Town & Country Fireplaces TC30.D Installation And Operating Instructions Manual
Horizontal variable depth power vent kit
Hide thumbs
Also See for TC30.D:
- Installation instructions manual (24 pages) ,
- Installation and operating instructions manual (21 pages)
Table of Contents
Advertisement
Quick Links
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation
and Operating Instructions supplied with the fireplace
and should be kept together. Refer to the Installation
and Operating Instructions for proper gas supply, safety
requirements and operating instructions.
Visit www. townandcountry.com for the most recent version of this manual
070322-20
HORIZONTAL
VARIABLE DEPTH
POWER VENT KIT
For use with TC Series "C" & "D" units,
NOT FOR USE with TC54
22270003
22270004
INSTALLATION AND
OPERATING INSTRUCTIONS
TCVT.HPV-D
1 - 25 FEET
7 - 110 FEET
1000035216
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC30.D
Summary of Contents for Town & Country Fireplaces TC30.D
- Page 1 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. These instructions are supplementary to the Installation and Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety HORIZONTAL requirements and operating instructions.
-
Page 2: Power Vent Installation
Powervents Available by Model UNDER NO CIRCUMSTANCES SHALL A RHEOSTAT BE USED MODEL TTCVT.PV1.25 TCVT.PV7.110 TCVT.PVKIT REQUIRED TO ALTER THE VOLTAGE SUPPLY TO THIS UNIT. TC30.D MINIMUM CLEARANCES TO Contents of Power Vent Kit COMBUSTIBLE TC36.DAR Terminal casing: TC36.D 0in. (0mm) ITEM PART No. -
Page 3: Vent Terminal Minimum Clearances
Minimum Vent Length Chart Warning: The clearances listed below are based on testing with allowable temperatures of 170F (75C), some building materials (vinyl, plastic etc.) may be damaged or distorted at these allowable temperatures. Soffits, Siding THIS POWER VENT SYSTEM IS FOR USE WITH 5”& 8” COAXIAL DIRECT VENT PIPING and Decking made with vinyl or other plastics will require larger clearances to prevent heat related damage. - Page 4 Horizontal (Side Wall) Venting Fig. #5 CAUTION: The rise and run combination and the This kit uses either Simpson Duravent GS direct vent pipe, Secure Vent direct vent number of elbows must not exceed pipe, Selkirk Direct-temp vent pipe or ICC Exceldirect vent pipe with a 5” inner pipe specifications in Fig #1 and Fig #2.
- Page 5 7b. For wall thicknesses greater than 7 1/2” and up to a maximum Fig. #11 Fig. #14 Control System Connection ACCESS PANEL ACCESS PANEL of 16 1/2” , attach the inner wall plate to the wall sleeve assembly, using the four screws provided (Fig #9). Then slide this assembly For “Series C”...
-
Page 6: Control System Connection
Pressure Switch Installation Fig. #19 Control System Connection For “Series D” Fireplaces For “Series C” Fireplaces PRESSURE PRESSURE SWITCH SWITCH FIREBOX ACCESS PANEL 1. Connect the pressure switch jumper wires to the he gas control system is located on the right hand side of the firebox behind an Fig. -
Page 7: Pressure Switch Installation
Pressure Switch Installation Fan Wiring For “Series D” Fireplaces The Flush Mount Power Vent assembly has an electrical Fig. #29 connector block mounted internally. The external wiring from the main voltage/control module should be connected to this block. Follow the steps below to access this block. Attach the silicone tube from the upper pressure tap on the power vent . -
Page 8: Venting Components
Dimensions Venting Components 1/2” SIMPSON DURAVENT COMPONENTS SECURE VENT COMPONENTS 5/8” Number Description Number Description 1208 6” Pipe Length SV5L6 6” Pipe Length 1207 9” Pipe Length SV5L12 12” Pipe Length 11/16” 1206 12” Pipe Length SV5L24 24” Pipe Length 7/8”... - Page 9 Wiring Diagram for Series “C” Fireplaces Wiring Diagram for Series “D” Fireplaces Fig. #34 Fig. #35 070322-20_TCVT.PV-D 0703221-20_TCVT.PV-D 100005216 100005216...
-
Page 10: Replacement Parts
Replacement Parts ITEM PART No. DESCRIPTION 80001902 FRONT GRILL COVER 80002217 INNER GRILL 80000553 BLOWER ASSEMBLY 1’ TO 25’ 80000554 BLOWER ASSEMBLY 25’ TO 110’ 80002024 BLOWER GASKET 80002216 MOUNTING FLANGE 80002059 FIRESTOP KIT Fig. #36 070322-20_TCVT.PV-D 0703221-20_TCVT.PV-D 100005216 100005216... - Page 11 © 2019 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For Technical Support, please contact your retailer. www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
