Town & Country Fireplaces TC30 Installation And Operating Instructions Manual

Series d modular direct vent fireplace
Hide thumbs Also See for TC30:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instructions for Use Manual, Instruction Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a re or
explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY
Installation and service must be performed
by a quali ed installer, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the re department.
Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certi ed kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room.
020615-48
SERIAL #
TC30
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL TC30
SERIES D
MODULAR DIRECT VENT
FIREPLACE
TC30_D
5056.429D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC30 and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC30

Summary of Contents for Town & Country Fireplaces TC30

  • Page 1 This appliance is not convertible for use with other gases, unless a certi ed kit is used. This appliance is suitable for installation in a bedroom or bed sitting room. MODEL TC30 SERIES D MODULAR DIRECT VENT FIREPLACE 020615-48 TC30_D 5056.429D...

  • Page 2: Table Of Contents

    Top Standoffs ................7 Vent Pipe Dimensions ............29 Framing and Finishing .............. 8 Vent Offset Chart ..............30 TC30 Steel Stud Framing Kit ..........10 Firebox Panels Installation ............31 Adjustable Lintel ..............12 Finishing Touch Trim Kit Instructions ........32 Hearth Extension ..............

  • Page 3: Caution

    This appliance must not be connected to a chimney ue serving a separate solid fuel burning appliance. 5056.429-D TC30-D_020615-48...

  • Page 4: Important Note For The Commonwealth Of Massachusetts

    A copy of all installation instructions for all Product Approved side wall horizontally vented gas fuelled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. 5056.429-D TC30-D_020615-48...

  • Page 5: Minimum Clearances To Combustible Material

    ** MANTEL DEPTH 12” TOP OF LINTEL BAR 6 3/4” 1 1/2” FIREPLACE FRONT Figure 2: TC30 Mantle clearances. Minimum Clearances: CEILING Side standoffs ..........0 in. (0 mm) Back standoffs ..........0 in. (0 mm) MANTEL Top standoffs ..........0 in.

  • Page 6: Manufactured (Mobile) Home

    Figure 5: Accessing Figure 6: Handle. Figure 4: Safety barrier handle. screen. 5056.429-D TC30-D_020615-48...

  • Page 7: Locating The Fireplace

    The minimum clearances from the replace to combustible surfaces must be adhered to and are shown in Figures 2 & 3. EXAMPLES OF COMMON LOCATIONS SEE FIG #XX FOR DIMENSIONS Figure 8: TC30 Common locations. 5056.429-D TC30-D_020615-48...

  • Page 8: Framing And Finishing

    LATION, PLASTIC VAPOR BARRIER OR GAS PLUMBING WITHIN THE STEEL STUD FRAMING ALL OTHER FRAMING CAN BE DONE WITH CONVENTIONAL LUMBER 47 3/8” 12” 47 3/8” 28 1/4” 40 3/8” 5 7/8” Figure 9: TC30 Framing kit dimensions. 5056.429-D TC30-D_020615-48...
  • Page 9 5 7/8" to the sides of the NOTE: It is recommended to pre-drill framing edges. mounting holes in the board prior to securing to the framing. This will prevent Figure 10: TC30 Non combustible board dimensions. the board from cracking. NON-COMBUSTIBLE RECESSED INSTALLATION DETAIL NON-COMBUSTIBLE...

  • Page 10: Tc30 Steel Stud Framing Kit

    TC30 Steel Stud Framing Kit Each Kit Contains: Figure 14: TC30 Framing kit parts. Item Description Screw, Teks #8 x 1/2” (Not Shown) Pkg 40 Stud, Sides Inner, 40 1/4” L Stud, Sides Outer, 40 1/4” L Stud, Center, 12” L Stud, Header Horizontal, 43 1/2”...
  • Page 11 Fasten the outer side studs (3) at the bottom using the base plates (7). Framing brackets 3. Attach the Assembled Frame to the Unit Figure 15: TC30 Framing brackets. • Align and secure the framing plates (8) to the frame so that they are in line with the framing brackets on the replace unit (Figure 15).

  • Page 12: Adjustable Lintel

    1” . 6. Tighten the securing bolts (Figure 18). 3/8 SECURING BOLT Re-attach the window trim. 8. Reinstall safety barrier screen Figure 18: Lintel securing bolt. 5056.429-D TC30-D_020615-48...

  • Page 13: Hearth Extension

    1” above the bottom of the replace. If thicker, replace must be raised accordingly. Caution: Hearth extensions thicker than 1” will interfere with the window frame when opening. 5056.429-D TC30-D_020615-48...

  • Page 14: Electrical

    12. Move the center button on the wall control (Figure 24) to switch the “ON” position. The igniter will start to spark. After a short delay, the pilot will light followed by the main burner. Figure 23: Control box. Wall switch Junction box Gas connector Interface board connector Module 5056.429-D TC30-D_020615-48...

  • Page 15: Selecting Natural Vent And Power Vent Modes

    “NV” . If using a power vent, “PV” should be selected. Follow the instructions provided with the power vent kit for proper installation. Figure 27: Natural vent - Power vent switch. 5056.429-D TC30-D_020615-48...

  • Page 16: Home Automation

    Digital I/O must be connected to a dry contact relay. • Analog ame and light input through 0 - 10 volt DC signal scaled as follows: Low = 1 volt High = 10 volts Figure 29: Home automation wiring detail. 5056.429-D TC30-D_020615-48...

  • Page 17: Gas Pressure Check

    Natural Gas Propane Manifold pressure Min. Pressure 5.0" WC 12.5" WC (For purpose of input adjustment) Max. Pressure 13.9" WC 13.9" WC Manifold Pressure Maximum 3.5" WC 10" WC Minimum 1.6" WC 6.4" WC Figure 30: Gas testing ports. 5056.429-D TC30-D_020615-48...

  • Page 18: Wall Termination Venting

    (Figure 35) The rise and run must be constrained to the boundaries of the chart shown in . The horizontal run of vent must (Figure 35) have a 1/4" rise for every 1 ft. of run towards the termination. 5056.429-D TC30-D_020615-48...
  • Page 19 Wall Termination Kit ..........TCVT.WTA Roof Termination Kit ..........TCVT.RTA Wall Shield/Ceiling Firestop ........TCVT.THIMA Roof Flashing, Adjustable ........TCVT.811FLADJ Roof Flashing, Flat ..........TCVT.811FLFLT Roof Flashing, Steep ..........TCVT.811FLSTP or any ashing that ts 11" pipe Figure 33: Vent system components. 5056.429-D TC30-D_020615-48...
  • Page 20 * Minimum height from the oor to center of the opening with a maximum horizontal run of 34 5/16" using a 24" pipe. The height will need to be increased with a longer horizontal run. Figure 34: Wall vent terminal framing. 5056.429-D TC30-D_020615-48...

  • Page 21: Wall Termination Venting Chart

    90° elbow, or an equal combination of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. A minimum of 1 support every 4’ must be used. Figure 35: Wall termination venting chart. 5056.429-D TC30-D_020615-48...

  • Page 22: Roof Termination Venting Chart

    For each additional 90° elbow, or an equal combination of elbows, reduce horizontal vent run by 2 feet. Ensure vent pipe is properly supported. A minimum of 1 support every 4’ must be used. Figure 36: Roof terminal venting chart. 5056.429-D TC30-D_020615-48...

  • Page 23: Roof Termination Venting

    ROOF SUPPORT BRACKET to accommodate roof pitch. Attach the (TCVT.93915) brackets to the roof joists with nails or building screws. Tighten the band around the vent pipe and secure in place with Figure 38: Roof support bracket. screws. 5056.429-D TC30-D_020615-48...
  • Page 24 VERTICAL TERMINATION CAP (TCVT.9365) VENT PIPE MASTIC (UNDER STORM STORM COLLAR COLLAR) (TC42.90665) FLASHING Note: Adjustable for various roof pitches, from at roof to 12/12 pitch roof. Figure 39: Roof terminal. 5056.429-D TC30-D_020615-48...

  • Page 25: Vent Terminal Minimum Clearances

    ** only permitted if veranda, porch, deck, or balcony is fully open on a minimum of 2 sides beneath the oor* * as speci ed in CAN/CSA B149.1 Installation Codes, Note: local Codes or Regulation may require different clearances * for U.S.A. Installations follow the current National Fuel Gas Code, NFPA54/ANSI Z223.1 5056.429-D TC30-D_020615-48...

  • Page 26: Vent Pipe Sealant

    VENT PIPE Figure 43: Sealing with tape. All outer joints of the vent pipe must be sealed with the approved "High Temper- ature" self-adhesive aluminium tape provided. Wrap the tape completely around the joint and press rmly in place. 5056.429-D TC30-D_020615-48...

  • Page 27: Vent Restrictor Adjustment

    To adjust the restrictor: • Loosen the screw holding the restrictor. • Move the restrictor to its intended opening. • Re-tighten the screw. FULLY OPEN OPENING VENT RESTRICTOR 18" Figure 44: Restrictor wall and roof chart. CAUTION: The vent restrictor must be fully open when using the power vent Figure 45: Vent restrictor. 5056.429-D TC30-D_020615-48...

  • Page 28: Wall Shield/ Ceiling Firestop Thimble

    Fire stop thimble. Figure 46: Figure 47: Wall terminal kit. Roof Termination Kit 16 1/2" VERTICAL TERMINATION CAP TCVT.9365 9" STORM COLLAR TC42.90665 WALL SHIELD / CEILING ROOF SUPPORT FIRESTOP BRACKET TCVT.THIMA TCVT.93915 Figure 48: Roof termination kit. 5056.429-D TC30-D_020615-48...

  • Page 29: Vent Pipe Dimensions

    24" PIPE ..22 1/4" 48" PIPE ..46 1/4" 10 15/16" 9 1/2" TCVT.811X12ADJ 11 1/8" TCVT.811X _ _ 13 13/16" 12 9/16" 8 5/16" 1 5/16" 13 1/8" 7/16" 10 5/16" TCVT.811XLB45 15 7/8" TCVT.811XLB90 Figure 49: Vent pipe dimensions. 5056.429-D TC30-D_020615-48...

  • Page 30: Vent Offset Chart

    1 1/4” 1 1/4 “ 18 3/4" 12" PIPE 29" Adding an adjustable section to 18" PIPE 35" pipe will increase offset by 3" 24" PIPE 41" to 9 1/2" 48" PIPE 65" Figure 50: Vent offset chart. 5056.429-D TC30-D_020615-48...

  • Page 31: Firebox Panels Installation

    Firebox Panels Installation PARK AVE. HERRINGBONE 2 ............TCPN.30PAC2 TC30 PANELS MANHATTAN STACKED BRICK 2 ............. TCPN.30MCN2 MT. VERNON RED BRICK 2 ...............TCPN.30VRC2 BLACK PORCELAIN ................TCPN.770.C COFFE BEAN BROWN PORCELAIN ..........TCPN.770CB.C MILAN 2 ..................... TCPN.30MILC2 TITANIUM .................... TCPN.770TI.C COPPER .....................TCPN.770CU.C...

  • Page 32: Finishing Touch Trim Kit Instructions

    Attach the side rails. Even the ends up with the door frame. Attach the top and bottom rails and adjust so mitres are even at the corners. Place TC magnetic logo in bottom right corner. Larger magnets Top or bottom rail Side rails Figure 53: TC30 trim kit. 5056.429-D TC30-D_020615-48...

  • Page 33: Lighting Instructions

    Serveiller les enfants. Garder les vêtements, le meubles, l'essence ou autres liquides produisant des vapeurs infl ammables loin de l'appareil. S'assurer que le brûleur et le compartiment des commandes sont propres. Voir les instructions d'installation et d'utilisation qui accompagnent l'appareil. 090713 5051.185 GBWY Figure 54: 5051.185 Lighting instructions. 5056.429-D TC30-D_020615-48...

  • Page 34: First Fire

    30 seconds to ignite each time the “ON” button has been selected. Remote Control Operation Blue back lit LCD display ON/OFF Key THERMOSTAT Key UP/DOWN Arrow Key MODE Key Figure 55: Pro ame 2 remote control handset. 5056.429-D TC30-D_020615-48...
  • Page 35 In case of remote control malfunction, turn off the replace using • the “on/off” main switch located on the wall. • For installation/maintenance, turn off the replace at the on/off switch located on the wall and at the replace power supply circuit breaker. 5056.429-D TC30-D_020615-48...

  • Page 36: Initializing The Fireplace For The Rst Time

    On the remote control transmitter, push the power on key once. The remote control transmitter will beep 4 times to indicate that the remote control transmitter and the IFC module are now synchronized. The remote control trans mitter is now ready to use. 5056.429-D TC30-D_020615-48...
  • Page 37 If the batteries of the remote control transmitter are low or depleted, the replace can Figure 62: Display in celcius. be turned off manually using ON/OFF switch located on Town & Country wall switch. This will bypass the remote control transmitter. 5056.429-D TC30-D_020615-48...

  • Page 38: Remote Flame Control

    (Figure 68). A single “beep” will con rm function MAX temp. reception of the command. Figure 67: Comfort fan off. Figure 68: Figure 66: Smart ame Comfort fan max. adjusting temperature. 5056.429-D TC30-D_020615-48...

  • Page 39: Key Lock

    This is an alert for a low battery condition for the IFC board. When the batteries are replaced, a single “beep” will be emitted from the IFC module when a key is pressed (See “Initializing the Fireplace for the rst time” on page 36) 5056.429-D TC30-D_020615-48...

  • Page 40: Maintenance

    Viewing glass may be cleaned as necessary with replace glass cleaner. b) Exterior nish may be cleaned with mild soap and water. CAUTION: Do not use abrasive cleaners on glass or any other part of the replace. Do not clean glass when hot. Figure 73: Pilot light. 5056.429-D TC30-D_020615-48...

  • Page 41: Tc30-D Replacement Parts

    PANEL SETS ITEM DESCRIPTION PART NO. PARK AVE. HERRINGBONE 2 ........TCPN.30PAC2 TC30 BODY..........TC30.D MANHATTAN STACKED BRICK 2 ......TCPN.30MCN2 MT. VERNON RED BRICK 2 ........TCPN.30VRC2 GLASS ASSM C/W GASKET ....GLAS.2066 BLACK PORCELAIN ............TCPN.770.C COFFE BEAN BROWN PORCELAIN ..... TCPN.770CB.C FRAMING KIT ........TC30.

  • Page 42: Replacement Parts - Valve Control System

    2d 1/2" BULKHEAD FITTING 1d CONTROL MOUNTING BRACKET 2e 1/4" BULKHEAD FITTING 1e IGNITION MODULE ELEC BULKHEAD FITTING WIRING HARNESS 1g TRANSFORMER #3... TEST FITTING 1h PRESSURE TEST ASSEMBLY REGULATOR BOARD #4... REMOTE TRANSMITTER PRESSURE SWITCH (not shown) 5056.429-D TC30-D_020615-48...

  • Page 43: Wiring Diagram

    Wiring Diagram 5056.429-D TC30-D_020615-48...

  • Page 44: Rating Label

    ANSI Z21.50-2014 / CSA 2.22-2014 Vented Gas Fireplaces CAN/CGA 2.17-M91 Gas-Fired Appliance For Use At High Altitudes. Certified for / Certifié pour Canada and U.S.A. This Appliance is Equipped For Use With / Cet Appareil est Équipé Pour Utilise Avec : LP-GAS NATURAL GAS LP GAZ GAZ NATUREL FOR USE WITH/ NATURAL GAS/ LP GAS/ MODEL/ TC30 EN CASE D’EMPLOI AVEC: DU GAZ NATUREL DU GAZ LP MODELE: Minimum supply pressure / Pression minimum d’alimentation: 5.0 in/wc / 5.0 po/c.e. 12.5 in/wc / 12.5 po/c.e. (1.25 kPa) (3.11 kPa) (For the purpose of input adjustment / dans le but de régler l’alimenation) Maximum supply pressure / Pression maximum d’alimentation:...
  • Page 45 5056.429-D TC30-D_020615-48...
  • Page 46 5056.429-D TC30-D_020615-48...
  • Page 47 5056.429-D TC30-D_020615-48...
  • Page 48 © 2015 Copyright Paci c Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For technical support, please contact your retailer. Web site: www.townandcountry replaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
