filter
316 MAINTAINING YOUR VEHICLE Engine Oil Filter WARNING! The engine oil filter should be replaced with a new filter The air induction system (air cleaner, hoses, etc.) can at every engine oil change. provide a measure of protection in the case of engine Engine Oil Filter Selection backfire.
Page 319: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 317 Maintenance-Free Battery WARNING! (Continued) Your vehicle is equipped with a maintenance-free battery. • Battery gas is flammable and explosive. Keep You will never have to add water, nor is periodic main- flame or sparks away from the battery. Do not use tenance required.
Page 320: Air Conditioner Maintenance
318 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance CAUTION! For best possible performance, your air conditioner • It is essential when replacing the cables on the should be checked and serviced by an authorized studio battery that the positive cable is attached to the at the start of each warm season.
Page 321 MAINTAINING YOUR VEHICLE 319 Protection Agency and is an ozone-saving product. How- WARNING! ever, the manufacturer recommends that air conditioning service be performed by authorized studio or other • Use only refrigerants and compressor lubricants service facilities using recovery and recycling equipment. approved by the manufacturer for your air condi- tioning system.
Page 322 320 MAINTAINING YOUR VEHICLE 1. Remove the T20 Torx screw that secures the passenger side console closeout cover. Console Closeout panel 3. Remove the two 5.5mm screws (1 and 2) that secure the particulate air filter cover to the HVAC housing. T20 Torx screw 2.
Page 323 MAINTAINING YOUR VEHICLE 321 4. Remove the A/C air filter by pulling it straight out of A/C Air Filter the housing. Take note of the air filter position indica- 5. Install the A/C air filter with the air filter position tors.
Page 324: Body Lubrication
322 MAINTAINING YOUR VEHICLE be wiped clean to remove dust and grit; after lubricating CAUTION! excess oil and grease should be removed. Particular attention should also be given to hood latching compo- The A/C air filter is identified with an arrow to nents to ensure proper function.
Page 325 MAINTAINING YOUR VEHICLE 323 Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades. Always use washer fluid when using the wipers to remove salt or dirt from a dry windshield. Avoid using the wiper blades to remove frost or ice from the windshield.
Page 326: Adding Washer Fluid
324 MAINTAINING YOUR VEHICLE 3. Grab the bottom of the wiper blade and rotate it 4. Install the wiper blade pivot pin into the wiper blade forward to unsnap the blade pivot pin from the wiper holder at the end of the wiper arm, and firmly press blade holder.
Page 327: Exhaust System
MAINTAINING YOUR VEHICLE 325 exhaust system inspected each time the vehicle is raised WARNING! (Continued) for lubrication or oil change. Replace as required. must be exercised when filling or working around the washer solution. WARNING! Exhaust System • Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and The best protection against carbon monoxide entry into odorless.
Page 328 326 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure • The catalytic converter requires the use of un- proper catalyst operation and prevent possible catalyst leaded fuel only.
Page 329: Cooling System
MAINTAINING YOUR VEHICLE 327 To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in • When working near the radiator cooling fan, motion.
Page 330 328 MAINTAINING YOUR VEHICLE Coolant Checks Cooling System – Drain, Flush, And Refill Check engine coolant (antifreeze) protection every 12 If the engine coolant (antifreeze) is dirty or contains months (before the onset of freezing weather, where visible sediment, have an authorized studio clean and applicable).
Page 331 MAINTAINING YOUR VEHICLE 329 CAUTION! CAUTION! (Continued) • Do not use water alone or alcohol-based engine • Mixing of engine coolant (antifreeze) other than coolant (antifreeze) products. Do not use additional specified Organic Additive Technology (OAT) en- rust inhibitors or antirust products, as they may not gine coolant (antifreeze), may result in engine be compatible with the radiator engine coolant and damage and may decrease corrosion protection.
Page 332 330 MAINTAINING YOUR VEHICLE you use the same engine coolant (OAT coolant conform- (antifreeze) solution. The use of lower quality water ing to MS-12106) throughout the life of your vehicle. will reduce the amount of corrosion protection in the engine cooling system. Please review these recommendations for using Organic Additive Technology (OAT) engine coolant (antifreeze) Please note that it is the owner’s responsibility to main-...
Page 333 MAINTAINING YOUR VEHICLE 331 The cap should be inspected and cleaned if there is any Disposal Of Used Engine Coolant accumulation of foreign material on the sealing surfaces. Used ethylene glycol-based engine coolant (antifreeze) is a regulated substance requiring proper disposal. Check WARNING! with your local authorities to determine the disposal rules for your community.
Page 334 332 MAINTAINING YOUR VEHICLE As long as the engine operating temperature is satisfac- • Do not overfill the coolant expansion bottle. tory, the coolant bottle need only be checked once a • Check the coolant freeze point in the radiator and in the month.
Page 335: Brake System
MAINTAINING YOUR VEHICLE 333 • Keep the front of the radiator clean. If your vehicle is WARNING! equipped with air conditioning, keep the front of the condenser clean. Riding the brakes can lead to brake failure and possibly a collision. Driving with your foot resting or •...
Page 336 334 MAINTAINING YOUR VEHICLE when the pads are replaced. However, low fluid level WARNING! may be caused by a leak and a checkup may be needed. • Use only manufacturer’s recommended brake NOTE: If your vehicle is equipped with a manual trans- fluid.
Page 337 MAINTAINING YOUR VEHICLE 335 WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum-based fluid to contaminate moisture, use only new brake fluid or fluid that has the brake fluid. Brake seal components could be been in a tightly closed container.
Page 338: Manual Transmission
336 MAINTAINING YOUR VEHICLE NOTE: If contaminated with water, the fluid should be Manual Transmission changed immediately. Lubricant Selection Appearance Care And Protection From Corrosion Use only the manufacturers recommended transmission fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in Protection Of Body And Paint From Corrosion “Maintaining Your Vehicle”...
Page 339 MAINTAINING YOUR VEHICLE 337 What Causes Corrosion? • If insects, tar, or other similar deposits have accumu- lated on your vehicle, use MOPAR® Super Kleen Bug Corrosion is the result of deterioration or removal of and Tar Remover to remove. paint and protective coatings from your vehicle.
Page 340 338 MAINTAINING YOUR VEHICLE Special Care • If you carry special cargo such as chemicals, fertilizers, de-icer salt, etc., be sure that such materials are well • If you drive on salted or dusty roads or if you drive packaged and sealed. near the ocean, hose off the undercarriage at least once a month.
Page 341 MAINTAINING YOUR VEHICLE 339 • For tough stains, apply MOPAR® Total Clean, or a CAUTION! mild soap solution to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. Do not use scouring pads, steel wool, a bristle brush, or metal polishes.
Page 342 340 MAINTAINING YOUR VEHICLE can act as an abrasive and damage the leather upholstery Plastic is not as scratch resistant as glass and therefore and should be removed promptly with a damp cloth. different lens cleaning procedures must be followed. Stubborn soils can be removed easily with a soft cloth To minimize the possibility of scratching the lenses and and MOPAR®...
Page 343 MAINTAINING YOUR VEHICLE 341 When cleaning the rear view mirror, spray cleaner on the Cleaning Plastic Instrument Cluster Lenses towel or rag that you are using. Do not spray cleaner The lenses in front of the instruments in this vehicle are directly on the mirror.
Page 344: Fuses
342 MAINTAINING YOUR VEHICLE Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. If the belts need cleaning, use a mild soap solution or lukewarm water.
Page 345 MAINTAINING YOUR VEHICLE 343 Vehicle Fuse Cavity Mini Fuse Description Number 7.5 Amp Brown Right Low Beam 5 Amp Tan Front and Rear Ceiling Lights Trunk and Door Courtesy Lights 5 Amp Tan Instrument Panel Node 20 Amp Yellow Central Door Locking 10 Amp Red Diagnostic Socket, Car Radio, Climate Control Sys- 20 Amp Yellow...
Page 346 344 MAINTAINING YOUR VEHICLE Vehicle Fuse Cavity Mini Fuse Description Number 5 Amp Tan Car Radio Switch, Climate Control System, Stop Light, Clutch 5 Amp Tan Stop Light Switch, Instrument Panel Node 5 Amp Tan Exterior Mirror, GPS, Electric Mirror, Parking Sen- 5 Amp Tan Ignition, Climate Control 20 Amp Yellow...
Page 347: Underhood Fuses
MAINTAINING YOUR VEHICLE 345 Underhood Fuses The Front Distribution Unit is located on the right side of the engine compartment, next to the battery. To access the fuses, press the release tabs and remove the cover. Front Distribution Unit The ID number of the electrical component correspond- ing to each fuse can be found on the back of the cover.
Page 348 346 MAINTAINING YOUR VEHICLE Cavity Maxi Fuse Mini Fuse Description 60 Amp Blue Body Controller 20 Amp Yellow Audio Amplifier 20 Amp Yellow Ignition Switch 40 Amp Orange Anti-Lock Brake Pump 70 Amp Tan Electric Power Steering 20 Amp Yellow Radiator Fan - Single Speed 30 Amp Green Radiator Fan - Low Speed...
Page 349 MAINTAINING YOUR VEHICLE 347 Cavity Maxi Fuse Mini Fuse Description 7.5 Amp Brown Transmission 25 Amp White Powertrain (Multiair – If Equipped) 15 Amp Blue Powertrain 15 Amp Blue Powertrain 5 Amp Tan Powertrain (Multiair – If Equipped) 7.5 Amp Brown Air Conditioning 15 Amp Blue Heated Seats –...
Page 350: Vehicle Storage
348 MAINTAINING YOUR VEHICLE Cavity Maxi Fuse Mini Fuse Description 5 Amp Tan Lights 5 Amp Tan Heated Mirrors VEHICLE STORAGE REPLACEMENT BULBS If you are leaving your vehicle dormant for more than 21 Interior Bulbs days, you may want to take these steps to protect your Bulb Number battery.
Page 351: Bulb Replacement
MAINTAINING YOUR VEHICLE 349 Exterior Bulbs Bulb Number Bulb Number Center High Mounted Front Low and High HIR2 Stop Lamp Beam Headlamp License Plate Lamps LED (See Authorized stu- Front Parking/Daytime W21/5W dio) Running Lamps NOTE: Numbers refer to commercial bulb types that Front Fog Lamps can be purchased from your authorized studio.
Page 352: Headlamps Low Beam And High Beam
350 MAINTAINING YOUR VEHICLE Headlamps Low beam and High beam 1. Remove the plastic cap from the back of the headlamp housing. 2. Rotate the bulb counter-clockwise. 3. Remove the bulb and replace as needed. 4. Install the bulb and rotate clockwise to lock in place. 5.
Page 353: Front Fog Lamps
MAINTAINING YOUR VEHICLE 351 6. Install the bulb into socket, and rotate bulb/socket 3. Pull the bulb from the socket and insert the replace- clockwise into lamp locking it in place. ment bulb. 7. Reinstall the plastic cap. 4. Install the bulb and socket assembly into the housing, and rotate the socket clockwise to lock it in place.
Page 354: Rear Tail, Stop, Backup And Turn Signal Lamps
352 MAINTAINING YOUR VEHICLE 4. Remove the tail, stop, or turn signal bulbs by pushing Rear Tail, Stop, Backup And Turn Signal Lamps them slightly and turning counter-clockwise. 1. Open the liftgate. 5. Remove the backup lamp bulb by pulling straight out. 2.
Page 355: Fluid Capacities
MAINTAINING YOUR VEHICLE 353 FLUID CAPACITIES U.S. Metric Fuel (Approximate) 10.5 Gallons 40 Liters Engine Oil with Filter 1.4 Liter Turbo Engine 4 Quarts 3.8 Liters Cooling System 1.4 Liter Turbo Engine (MOPAR® Antifreeze/Engine Coolant 4.6 Quarts 4.4 Liters 10 Year/150,000 Mile Formula) FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component...
Page 356: Chassis
354 MAINTAINING YOUR VEHICLE Component Fluid, Lubricant, or Genuine Part Engine Oil We recommend you use API Certified SAE 5W-40 Full Synthetic Engine Oil, meeting the requirements of Chrysler Material Standard MS-12991. Refer to your engine oil filler cap for correct SAE grade. Engine Oil Filter We recommend you use a MOPAR®...
Page 357: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS MAINTENANCE SCHEDULE ... . .356 ▫ Maintenance Chart.....358...
Page 358 356 MAINTENANCE SCHEDULES NOTE: Under no circumstances should oil change inter- MAINTENANCE SCHEDULE vals exceed 10,000 miles (16,000 km) or twelve months, Your vehicle is equipped with an automatic oil change whichever comes first. indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for Once A Month Or Before A Long Trip: scheduled maintenance.
Page 359 MAINTENANCE SCHEDULES 357 Required Maintenance Intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Refer to the Maintenance Schedules on the following pages for required maintenance. • Inspect engine cooling system protection and hoses. At Every Oil Change Interval As Indicated By Oil •...
Page 360 358 MAINTENANCE SCHEDULES Maintenance Chart Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary. Inspect the brake linings, parking brake function. Additional Maintenance Replace cabin/air conditioning filter.
Page 361 MAINTENANCE SCHEDULES 359 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Replace the spark plugs. ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Inspect and replace PCV valve if necessary. Replace the timing belt.
Page 362 360 MAINTENANCE SCHEDULES WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 363 DEPARTMENT OF TRANSPORTATION UNIFORM ▫ FIAT Customer Center ....363 TIRE QUALITY GRADES ....367 ▫...
Page 364: Suggestions For Obtaining Service For Your Vehicle
362 IF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 365: Fiat Customer Center
• Vehicle delivery date and mileage This is why you should always talk to an authorized FIAT Customer Center studio service manager first. Most matters can be re- solved with this process. P.O. Box 21–8004 •...
Page 366: Service Contract
364 IF YOU NEED CONSUMER ASSISTANCE Canadian residents with hearing difficulties that require The manufacturer will not stand behind any service assistance can use the special needs relay service offered contract that is not the manufacturer’s service contract. It by Bell Canada. For TTY teletypewriter users, dial 711 is not responsible for any service contract other than the and for Voice callers, dial 1 800 855-0511 to connect with manufacturer’s service contract.
Page 367: Warranty Information
However, NHTSA cannot become involved in individual problems between you, your authorized stu- See the Warranty Information Booklet, located on the dio, and the manufacturer. DVD, for the terms and provisions of FIAT Group Automobiles warranties applicable to this vehicle and market.
Page 368: In Canada
Canada, Motor Vehicle Defect Investigations and diagnosing/troubleshooting, problem solving, maintain- Recalls at 1-800-333-0510 or go to http://www.tc.gc.ca/ ing, servicing, and repairing FIAT Group Automobiles roadsafety/ vehicles. A complete working knowledge of the vehicle, system, and/or components is written in straightforward...
Page 369: Department Of Transportation Uniform
The following tire grading categories were established by assistance of service and engineering specialists to ac- the National Highway Traffic Safety Administration. The quaint you with specific FIAT Group Automobiles ve- specific grade rating assigned by the tire’s manufacturer hicles. Included are starting, operating, emergency and...
Page 370: Treadwear
368 IF YOU NEED CONSUMER ASSISTANCE All passenger car tires must conform to Federal safety Traction Grades requirements in addition to these grades. The Traction grades, from highest to lowest, are AA, A, B, and C. These grades represent the tire’s ability to stop on Treadwear wet pavement, as measured under controlled conditions The Treadwear grade is a comparative rating, based on...
Page 371: Temperature Grades
IF YOU NEED CONSUMER ASSISTANCE 369 Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, The temperature grade for this tire is established for representing the tire’s resistance to the generation of heat a tire that is properly inflated and not overloaded. and its ability to dissipate heat, when tested under Excessive speed, under-inflation, or excessive load- controlled conditions on a specified indoor laboratory...
Page 373 INDEX...
Page 374 372 INDEX Adding Engine Coolant (Antifreeze) ... .329 Antifreeze (Engine Coolant) ....328 Adding Fuel ......277 Capacities .
Page 375 INDEX 373 Brake, Parking ......234 Cellular Phone ......205 Brakes .
Page 376 374 INDEX Coolant (Antifreeze) ..... . .353 Disposal Cooling System......327 Antifreeze (Engine Coolant) .
Page 377 INDEX 375 Jump Starting ......299 Enhanced Accident Response Feature ... .49 Towing .
Page 378 376 INDEX Fluids, Lubricants and Genuine Parts ...353 Fuses ........342 Fog Lights .
Page 379 INDEX 377 Cleaning ......340 Instrument Panel Lens Cleaning ....341 High Beam .
Page 380 378 INDEX Hood ....... .109 Oil Pressure ......151 Lead Free Gasoline .
Page 381 INDEX 379 Maintenance Free Battery....317 New Vehicle Break-In Period ....78 Maintenance, General .
Page 382 380 INDEX Onboard Diagnostic System ....310 Preparation for Jacking .....294 Operating Precautions .
Page 383 INDEX 381 Remote Sound System (Radio) Controls ..203 And Pregnant Women .....39 Replacement Bulbs .
Page 384 382 INDEX Shoulder Belts ......29 Storage ....... .348 Side Airbag .
Page 385 INDEX 383 Changing ......293 To Open Hood ......109 General Information .
Page 386 384 INDEX Universal Consumer Interface (UCI) Connector ..202 Water Unleaded Gasoline ......272 Driving Through ......230 Untwisting Procedure, Seat Belt .
Page 387 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 388 Chrysler Group LLC 13FX24-126-AE Fifth Edition Rev 1 Printed in U.S.A.

Save PDF
