ASSEMBLY INSTRUCTIONS FOR THE TR-100

TABLE TOP

LEGS

STEP-I

Unpack, inspect and lay the parts on a clean, flat, soft surface to avoid marring the wood.

NOTE: During assembly of the furniture please match the tenons and mortise holes with the

corresponding letters or numbers stamped on the component parts.

KINGSLEY-BATE

Fine Garden Furniture

* NOTE

A TENON

B MORTISE HOLE

STEP-II

Fit tenons of the LEGS into the respective

mortise holes of the BASES. If necessary,

gently rock the parts while pushing the tenons

into the mortise holes until joints fit snugly.

Dowel

the photographs.

STEP-III

Fit the LEG STRETCHERS into the LEGS and

dowel the joints. Again, match the numbers of

the tenons with the corresponding mortise

holes. Dowel the joints as shown in the

photographs.

the

joints

shown
